Manual de uso Amana AER5845QAF Cocina

Manual de uso

4

Surface Cooking

Surface Controls

Use to turn on the surface elements. An infinite choice of

heat settings is available from Low to High. The knobs can

be set on or between any of the settings.

Setting the Controls

1. Place pan on surface element.

2. Push in and turn the knob in either direction to the desired

heat setting.

• The control panel is marked to identify which

element the knob controls. For example, the

graphic at right indicates left front element.

3. There is an element indicator light on the control panel.

When any surface control knob is turned on, the light will

turn on. The light will turn off when all the surface

elements are turned off.

When a control is turned on, a glow can be seen through

the smoothtop surface. The element will cycle on and off

to maintain the preset heat setting, even on High.

4. After cooking, turn knob to Off. Remove pan.

Dual Elements

The cooking surface has two dual elements

located in the right front and left front of

the smoothtop. This allows you to change

the size of these elements.

Press the switch to the left to use the large

element or to the right to use the small

element. The selection should be made

prior to turning on the element.

Medium (5-7): Use to

maintain slow boil for

large amounts of liquids

and for most frying

operations.

BEFORE COOKING

• Always place a pan on the surface unit before you turn it

on. To prevent damage to range, never operate surface

unit without a pan in place.

• NEVER use the cooktop as a storage area for food or

cookware.

DURING COOKING

• Be sure you know which knob controls which surface

unit. Make sure you turned on the correct surface unit.

• Begin cooking on a higher heat setting then reduce to a

lower setting to complete the operation. Never use a

high heat setting for extended cooking.

• NEVER allow a pan to boil dry. This could damage the

pan and the appliance.

• NEVER touch cooktop until it has cooled. Expect some

parts of the cooktop, especially around the surface units,

to become warm or hot during cooking. Use potholders

to protect hands.

CAUTION

Suggested Heat Settings

The size, type of cookware and cooking operation will affect

the heat setting. For information on cookware and other

factors affecting heat settings, refer to Cookware

Recommendations on page 7.

AFTER COOKING

• Make sure surface unit is turned off.

• Clean up messy spills as soon as possible.

OTHER TIPS

• If cabinet storage is provided directly above cooking

surface, limit it to items that are infrequently used and can

be safely stored in an area subjected to heat. Tempera-

tures may be unsafe for items such as volatile liquids,

cleaners or aerosol sprays.

• NEVER leave any items, especially plastic items, on the

cooktop. The hot air from the vent may ignite flammable

items, melt or soften plastics, or increase pressure in

closed containers causing them to burst.

• NEVER allow aluminum foil, meat probes or any other

metal object, other than a pan on a surface element, to

contact heating elements.

• NEVER store heavy items above the cooktop that could fall

and damage it.

Low (2): Use to keep foods

warm and melt chocolate

and butter.

High (10): Use to bring

liquid to a boil. Always

reduce setting to a lower

heat when liquids begin to

boil or foods begin to cook.

Med. Low (3-4):

Use to continue

cooking covered

foods or steam

foods.

Med. High (8-9): Use

to brown meat, heat oil

for deep fat frying or

sauteing. Maintain fast

boil for large amounts

of liquids.
