2. Remove toe grille and bottom bracket

cover(s).

• Open freezer door as wide as

possible.

• Depending on the model of your

refrigerator, you may have one or

two bracket covers.

3. Remove top hinge

cover from refrigerator

door by removing

Phillips screw.

•Retain screw and

cover for replace-

ment.

4. Unscrew

5

⁄16" hex head

screws from top hinge

to remove hinge.

• Retain all screws for

later use.

5. Lift refrigerator door from center hinge

pin.

6. For freezer door models

only: Hold freezer door

while removing hinge pin

with a

5

⁄16

" hex head driver.

Remove door from bottom hinge.

• Retain hinge pin for later use.

For freezer drawer models only:

Remove center hinge pin with a

5

⁄16" hex

head driver.

• Retain hinge pin for later use.

7. Remove Phillips

screws to remove

center hinge.

• Retain all screws

for later use.

8. Remove bottom hinge or stabilizing

bracket with

3

⁄8" hex head driver.

• Retain screws for

later use.

• Lift out bottom hinge

pin (some models).

4

Installing your refrigerator

These instructions are provided to aid

you in the installation of your refrigerator.

Amana cannot be responsible for

improper installation.

Measuring the opening

A

1

⁄2" of air space should be provided for

the top and back of the refrigerator. When

installing your refrigerator, measure

carefully.

Subflooring or floor coverings (i.e. carpet,

tile, wood floors, rugs) may make your

opening smaller than anticipated.

Some clearance may be gained by using

the leveling procedure under How to

Level Your Refrigerator (page 10).

IMPORTANT: If refrigerator is to be

installed into a recess where top of refrig-

erator is completely covered, use dimen-

sions from floor to top of hinge cap to ver-

ify proper clearance.

Transporting your

refrigerator

Follow these tips when moving the refrig-

erator to final location:

➢ NEVER transport refrigerator on its

side. If an upright position is not possi-

ble, lay refrigerator on its back. Allow

refrigerator to sit upright for approxi-

mately 30 minutes prior to plugging

refrigerator in to assure oil return to

the compressor. Plugging refrigerator

in immediately may cause damage to

internal parts.

➢ Use an appliance dolly when moving

refrigerator. ALWAYS truck refrigera-

tor from its side or back–NEVER from

its front.

➢ Protect outside finish of refrigerator

during transport by wrapping cabinet

in blankets or inserting padding

between the refrigerator and dolly.

➢ Secure refrigerator to dolly firmly with

straps or bungee cords. Thread straps

through handles when possible. DO

NOT overtighten. Overtightening

restraints may dent or damage outside

finish.

Selecting the best

location

Observe these points when choosing the

final location for your refrigerator:

➢ DO NOT install refrigerator near oven,

radiator or other heat source. If not

possible, shield refrigerator with

cabinet material.

➢ DO NOT install where temperature

falls below 55° F (13° C). Malfunction

may occur at this temperature.

➢ Make sure floor is level. If floor is not

level, shim rear wheels of refrigerator

with a piece of plywood or other shim

material.

➢ To assure proper door closure, verify

that the refrigerator is leveled with a

1

⁄4"

tilt to the back.

How to remove the

doors and hinges

Some installations require door removal

to get refrigerator to final location. If

removal of the pullout drawer is required,

see later section entitled How to

Remove and Install the Pullout Drawer

(page 8).

To avoid electrical shock which can

cause severe personal injury or death,

observe the following:

➢ Disconnect power to refrigerator

before removing doors. Connect

power only after replacing doors.

WARNING

To avoid damage to walls and flooring,

protect soft vinyl or other flooring with

cardboard, rugs or other protective

material.

CAUTION

1. Unplug power cord from power

source.
