Manual de uso

LOCATION OF CONTROLS

16) DUST COVER

17) LEFT SPEAKER

18) VOLUME KNOB

19) POWER ON/OFF BUTTON

20) POWER LED INDICTOR

21) RIGHT SPEAKER

22) HI LOW TONE CONTROL

23) AUTO STOP LED INDICATOR

24) SPINDLE ADAPTOR

25) 33/45 RPM SPEED SELECTOR

26) PICK-UP HOLDER

27) LINE OUT SOCKET

28) FM ANTENNA

29) AUTO STOP SWITCH

30) AC CORD

CAUTION:

USAGE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE

SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

THIS UNIT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT QUALIFIED SERVICE

PERSONNEL.

PRECAUTIONS FOR USE

INSTALLATION

• UNPACK ALL PARTS AND REMOVE PROTECTIVE MATERIAL.

• DO NOT CONNECT THE UNIT TO THE MAINS BEFORE CHECKING THE MAINS VOLTAGE AND BEFORE

ALL OTHER CONNECTIONS HAVE BEEN MADE.

• DO NOT COVER ANY VENTS AND MAKE SURE THAT THERE IS A SPACE OF SEVERAL CENTIMETERS

AROUND THE UNIT FOR VENTILATION.

CONNECTION

3. CONNECT THE POWER CORD TO AC OUTLET

4.

SWITCH THE SYSTME TO “ POWER ON “ POSITION. IF THE POWER LED INDICATOR IS ON WITH RED

LIGHT, IT’S MEAN THE POWER SUPPLY IS NORMAL. NOW YOUR SYSTEM IS READY TO PLAY THE

MUSIC.

PHONO

NOTED:

- REMOVE THE STYLUS PROTECTOR.

- BE SURE THAT THE TONE ARM IS BEING DETACHED FROM THE TONE ARM

REST BEFORE OPERATING AND RE-SECURED AGAIN AFTERWARDS.

8. SET THE SPEED SELECTOR TO THE PROPER POSITION DEPENDING ON

THE RECORD TO BE PLAYED.

9. PLACE THE RECORD ON THE PLATTER (USE THE SPINDLE ADAPTOR IF REQUIRED).

10. LIFT THE TONE ARM FROM THE REST AND SLOWLY MOVE IT TO THE RECORD SIDE.

THE PLATTER WILL START TO ROTATE.

11. PLACE THE TONE ARM TO THE DESIRED POSITION OF THE RECORD.

12. ADJUST THE VOLUME TO THE DESIRED LEVEL.

13. AT THE END OF RECORD, THE PLATTER WILL AUTOMATICALLY STOP ROTATING. LIFT THE TONE ARM

FROM THE RECORD AND RETURN IT TO THE REST.

14. TO STOP MANUALLY, LIFT THE TONE ARM FROM THE RECORD AND RETURN IT TO THE REST.

REMARK: AS SOME KIND OF RECORD THE AUTO-STOP AREA WAS OUT OF THE UNIT SETTING, SO IT WILL

STOP BEFORE THE LAST RACK FINISH. IN THIS CASE, SELECT THE AUTO-STOP SWITCH TO “ OFF

“ POSITION AND THE AUTO-STOP LED INDICATOR (8) WILL TURN ON, THEN IT WILL RUN TO THE END OF

THE RECORD BUT WILL NOT STOP AUTOMATICALLY (TURN OFF THE UNIT BY POWER BUTTON OR SWITCH

BACK THE AUTO-STOP SWITCH TO “ ON “ POSITION TO STOP THE PLATTER ROTATE). THEN PUT BACK THE

TONE ARM TO THE REST POSITION.

E-1
