EN

Installation

Warning: Incorrect installation, operation, maintenance or cleaning of the equipment, as

well as any modification can cause property damage and personal casualty. Fully read and

understand all instructions before installation.

• Avoid placing the appliance on or close to easily flammable materials. Maintain a distance of 20cm (7

inches) between the appliance and walls or other objects for ventilation.

• Avoid positioning the unit in direct sunlight or damp areas.

• Ensure the electrical wires will not be dragged when moving the appliance.

Electrical wiring

DANGER of electric shock from incorrect connection

There is a danger to life if the wires are incorrectly connected.

Connection to a suitable power supply should only be carried out by a qualified and

competent electrical engineer.

Warning: The fixed wiring of the power cord connection must be equipped with a

disconnect device (leakage protection switch) with a contact distance greater than 30mm

according to the wiring rules.

Connect the unit in accordance with the applicable regulations of your country, federal state, city or local

authority.

Connect the unit to a standard energy supply network.

For a proper electrical connection, adjust the power ratings to the local circumstances and requirements.

Equipotential bonding terminal in electrical appliances is to connect exposed metal and conductive

parts of electrical devices and other devices in electrical appliances with artificial or natural grounding

conductors to reduce potential differences (reduce and prevent the risk of electric shock).

• This appliance is supplied unplugged and require hardwiring to a suitable electrical power supply.

CU487 requires a 7kW 400V three-phase circuit at 50Hz

CU488 requires a 14kW 400V three-phase circuit at 50Hz.

• Connect the wires correctly according to their colour coding. This appliance is wired as follows:

Wire colour Wire function To terminals of power supply

Yellow/green Earth wire, protective conductor Terminal marked E

Blue Neutral wire, neutral conductor Terminal marked N

Brown, grey and black Live wires, Phase L1, L2, L3 Terminal marked L1, L2, L3

• The appliance must be earthed. If in doubt consult a qualified electrician.

• Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.
