Manual de uso Campbell Hausfeld TL0502 Llave de impacto

Manual de uso

4

Operating Instructions

Do not make any

modifi cations to

the tool without fi rst obtaining

written approval from Campbell

Hausfeld. Do not use the tool if

any shields or guards are removed

or altered. Do not use the tool as

a hammer. Personal injury or tool

damage may occur.

AIR SOURCE

a. Never connect to an air source that

is capable of exceeding 200 psi.

Over pressurizing the tool is able

to result in bursting, abnormal

operation, breakage of the tool or

serious injury to persons. Use only

clean, dry, regulated compressed air

at the rated pressure or within the

rated pressure range as marked on

the tool. Always verify prior to using

the tool that the air source has been

adjusted to the rated air pressure or

within the rated air-pressure range.

b. Never use oxygen, carbon dioxide,

combustible gases or any bottled

gas as an air source for the tool.

Such gases are capable of explosion

and serious injury to persons.

Do not

use any

type of reactive gases,

including, but not

limited to, oxygen and

combustible gases, as a power

source. Use fi ltered, lubricated,

regulated compressed air only.

Use of a reactive gas instead of

compressed air may cause the tool

to explode which will cause death

or serious personal injury.

Use only

a pressure-regulated

compressed air source

to limit the air pressure

supplied to the tool. The regulated

pressure must not exceed 90 psi.

If the regulator fails, the pressure

delivered to the tool must not

exceed 200 psi. The tool could

explode which will cause death or

serious personal injury.

c. Do not exceed any pressure rating of

any component in the system.

SAVE THESE INSTRUCTIONS

DO NOT DISCARD

OPERATING INSTRUCTIONS

LUBRICATION

Proper lubrication is the owner’s

responsibility. Failure to lubricate the air

tool properly will dramatically shorten

the life of the tool and will void the

warranty.

This impact

wrench requires

lubrication before the initial

use and before and after each

additional use.

Impact wrenches require lubrication

throughout the life of the tool and

must be lubricated in two separate

areas: the air motor and the impact

mechanism. Air tool oil is recommended

because this oil cleans, lubricates and

inhibits rust all in one step.

AIR MOTOR LUBRICATION

The motor must be lubricated daily. An

air motor cannot be oiled too often.

Disconnect the

impact wrench from

the air supply before lubricating.

1. Disconnect the impact wrench from

the air supply.

2. Turn the impact wrench upside

down.

3. While pulling the trigger, squeeze

approximately a 1/4 oz. of airtool

oil in the air inlet. Then, push the

forward and reverse button in both

directions.

After an air tool

has been

lubricated, oil will discharge

through the exhaust port during

the fi rst few seconds of operation.

Thus, THE EXHAUST PORT MUST BE

COVERED WITH A TOWEL before

applying air pressure. FAILURE TO

COVER THE EXHAUST PORT CAN

RESULT IN SERIOUS INJURY.

4. Connect the impact wrench to the

air supply and cover the exhaust port

with a towel. Run the impact wrench

in both the forward and reverse

directions for 20 to 30 seconds. Oil

will discharge from the exhaust port

when air pressure is applied.

IMPACT MECHANISM LUBRICATION

Lubricate the impact mechanism

monthly.

Disconnect the

impact wrench

from the air supply before

lubricating.

1. Disconnect the impact wrench from

the air supply.

2. Remove the slotted screw or allen

head screw from the oil port hole.

3. Squeeze approximately 1 oz. of air

tool oil in the oil port hole. Replace

the screw.

4. Reconnect the air supply to the

impact wrench and run for 20 to 30

seconds. Lubricate the entire impact

mechanism by rotating the tool

upside down and sideways while

running the tool.

5. Remove the screw and hold the oil

port hole over a suitable container

to allow excess oil to drain.

Sometimes triggering the tool when

dumping the oils helps to force out

the excess oil.

6. If the oil is dirty, repeat the

procedure above until the oil comes

out clear. Install the screw and

tighten. The residual oil remaining

in the impact mechanism chamber

is all that is needed for proper

lubrication.

www.campbellhausfeld.com

O

CO

2

90 psi

Important Safety Instructions

(Continued)
