OPERATION FUNCTION

1. Remove all packaging materials.

2. Remove the fryer and remove the frying pan protective paper.

3. Remove the protective film on the console and the adhesive on the product.

4. Pull the fryer handle and open the drawer. Clean the frying basket and the fryer thoroughly with hot

water, detergent, and non-abrasive sponges.

5. Wipe the inside and outside of the product with a wet cloth.

6. Put the frying basket into the fryer, and then put the drawer back into the air fryer.

1. Place the product on a stable, horizontal surface. Do not place running products on a heat-refractory surface.

2. Do not place running products near or below objects that may be damaged by steam (e. g. walls and cabinets).

3. Place the food on the grid rack.

POWER:

220-240V/50/60Hz

POWER RATING:

2400W

CAPACITY:

9L (2 independent 4.5L)

WORK TIME:

0-60 min

TEMPERATURE SETTING:

80-200℃

FRY FORCE:

360° Technology

COOKING FUNCTION

10 One-touch cooking functions

AUTOMATIC SHUT DOWN:

YES

OVERHEAT PROTECTION:

YES

FOOD GRADE MATERIALS:

YES

NON-STICK COATING:

YES

1. Power-on self-test procedure: all lights and digital tubes are lit at the same time for 2 seconds and the buzzer sounds.

2. After the self-test procedure, the key lights start flashing;

3. After clicking the switch, turn on the key light; menu button; temperature time "+" and "-"; the lights operate on, and the

start light (position number) shines.

4. Menu operation: Click the menu key: fries; fish; steak; chestnut; pizza; chicken legs; cake; prawns; bacon; thaw. The menu

program above the menu button is clicked in turn (see the program data below for the menu temperature time)

5. Program data description: after clicking the power button, the default program: 30 minutes; temperature 180℃, Click the

time temperature key to switch, Click Add or subtract to add or subtract time temperature, Bring-in program: Chips: 200 /

15min Fish: 180 / 15min Steak: 180 / 15min Chestnut: 200 / 15min Pizza: 200 / 15min Chicken legs: 200 / 25min Small cake:

200 / 30min Shrimp: 180 / 15min Bacon: 200 / 15min Thaw: 80 / 15min Bring-in program, All procedures plus 5min

preheating temperature unchanged, Preheat light on screen display time temperature digital tube only shows the normal

procedure time, Start any cooking program for the menu (fries; Fish; steak; chestnut; pizza; drumstick; cake; prawn; Baconic;

Thaw out) the light is not on, Temperature switching; switch; cease; +; -; These can be operated and always bright, The

buzzer rings a "pan-turning reminder light" three times every five minutes, Used to remind customers to flip over the

ingredients.

6. Description of function button: tap button once to open other function button; press three seconds to shut down; select

the menu button; temperature switch: long time switch: click the digital tube time, click the second time long time, click the

third time and so on, "+" "-" click to adjust the time temperature for one minute each time, the temperature adjustment

span is 5℃ each time. Key in the program cooking process can directly stop cooking into the cooling program, stop the

button pressed to pause the cooking program of time into the cooling program.

7. Power off memory, when the fryer is working, the fryer suddenly power off the program was suspended, the fryer is

performing the program continued to work (power off memory function execution conditions: power off within 30 minutes).

8. Fryer cooling procedure: after the consumer sets the default program or the program set by the consumer, the fryer beep

three times and the fan rotates for 20 seconds, and the heating pipe stops heating after the end of the procedure.

9. Digital tube switch display every 3-5 seconds, display content example: 15:00 indicates time 15 minutes; 200℃ indicates

temperature 200 degrees Celsius.

10. NTC error code E1; E2.

11. Click the bulb button, the built-in perspective light starts, you can click the bulb button again to turn off, light up within

three minutes, three minutes after the automatic extinguish, you can click the bulb button again to turn off

BEFORE THE FIRST USE

PREPARATION BEFORE USING

Note: Place the product on a fully open table, keep the product at least 15cm from the wall and keep

ventilated.

DESCRIPTION & SPECIFICATION
