Manual de uso Cuisinart DFP-14SENY Robot de cocina

Manual de uso

2

CAPACITY CHART

Recommended work bowl capacity for various foods

FOODS CAPACITY

Chopped and Puréed Fruit

and Vegetables

3 cups

Chopped or Puréed Meat, Poultry,

Fish or Seafood

2

¼ pounds

Bread Dough 2½ pounds (5 cups flour, yielding

two 1-1/4 pound loaves)

Nuts for Nut Butters 3 cups

Sliced or Shredded Fruit,

Cheese, or Vegetables

14 cups

Cake Batter 4 pounds (five 8-inch layers)

Cookie Dough 3½ pounds (90 cookies)

IMPORTANT

UNPACKING

INSTRUCTIONS

This packing contains a Cuisinart

®

Food Processor, and these standard

parts for it: metal chopping blade,

slicing disc and shredding disc, de-

tachable stem for discs and spatula.

CAUTION: THE CUTTING TOOLS

HAVE VERY SHARP EDGES. To

avoid injury when unpacking the

parts, please follow these instruc-

tions:

1. Place the box on a low table or

on the  oor next to the kitchen

counter or table where you plan

to keep the food processor. Be

sure the box is right-side up.

2. Remove the cardboard panel

and the instruction material with

plastic spatula.

3. You will see a rectangular block

of plastic foam that holds the

processor parts each  tted into

a cavity in the foam.

4. The detachable stem (A) for the

discs is in a cavity at one

short side of the foam block.

Remove it  rst.

5. The slicing disc (B) is on one

long side and the shredding

disc (C) on the other. Slide

them out of their grooves WITH

GREAT CARE; THE BLADES

ARE SHARP.

6. Now only the work bowl cover

(D) and the pusher assembly (E)

remain in the foam block. Grasp

the edge of the work bowl cover

and lift it straight up. Lift the

pusher assembly straight up by

following.

7. Lift out the foam block.

8. The machine base and work

bowl with metal blade are at the

bottom of the box.

CAREFULLY REMOVE THE METAL

BLADE BY GRASPING THE CEN-

TER WHITE HUB AND LIFTING

IT STRAIGHT UP. NEVER TOUCH

THE BLADES, WHICH ARE RAZOR

SHARP.

9. Lift the bowl straight up.

10. You will see the machine base

remain at the bottom of the box.

Remove the base by grasping

the base housing with both

hands and lifting it straight up.

Place the base on a counter or

table and read the instructions

thoroughly before using the

machine.

11. Save the shipping cartons and

plastic foam blocks. You may

want to use them in shipping

the processor at a later date.
