Important safety instructions

3

• If an outside antenna or cable system is connected to the

television, be sure the antenna or cable system is grounded so as

to provide some protection against voltage surges and built-up

static charges. Article 810 of the National Electrical Code, ANSI/

NFPA 70, provides information with regard to proper grounding of

the mast and supporting structure, grounding of the lead-in wire

to an antenna discharge unit, size of grounding conductors,

location of antenna-discharge unit, connection to grounding

electrodes, and requirements for the grounding electrode.

• Use No. 10 AWG (5.3 mm

2

) copper, No. 8 AWG (8.4 mm

2

)

aluminum, No. 17 AWG (1.0 mm

2

) copper-clad steel or bronze

wire, or larger, as a ground wire.

• Secure antenna lead-in and ground wires to house with

stand-off insulators spaced from 4-6 feet (1.22 -1.83 m)

apart.

• Mount antenna discharge unit as close as possible to where

lead-in enters house.

• Use jumper wire not smaller than No. 6A WG (13.3 mm

2

)

copper, or the equivalent, when a separate

antenna-grounding electrode is used. See ANSI/NFPA70.

• An outside antenna system should not be located in the vicinity of

overhead power circuits, or where it can fall into such power lines

or circuits. When installing an outside antenna system, extreme

care should be taken to keep from touching such power lines or

circuits as contact with them might be fatal.

• For added protection for this television during a lightning storm,

or when it is left unattended and unused for long periods of time,

unplug it from the power outlet and disconnect it from the

antenna or cable system. This prevents damage to the television

due to lightning and power line surges.

• Do not overload wall outlets and extension cords, because

overloading can cause a fire or electric shock.

• Never push objects of any kind into this television through slots in

the case, as they may touch dangerous voltage points or short out

parts that could result in a fire or electric shock. Never spill liquid

of any kind on the television.

• Do not attempt to service this television yourself, because opening

or removing covers may expose you to dangerous voltages or

other hazards. Refer all servicing to qualified service technicians.

• Unplug this television from the wall outlet and refer servicing to

qualified service technicians under the following conditions:

• When the power cord or plug is damaged or frayed.

• If liquid has been spilled into the television.

• If the television has been exposed to rain or water.

• If the television does not operate normally by following the

operating instructions. Adjust only those controls that are

covered by the operating instructions, because incorrect

adjustment of other controls may result in damage and often

requires extensive work by a qualified technician to restore

normal operation.

• If the television has been dropped or the case has been

damaged.

• When the television exhibits a distinct change in

performance.

• When replacement parts are required, be sure the service

technician has used replacement parts specified by the

manufacturer that have the same characteristics as the original

part. Unauthorized substitutions may result in fire, electric shock,

or other hazards.

• Upon completion of any service or repairs to this television, ask

the service technician to perform routine safety checks to

determine that the television is safe to operate.

Note to cable television system installer

This reminder is provided to call the cable television system installer’s

attention to Section 820 40 of the NEC which provides guidelines for

proper grounding and, in particular, specifies that the cable ground shall

be connected to the grounding system of the building, as close to the

point of cable entry as practical.

Reference Grounding component

1 Electric service equipment

2 Power service grounding

electrode system

(NEC Art 250, Part H)

3Ground clamp

4 Grounding conductors (NEC

Section 810-21)

5 Antenna discharge unit (NEC

Section 810-20)

6Ground clamp

7 Antenna lead-in wire

6

7

5

2

1

3

4
