Manual de uso

3

EN

TABLE SAW 900W - 200MM

The numbers in the text refer to the diagrams

on page 2

For your own safety and that of others, we

recommend that you read this instruction

manual carefully before using this saw.

Keep this instruction manual and the

documentation provided with the saw for

future reference.

Introduction

This tool is suitable for cutting various wall and

floor tiles with a maximum tile size of 500 x 500 x

35 mm. The diamond wheel can be replaced by

the customer. It is not permitted to use the tool for

any other materials.

Contents

1. Machine information

2. Safety instructions

3. Assembly

4. Operation

5. Service & maintenance

1. MACHINE INFORMATION

Technical specifications

Voltage 230 V~

Frequency 50 Hz

Power consumption 900W/S2=10 min*

IP Class IP20

No load speed 2950/min

Max. depth of cut 90º 41 mm

Max. depth of cut 45º 20 mm

Cutting angle 0 - 45°

Ø Cutting blade Ø200 x Ø25.4 x 2.4 mm

Table dimensions 500 x 400 mm

Lpa (sound pressure level) 92+3 dB(A)

Lwa (sound power level) 105+3 dB(A)

Vibration < 2.5 m/s

2

*S2= Maximum period of operation with a

capacity of 900 W

Vibration level

The vibration emission level stated in this

instruction manual has been measured in

accordance with a standardised test given in EN

61029; it may be used to compare one tool with

another and as a preliminary assessment of

exposure to vibration when using the tool for the

applications mentioned

• using the tool for different applications, or with

different or poorly maintainted accessories,

may significantly increase the exposure level

• the times when the tool is switched off or when

it is running but not actually doing the job, may

signifi cantly reduce the exposure level

Protect yourself against the effects of

vibration by maintaining the tool and its

accessories, keeping your hands warm, and

organizing your work patterns.

Contents of packing

1 Tile cutter

1 Water tray

1 Full-length adjustable fence

1 Set of instructions

1 Safety instructions

1 Guarantee card

Check the machine, loose parts and accessories

for transport damage.

2. SAFETY INSTRUCTIONS

Explanation of the symbols

Denotes risk of personal injury, loss of life

or damage to the tool in case of non-

observance of the instructions in this

manual.

Indicates electrical shock hazard.

Immediately unplug the plug from the

mains electricity in the case that the cord

gets damaged and during maintenance.

Wear ear and eye protection.

Faulty and/or discarded electrical or

electronic apparatus have to be collected

at the appropriate recycling locations.
