Manual de uso Frigidaire MLV34FGTWB Lavadora

Manual de uso

4

1.Touch this pad to turn on or off your

washing machine.

2. Selection of Automatic Cycles

Turn the knob to select the desired

program. Depending on the model of

your machine, up to 14 programs may

be available.

3. Start/Pause

Press this pad when you want to

start or pause the operation of

your washer.

4. Soil Level

Press this pad to select the proper

level according to the amount of soil

of the load (minimum to maximum).

5. Selection of stages (manual cycles)

Repeatedly press this pad to select a

single stage or a combination of

washing stages you want to execute,

for example: spin only, or rinse and

spin. Indicator lights will come on

showing the selected stages.

6. My Cycle

This pad will allow you to save your

own wash cycle by selecting the

program of your preference, the

water level, spinning level and desired

temperature. Then press and hold 3

seconds the My Cycle pad to save

your cycle, so every time you require

it, your favorite program will be

executed. The selected options will be

illuminated by just pressing the My

Cycle pad and then the START pad.

7. Delay Start

Use these two pads to select hours

of delay until the start of operation

(1 to 24 hours of delay), then press the

Start pad to confirm and start the

countdown, otherwise the delay will

not be executed. Once initiated the

Delay Start process, you can cancel it

by pressing the “-1 hr” pad for 3

seconds.

8. Temperature Level

Each cycle has recommended wash

temperature. Repeatedly press this

pad if you prefer a different

temperature (from cold to hot).

9. Water/ Load Level

Repeatedly press this pad to select

the desired level, or let the automatic

sensor to determine an optimal level.

We recommend using the automatic

option to efficiently wash a load and

saving large amounts of water.

Note: Both, the automatic and

manual levels are designed to save

water. It is normal that the load is not

completely immersed in water.

10. Spin Level

Repeatedly press this pad to select

the level of drying you want to get for

your clothes aer the wash cycle, or

use the automatic level so the

machine will select the recommended

level according to the selected

program.

ELECTRICAL ENERGY REQUERIMENTS

1

3

5

4

6

7

98 10

11

13

12

14

11. Eco Care

By pressing this pad, you will be

saving more water in each wash cycle.

The EcoCare mode can only be used

in programs marked “EcoCare” in the

“Automatic Programs” knob.

12. Self-Cleaning (alarm)

The LED of this pad will light up

when the machine needs to run the

self-cleaning cycle. When this occurs,

press the “Self-cleaning” pad. Make

sure there are no clothes in the

washing machine and press

Start/Pause.

Note: When you use this program, the

“Automatic programs” knob will be

deactivated (LEDs will be off).

13. Extra Rinse

Press this pad if you want to execute

a double rinse on every wash program

(the Baby cycle always does),

excepting the Whites Cycle, Express

and Spin Wash.

14. Extra Spin

Press this pad if you want to extend

the spin time in order to achieve a

higher drying level. Note: In order to

lock the control panel, press the

“Extra Rinse” and “Extra-Spin” pads at

the same time for 3 seconds.

2
