22 EN

After performing the maintenance, with the hood off and the button active, press the button for more than 3 seconds to perform the

reset of the lter saturation indicator; repeat the operation if necessary (for ex., when both lters are saturated).

Activationofthecharcoalltersaturationindicator

The saturation indicator of the charcoal lter is normally disabled. To activate it, proceed in the following manner:

With the display on (ON) and the suction off (OFF), press simultaneously the buttons T8 and T9 for more than 3 seconds; the button

T9 lights on with steady light for approx. 5 seconds, to indicate the activation.

To disable it, repeat the operation; the button T9 will ash for approx. 5 seconds to indicate the disabling.

Buttons T8 and T9 are not visible at this stage (on some models). They are visible only as described

in operation section of the manual.

Approximate distance of button T8 from T7 is 15 mm, and distance of button T9 from T8 is 40 mm.

Setting of Automatic Operation parameters

For correct use of the automatic operation, perform „Hood Calibration”.

Hood Calibration

With the display on (ON) and the suction off (OFF), press button T3 for 3 seconds.

The suction speed (power) 2 starts functioning and button T3 ashes to indicate that hood calibration is initiated and it will last for approx.

15 minutes.

Note: to interrupt the calibration, press T3 for 5 seconds; the calibration will be invalidated and should therefore be repeated.

WHT943A2XBG, WHT643A2XBG, WHT663S2X, WHT963S2X

To select the functions of the hood press on the symbol. Function will be activated when symbol will be released.

T1. Standby mode (the control panel off – all functions disabled) / ON (control panel switched on)

Note: After about a minute of inactivity (suction and lights), the hood will automatically switch to standby.

T2. ON/OFF lights

On certain models only (see drawing above):

press repeatedly to select the desired light intensity:

L1: low light

L2: medium light

L3: high light

Press again to turn off the lights.

T3. ON/OFF Automatic operation “AdaptTech”.

The hood automatically sets the suction speed (power) 1 to increase if the environmental conditions detected by the hood sensor

require it.

If there are no variations in the environmental conditions, after 10 minutes (if the hood is already in suction speed (power) 1), the hood

turns off.

Note: for a correct use of this function, rst perform the „Setting of the parameters for Automatic Operation” (see corresponding

paragraph).

Note: During automatic operation, if the user acts on the other functions that adjust the speed, auto ventilation function is switched off.

T4. Manual selection of the suction speed (power):

L4: suction speed (power) 1

L5: suction speed (power) 2

L6: suction speed (power) 3

Press again to turn off the hood (OFF).

Note: manual selection excludes any other suction related set function.

T5. ON/OFF Intensive suction speed (power) “POWER BOOST” (timed)

Note: After 5 minutes of operation the hood returns to its previous state.

T6*. (Only certain models ON/OFF intensive suction speed (power) “POWER BOOST x 2” (timed)

Note: After 5 minutes of operation, the hood goes back to the previous status.

T7. ON/OFF operation mode „ReFresh”.

Every 50 minutes of inactivity, the suction speed (power 1 is turned on for 10 minutes.

T8. ON/OFF Timer of the suction speed (power) (approx. 30 minutes)

Note: this function is available for the speeds that can be selected with button T4.

T9. Indicatorandresetltersaturation

The button lights on automatically with steady light when it is necessary to perform the grease lter maintenance.

The button lights on automatically with ashing light when it is necessary to perform the charcoal lter maintenance.

After performing the maintenance, with the hood off and the button active, press the button for more than 3 seconds to perform the

T1 T2 T3 T4 T5 T6 T7 T8 T9

L1 L2 L3 L4 L5 L6

T7 T8 T9

15 mm 40 mm
