English (original instructions)
EN
DE ES IT FR PT NL RU FI SV NO DA PL CS SK SL HR HU RO BG EL AR TR HE LT LV ET
SPECIFICATIONS
Type 2402207
Voltage 24V DC
AIR volume 9.4 m³/min
Air speed 161 KM/H
Weight (Without
Battery)
1.5 kg
Battery Pack 2902707/2902807
Charger
2903607 (VDE PLUG)/
2903507 (BS PLUG)/
2913907 (For both VDE nd BS
PLUG)
Sound pressure level
LpA: 86.8 dB(A) k: 3 dB(A)
Sound power level
LwA: 106 dB(A) K: 3.0dB(A)
Vibration level
ah: <2.5 m/s2; K: <1.5 m/s2
DESCRIPTION
See Figure 1.
1. FRONT BLOWER TUBE
2. REAR BLOWER TUBE
3. TRIGGER
4. TRIGGER HANDLE
ASSEMBLY
UNPACKING
Carefully remove the product and any accessories
from the box.
Inspect the product carefully to make sure no
breakage or damage occurred during shipping.
Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
If any parts are damaged or missing, please call your
Greenworks Tools service centre for assistance.
PACKING LIST
See Figure 2.
Blower
Front Blower Tube
Rear Blower Tube
Operator’s Manual
WARNING
Do not use this product if any parts on the Packing
List are already assembled to your product when you
unpack it. Parts on this list are not assembled to the
product by the manufacturer and require customer
installation. Use of a product that may have been
improperly assembled could result in serious personal
injury.
ASSEMBLING THE BLOWER TUBE
See Figure 3.
WARNING
To prevent accidental starting that could cause serious
personal injury, always remove the batterypack from
the tool when assembling parts.
Align either of the grooves (5) on the tube (2) with the
tabs (7) on the blower housing. Slide the tube onto the
blower housing until the tab engages the grooves.
Turn the tube in the direction of the arrow until both of
the tabs slide into the lock positions (6).
To install the Front tube (1) to Rear Tube (2), line
the hole on the front tube to the tab on the rear tube.
Once aligned slide the front tube on to the rear tube
until the tube is secured.
TO INSTALL/REMOVE BATTERY PACK
See Figure 4.
IMPORTANT! The battery pack is not charged when it
place the battery pack in the battery charger and charge.
Make sure to read all safety precautions, and follow the
instructions in the Battery Charger manual.
TO REMOVE BATTERY PACK
Press and hold the latch button (8) with firm grip.
Grasp the trigger handle (4) firmly. Pull the battery
pack out of the handle.
TO INSTALL BATTERY PACK
Align the tongue (9) of the battery pack with the cavity
in the handle housing.
Push the battery pack into the handle until both sides
lock. The latch button will click when locked into place.
Do not use force when inserting the battery pack. It
should slide into place and click.
WARNING
Follow these instructions in order to avoid injury and to
• Replace the battery pack or the charger immediately
if the battery case or charger cord is damaged.
• Verify that the switch is in the OFF position before
inserting or removing the battery pack.
• Verify that the battery pack is removed and the switch
is in the OFF position before inspecting, adjusting, or
performing maintenance on any part of the blower.
• Read, understand, and follow the instructions
contained in the section entitled Charging Procedure.
1
