Points to observe

Turn off the power supply switch. Do not touch with wet hand. Do not use hot water or volatile liquid.

ON

OFF

Thinner

Do not

use!

Benzine

Tooth powder

"HOT KEEP" function

"HOT KEEP" is operated in the following cases.

When heating is started:

In order to prevent blowing out of cool wind, the indoor unit

fan stopped according to the room temperature which

heating operation is started. Wait for approx. 2 to 3 minute,

and the operation will be automatically changed to the

ordinary heating mode.

Defrosting operation (in the heating mode):

When it is liable to frost, the heating operation is stopped

automatically for 5 to 12 minutes once per approx. one

hour, and defrosting is operated. After defrosting is

completed, operation mode is automatically changed to

ordinary heating operation.

When the room thermostat is actuated:

When room temperature increases and room temperature

controller actuates, the fan speed is automatically changed

to stop under low temperature condition of indoor heat

exchanger. When room temperature decreases, air

conditioner automatically changes over to ordinary heating

operation.

Heat pump type warming

With the heat pump type warming, the mechanism of heat

pump that concentrate heat of outdoor air with the help of

refrigerant to warm the indoor space, is utilized.

Defrosting operation

When a room is warmed with a heat pump type air conditioner,

frost accumulates on the heat exchanger of outdoor unit along

with the drop of indoor temperature. Since the accumulated

frost reduces the effect of warming, it is necessery to

automatically switch the operation to the defrosting mode.

During the defrosting operation, heating operation is

interrupted.

Atmospheric temperature and warming capacity

Warming capacity of heat pump type air conditioner decreases

along with the drop of outdoor temperature.

When the warming capacity is not sufficient, it is recommended

to use another heating implement.

Period of warm-up

Since the heat pump type air conditioner employs a method

to circulate warm winds to warm

the entire space of a room, it takes time before the room

temperature rises.

It is recommendable to start the operation a little earlier in a

very cold morning.

Warming operation

Cleaning the air filter

1.Clean the air filter by lightly tapping it or with the cleaner.

It is more effective to clean

the air filter with water.

If the air filter is very dirty, dissolve neutral detergent in

the lukewarm water (approx. 30

o

C),

rinse the air filter in the water, and thoroughly wash off

the detergent on the air filter

in the plain water.

2.After drying the air filter, set it up on the air conditioner.

CAUTION

CAUTION

14

Heating Mode

Care and Maintenance

Do not open the inlet grill until fan stops completely.

Fan will continue rotating for a while by the law of inertia

after operation is being stopped.

Do not dry the air filter with fire.

Do not run the air conditioner without the air filter.

Pre-Season Care

See that there are no obstacles blocking the air inlet and

air outlet of both indoor and outdoor units.

Make sure that the air filter is not dirty.

Turn on the power supply switch 12 hours before starting

run.

Post-Season Care

Operate the unit with FAN mode on a fair day for about half

a day to dry the inside of the unit well.

Stop operation and turn off the power supply switch. Electric

power is consumed even if the air conditioner is in stop.

Clean the air filter and set it in the place.

Care and Cleaning of the unit

Clean with soft and dry cloth.

If it is very dirty, dissolve neutral detergent in the lukewarm

water and make the cloth wet with the water. After wiping,

clean off the detergent using clean water.
