Operation

Unit start / stop

Remote controller:

Press

button

Every time the button is pressed, temp.setting

increase 1

o

C,if kept depressed, it will increase

rapidly

Every time the button is pressed, temp.setting

decrease 1

o

C,if kept depressed, it will

decrease rapidly

Select a desired temperature.

3.Fan function

2.Select temp.setting

Air conditioner is running under displayed fan speed.

When FAN is set to AUTO, the air conditioner

automatically adjusts the fan speed according to room

temperature.

1. Unit start

Press ON/OFF on the remote controller, unit starts.

/

In HEAT mode,warm air will blow out after a short

periodof the time due to cold-draft prevention function.

When FAN is set to AUTO, the air conditioner automatically

adjusts the fan speed according to room temperature.

Cooling only unit do not have displays and functions

related with heating

Display Board

Remote

Controller

Note

COOL

DRY

HEAT

FAN

nothing

In DRY mode, when room temperature becomes

lower than temp.setting+2

o

C,unit will run intermittently

at LOW speed regardless of FAN setting.

Under the mode of auto operation, air conditioner will

automatically select Cool or Heat operation according

to room temperature.

air conditioner

automatically adjusts the fan speed

temperature.

When FAN is set to AUTO, the

according to room

In FAN operation mode, the unit will not operate in

COOL or HEAT mode but only in FAN mode ,AUTO is

not available in FAN mode.And temp.setting is disabled.

In FAN mode,SLEEP operation is not available.

Operation

Mode

AUTO

nothing

Remote controller

changes as follows:

LOW

MED HI

AUTO

Display

circulated

Emergency operation and test operation

For each press button fan speed

Press button to enter additional options, when

cycle display to , will flash. And then press

enter to FAN function.

Air Flow Direction Adjustment

1.Status display of air flow

When restart after remote turning off, the remote

memorize the previous

Move the vertical blade by a knob on air

to adjust left and right direction referring to Fig.

2.Left and right air flow adjustment

(manual)

Cautions:

When adjusting the flap by hand,turn off the unit.

When humidity is high,condensate water might occur

adjusted to left or

It is advisable not to keep horizontal flap at downward

position for a long time in COOLor DRY

otherwise, condensate water might occur.

conditioner

at air outlet if all vertical louvers are

right.

mode ,

controller will automatically

Note:

set swing position.

3D

Emergency Operation:

Use this operation only when the remote controller is defective

or lost, and with function of emergency running, air conditoner

can run automatically for a while.

When the emergency operation switch is pressed, the " Pi "

sound is heard once, which means the start of this operation.

When power switch is turning on for the first time and

emergency operation starts, the unit will run automatically in

the following modes:

Room

temperature

Designated

temperature

Timer

mode

Fan

speed

Operation

mode

Above 23

o

C

Below 23

o

C 23

o

C

26

o

C

No

AUTO

AUTO

COOL

HEAT

No

It is impossible to change the settings of temp. and fan speed,It

is also not possible to operate in timer or dry mode.

temperature is below 16

o

C, do not use it in the

Test operation:

Use this switch in the test operation when the room

normal operation.

your finger from the switch: the cooling

Continue to press the test operation

switch for more than 5 seconds . After

you hear the "Pi" sound twice,

release

Test operation switch is the same as emergency switch.

operation starts with the air flow speed "Hi".

Under this operation mode,the fan motor of indoor

unit will run in high speed.

COOL/DRY:

HEAT:

Initial state

Pi

Pi Pi

2

1

4

3

3

2
