Indoor Unit Installation

Fix to side bar and lintel a mounting bar, Which is separately sold, and

then

fasten the plate to the fixed mounting bar.

Refer to the previous article, “ When the mounting plate is fi

position of wall hole.

Make a hole of 70 mm in diameter, slightly descending to outside the wall

Install piping hole cover and seal it off with putty after installation

1. Carry out, based on the neighboring pillars or lintels, a

to be fixed against the wall, then temporarily fasten the plate

with

one steel nail.

2. Make sure once more the proper level of the plate, by

hanging a thread

with a

weight from the central top of the plate, then fasten securely the

plate with

the

attachment steel nail.

3.Findthewallholelocation A/C using a measuringtape

When the mounting plate is fixed side bar and lintel

Fitting of the Mounting Plate and

Positioning of the wall Hole

Lid for right

piping

Lid for under piping pipe

Fix with adhesive tape

Lid for left piping

Indoor/outdoor electric cable and drain hose must be bound with

efrigerant

pipingbyprotectingtape.

[ Other direction piping ]

Cut away, with a nipper, the lid for piping according to the piping

direction

and

then bend the pipe according to theposition of wall

hole. When bending, be

careful not to crash

pipes.

Connect beforehand the indoor/outdoor electric cable,

and then

pull out the

connected to the heat insulation of connecting part

specially.

proper leveling

for

the plate

rst fixed “,

for the

Making a Hole on the Wall and Fitting the Piping Hole Cover

Drawing of pipe

Installation of the Indoor Unit

[ Rear piping ]

Draw pipes and the drain hose, then fasten them with the adhesive tape

[Left Left-rear piping ]

In case of left side piping, cut away, with a nipper, the lid for left

piping.

In case of left-rear piping, bend the pipes according to the piping

direction to

the mark of hole for left-rear piping which is marked on

heat

insulation materials.

1. Insert the drain hose into the dent of heat insulation materials of

indoor

unit.

2. Insert the indoor/outdoor electric cable from backside of indoor

unit,

and pull it

out on the front side, then connect them.

3. Coat the flaring seal face with refrigerant oil and connect pipes.

Cover the connection part with heat insulation materials closely,

and

make sure fi

xing with adhesive tape

Hang surely the unit body onto the upper

notches of the

mounting plate. Move the body

from

side to side to verify its

secure fixing.

In order to fix the body onto the mounting

plate,hold up

thebodyaslantfromthe

underside and

thenputitdown

perpendicularly.

R

emove terminal cover at rig

ht bottom corner of

indoor unit, then take

off wiring cover by removing

its screws.

mounting plate

When you unload the indoor unit,please use your hand to arise

slightly and lift the unit aslant until it leaves the mounting plate.

agraffe

mounting plate

the body to leave agraffe,then lift the bottom of the body outward

Heat insulation

material

Drain hose

Piping

Pipe supporting

plate

Indoor/outdoor electric cable

Indoor side

Outdoor side

Ø70mm

Wall hole

Thickness of wall

(Section of wall hole)

Piping hole pipe

G

When the mounting plate is first fixed

Fixing the indoor unit body

Unloading of indoor unit body

Connecting the indoor/outdoor Electric Cable

Removing the wiring cover



ĭPP

37mm

108mm

ĭPP

37mm

45mm
