Manual de uso Hikoki G 18DSL2 Amoladora angular

Manual de uso

9

English

9. Keep away from fi re immediately when leakage or foul

odor are detected.

10. Do not use in a location where strong static electricity

generates.

11. If there is battery leakage, foul odor, heat generated,

discolored or deformed, or in any way appears abnormal

during use, recharging or storage, immediately remove it

from the equipment or battery charger, and stop use.

12. Do not immerse the battery or allow any fl uids to fl ow

inside. Conductive liquid ingress, such as water, can

cause damage resulting in fi re or explosion. Store your

battery in a cool, dry place, away from combustible and

fl ammable items. Corrosive gas atmospheres must be

avoided.

CAUTION

1. If liquid leaking from the battery gets into your eyes,

do not rub your eyes and wash them well with fresh

clean water such as tap water and contact a doctor

immediately.

If left untreated, the liquid may cause eye-problems.

2. If liquid leaks onto your skin or clothes, wash well with

clean water such as tap water immediately.

There is a possibility that this can cause skin irritation.

3. If you fi nd rust, foul odor, overheating, discolor,

deformation, and/or other irregularities when using the

battery for the fi rst time, do not use and return it to your

supplier or vendor.

WARNING

If a conductive foreign matter enters in the terminal of lithium

ion battery, the battery may be shorted, causing fi re. When

storing the lithium ion battery, obey surely the rules of

following contents.

○ Do not place conductive debris, nail and wires such as

iron wire and copper wire in the storage case.

○ To prevent shorting from occurring, load the battery in

the tool or insert securely the battery cover for storing

until the ventilator is not seen.

REGARDING LITHIUM-ION BATTERY

TRANSPORTATION

When transporting a lithium-ion battery, please observe the

following precautions.

WARNING

Notify the transporting company that a package contains a

lithium-ion battery, inform the company of its power output

and follow the instructions of the transportation company

when arranging transport.

○ Lithium-ion batteries that exceed a power output of

100 Wh are considered to be in the freight classifi cation

of Dangerous Goods and will require special application

procedures.

○ For transportation abroad, you must comply with

international law and the rules and regulations of the

destination country.

Wh

Power Output

2 to 3 digit number

NAMES OF PARTS (Fig. 1–Fig. 12)

Motor M5 screw

Push button Nameplate

Side handle Latch

Gear cover Pilot lamp

Depressed center

wheel

Wheel guard

(for cutting)

Wheel guard Wheel washer

Switch Wheel nut

Switch Panel Wrench

Remaining battery

indicator switch

Abrasive cutting

wheel

Remaining battery

indicator lamp

Carbon brush

Battery Filter

Brush cap

SYMBOLS

WARNING

The following show symbols used for the machine.

Be sure that you understand their meaning before

use.

G18DSL2: Cordless Disc Grinder

To reduce the risk of injury, user must read

instruction manual.

Always wear eye protection.

Only for EU countries

Do not dispose of electric tools together with

household waste material!

In observance of European Directive 2012/19/EU

on waste electrical and electronic equipment and

its implementation in accordance with national law,

electric tools that have reached the end of their life

must be collected separately and returned to an

environmentally compatible recycling facility.

V Rated voltage

n

Rated speed

n

0

No-load rotation speed

min

-1

Revolution or reciprocations per minute

Switching ON

Switching OFF

Disconnect the battery

Warning

The battery remaining power is nearly empty.

Recharge the battery soonest possible

The battery remaining power is a half.

The battery remaining power is enough.

000BookG18DSL2EU.indb9000BookG18DSL2EU.indb9 2020/09/2514:21:542020/09/2514:21:54
