This monitor syncs your blood pressure readings to the Homedics
Health
app that is free to download on the App Store
®
and on Google
Play™. Make sure you have the Homedics Health
app downloaded,
and open on your mobile device before trying to transmit your blood
pressure measurements. Before attempting to sync the blood pressure
monitor with your mobile device, make sure Bluetooth
®
is turned ON on
both your mobile device and the monitor.
Transmit Reading
There are 2 ways to activate the Bluetooth
®
function.
Automatically activate: When measurement completed, the device activates the
Bluetooth
®
function automatically, and Bluetooth
®
symbol will flash on the screen.
NOTE: The app must be open for the data to transmit successfully.
Manually activate: Under standby mode, user can press the button for 3
seconds to activate the Bluetooth
on the screen.
NOTE: The app must be open for the data to transmit successfully.
•
symbol will appear on the screen.
• If the monitor cannot be connected to paired Bluetooth
®
- enabled device over 45
seconds, LCD will display Error message "E4" and Bluetooth
®
will be turned off.
NOTE:
• The measurement is stored in the monitor’s memory even if the reading is not
transmitted to your mobile device.
• The Homedics Health
app must be open on your mobile device in order to
transmit your measurements.
• Only new readings will be accepted by the App.
• This monitor can only pair up with one Bluetooth-enabled device at a time.
• To ensure readings transmitted to the App have the correct date and time, it is
important that the correct date and time is set on the blood pressure monitor
before taking measurements.
• Measurements transmitted to the App cannot be edited.
•
device is:
–
–
RECALLING VALUES FROM MEMORY
This monitor can be used by two individuals. Each
user can store up to 120 measurements. This monitor
features a memory mode to provide you with a variety
of options for reviewing your measurement history,
including AM/PM averaging. Reviewing your morning
(AM) and nighttime (PM) measurements can provide
important information about how your blood pressure
changes throughout the day.
1. Press the USER-SELECT
button to choose User 1
or User 2.
2. Press the
button to access the memory.
3. The monitor will first display the calculated average
applied to the last 3 measurements.
NOTE:
• If there is no data stored, nothing (except month, date,
and time) will appear on the display.
• If the records are less than 3, it will display the latest
record.
4. Press the
button again and the monitor will display the average of the last 3
AM readings.
5. Press the
button again to display the average of the last 3 PM readings.
6. Every new press of the
button will recall a previous reading. The latest
reading will be recalled first.
7. To exit memory mode, press START/STOP button, and switch to sleep mode.
Symbol Status
An average of last 3 measurements.
An average of last 3 morning measurements. (4:00AM - 12:00PM)
An average of last 3 nighttime measurements. (6:00PM - 2:00AM)
NOTE: If the wrist positioning guide is ON before the measurement and the
monitor is not in the ideal position,the
icon will be displayed with the saved
readings.
CLEARING VALUES FROM MEMORY
1. Press the USER-SELECT button to choose User 1 or User 2.
2. Press the
button to access the memory
recall mode.
3. Press and hold the DATE/TIME SET
and
buttons at the same time and the data for the
selected user will be erased automatically.
4. To confirm deletion, press the
button and
no data should appear.
NOTE: Once deleted, your readings cannot be restored.
IMPORTANT NOTES REGARDING YOUR
BLOOD PRESSURE MEASUREMENT
• It is suggested that you take your measurements at the same time each day and use the
same wrist for consistency.
• Users should wait a minimum of 5 minutes before taking additional measurements.
More time may be necessary depending upon your physiology.
• The measurement results that users receive are for reference only. If users have any
blood pressure concerns, please consult a physician.
• Once inflation reaches 300 mmHg, the unit will deflate automatically for safety
reasons.
• This device is not suitable for people with arrhythmias.
• This device may have difficulty determining the proper blood pressure for pregnant
women and for users with irregular heartbeat, diabetes, poor circulation of blood,
kidney problems, or for users who have suffered a stroke.
CARE, MAINTENANCE, & CLEANING
• Clean the blood pressure monitor body and cuff carefully with a slightly damp, soft
cloth. DO NOT press. DO NOT wash cuff or use chemical cleaner on it. Never use
thinner, alcohol, or petrol (gasoline) as cleaner.
• Make sure the cuff is completely dry before using.
• Leaky batteries can damage the unit. Remove the batteries when the unit will not be
used for a long time.
• Follow local ordinances and recycling instructions regarding disposal or recycling of
the device and device components, including batteries.
• If the unit is stored near freezing, allow it to acclimate to room temperature before use.
• This blood pressure monitor is not field serviceable. You should not use any tool to
open the device nor should you attempt to adjust anything inside the device. If you
have any problems with this device, please contact Homedics Consumer Relations
(contact information on warranty page).
• DO NOT immerse the unit in water as this will result in damage to the unit.
• DO NOT subject the monitor or cuff to extreme temperatures, humidity, moisture, or
direct sunlight. Protect from dust.
• DO NOT fold the cuff tightly.
• DO NOT disassemble the monitor or cuff. If in need of repair, refer to the warranty
section of this manual.
• DO NOT subject the monitor to extreme shocks (DO NOT drop on floor).
• DO NOT inflate the cuff unless wrapped around wrist.
• DO NOT wrap the cuff around body parts other than your wrist.
• DO NOT drop or insert any object into any opening.
• This monitor may not meet its performance specifications if stored or used outside of
these temperature and humidity ranges:
Storage/Transportation Environment Temperature: -13°F ~ 158°F(-25°C ~ 70°C)
Humidity: Less than 93% RH
Operation Environment Temperature: 41°F ~ 104°F(5°C ~ 40°C)
Humidity: 15 ~ 93% RH
Atmospheric Pressure: 700hPa-1060hPa
POTENTIAL FOR ELECTROMAGNETIC INTERFERENCE
To avoid inaccurate results caused by electromagnetic interference between
electrical and electronic equipment, DO NOT use the device near a cell
phone or microwave oven. For most wireless communication devices, it is
recommended to maintain a distance of 10.8 feet (3.3m) in order to avoid
electromagnetic interference.
SUPPLIER’S DECLARATION OF CONFORMITY
Product Description: Blood Pressure Monitor
Model Number: BPW-800BTA
Trade Name: Homedics
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. This device contains license-exempt
transmitter/receiver that complies with Innovation, Science and Economic Development
Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
U.S. Contact Information
Company: Homedics, LLC.
Address: 3000 N. Pontiac Trail, Commerce Township, MI 48390
8:30am-7:00pm EST Monday-Friday 1-800-466-3342
Homedics is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate the
equipment.
Emissions Test Compliance
Electromagnetic
Environment - Guidance
RF emissions
CISPR 11
Group 1
RF energy is used only to maintain device’s
operation. Therefore, its RF emissions
are so low that it’s not likely to cause any
interference in nearby
RF emissions
CISPR 11
Group B
Harmonic
Emissions IEX
61000-3-2
Not
Applicable
The device is suitable for use in all
establishments, including domestic
establishments, and those directly
connected to the public low-voltage
power supply network that supplies
buildings used for domestic
purposes.
Voltage
fluctuations/
flicker emissions
IEC 61000-3-3
Not
Applicable
Guidance and manufacturer’s declaration – electromagnetic immunity
The device is intended for use in the electromagnetic environments listed
below, and should only be used in such environments:
Immunity Test
IEC 60601
Test Level
Compliance
Level
Electromagnetic
Environment–
Guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 8 kV
contact
discharge
± 15 kV air
discharge
± 8 kV contact
± 15 kV air
In the case of air
discharge testing,
the climatic
conditions shall be
within the following
ranges: Ambient
Temperature: 15°C
~ 35°C Relative
Humidity: 30% ~ 60%.
Power frequency
magnetic field
IEC 61000-4-8
30 A/m
50 or 60 Hz
30A/m
50 or 60 Hz
Power frequency
magnetic fields
should be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment.
Guidance and manufacturer’s declaration – electromagnetic immunity
The device is intended for use in the electromagnetic environments listed below,
and should only be used in such environments:
Immunity
Test
IEC 60601 Test
Level
Compliance
Level
Electromagnetic
Environment–
Guidance
Conducted
RF IEC
61000-4-6
3V rms At
0.15-80 MHz 6V
rms At ISM &
RadioAmateur
Freq
Not Applicable
Portable and mobile RF
communications
equipment should be
used no closer to any
part of the device,
including cables, than the
recommended separation
distance calculated from
the equation applicable
to the frequency of the
transmitter.
Radiated RF
IEC 61000-
4-3
Proximity
fields
from RF
wireless
communica-
tions
equipment
IEC 61000-
4-3
10 V/m at 80-2700
MHz
AM Modulation
And 9-28V/m at
385-6000MHz,-
Pulse Mode and
other Modulation.
The system shall
be tested as spec-
ified in
IEC60601-1-2
Table 9 for
proximity fields
from RF wireless
communications
equipment using
the test methods
specified in IEC
61000-4-3
10 V/m at 80-2700
MHz
AM Modulation
And 9-28V/m at
385-6000MHz,
Pulse Mode and
other Modulation.
The system
shall be tested
as specified
in IEC60601-
1-2 Table 9 for
proximity fields
from RF wireless
communications
equipment using
the test methods
specified in IEC
61000-4-3
Recommended
separation distance
Considering to reduce
the minimum separation
distance, based on RISK
MANAGEMENT, and
using higher IMMUNITY
TEST LEVELS that are
appropriate for the
reduced minimum
separation distance.
Minimum separation
distances for higher
IMMUNITY TEST LEVELS
shall be calculated using
the following equation:
E=6/d
where P is the maximum
power in W, d is the
minimum separation
distance in m, and E is
the IMMUNITY TEST
LEVELS in V/m.
Field strengths from
fixed RF transmitters,
as determined by an
electromagnetic site
survey,a should be less
than the compliance
level in each frequency
range.
b
Interference may
occur in the vicinity of
equipment marked with
the following symbol:
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is
affected by absorption and reflection from structures, objects and people.
a: Field strengths from fixed trans-mitters, such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and
TV broadcast can-not be predicted theoretically with accuracy. To assess the electro-
magnetic environment due to fixed RF transmitters, an electromagnetic site survey should
be considered. If the measured field strength in the location in which the device is used
exceeds the applicable RF compliance level above, the device should be observed to verify
normal operation. If abnormal performance is observed, additional measures may be
necessary, such as reorienting or relocating the device.
b: Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAN ICES-003(B)/NMB-003(B)
RF Exposure Statement
This equipment complies with FCC and ISED RF radiation exposure limits set forth for an
uncontrolled environment. This transmitter must not be co-located or operated in conjunction
with any other antenna or transmitter.
This equipment essential performance per IEC 80601-2-30 additional essential performance
requirements:
• 201.12.1.102 Limits of the error of the manometer from environmental conditions Over the
temperature range of 5°C to 40°C (41°F ~ 104°F) and the relative humidity range of 15% to
93% (non-condensing), the maximum error for the measurement of the CUFF pressure at
any point of the NOMINAL measurement range shall be less than or equal to ‡ 3 mmHg (‡ 0.4
kPa) or 2 % of the reading, whichever is greater.
• 201.12.1.107 Limits of the change in error of the blood pressure determination The
laboratory limits of the change in error of the BLOOD PRESSURE DETERMINATION of the
AUTOMATED SPHYGMOMANOMETER shall be less than 3 mmH (0.4 kPa).
ELECTROMAGNETIC COMPATIBILITY EMC
Guidance and manufacturer’s declaration – electromagnetic emissions
The device is intended for use in the electromagnetic environments listed below,
and should only be used in such environments:
Symbols/
Symptoms
Conditions/Causes Indication/Correction
Unit does not turn on
when START/STOP
button is pushed.
Worn out batteries Replace them with
2 new AAA (LR03)
alkaline batteries.
Battery polarities
have been positioned
incorrectly.
Reinsert the batteries in
the correct positions.
Measuring Error Symbol
appears when blood
pressure value displayed
is excessively low or
high.
Cuff has been placed
incorrectly
Wrap the cuff properly
so that it is positioned
correctly.
Measuring Error Symbol
Air circuit abnormality.
Cuff tube may not be
plugged into
monitor correctly.
Check cuff connection.
Measure again.
Measuring Error Symbol
Inflation pressure
exceeding 300 mmHg.
Switch the unit off, then
measure again.
Measuring Error Symbol
Can’t determine blood
pressure measurement
data.
Wrap the cuff snugly
so that it is positioned
correctly. If you have any
question about the
cuff wearing and/or
measurement result,
please consult your
healthcare professional.
Cuff is worn improperly
Measuring Error Symbol
If the device cannot be
connected to paired
Bluetooth-enabled
device over 45 seconds,
LCD will display (Error
message “E4” and
Bluetooth
®
will be
turned off.
Please press
button
for 3 seconds to start
Excessive Body Motion
Detector
Notice:
The measured blood
pressure reading may
not be accurate if the
icon is displayed.
Body movement
during measurement,
especially, the
movement on the wrist
the blood pressure
monitor is worn on.
e.g. Talking, moving
or shaking of the arm
with the cuff on while
measurement.
Measure again.
Keep steady during
measurement.
Cuff is worn improperly,
or the shape of the wrist
is unusual, excessive gap
might be exist between
the cuff and the wrist.
Wrap the cuff properly
and keep steady.
Measure again. If you
have any question about
the cuff wearing and/or
measurement
result, please consult
your healthcare
professional.
Cuff Fitness detection
Symbol
The cuff was wrapped
incorrectly (for example
too loosely or too
tightly).
Please reference
“Applying the Cuff”
section to wrap the cuff
correctly.
BPM cannot
communicate with
Bluetooth-enabled
device
Pairing has not been
completed.
Please reference
“Applying the Cuff”
section to wrap the cuff
correctly.
Bluetooth
®
function is
not turned on.
See the “Bluetooth
®
Operation” section
to turn on Bluetooth
®
function.
The distance between
BPM and Bluetooth-
enabled device is out of
transmitting range.
Please make sure the
acceptable distance (<10
meters) with each other.
Use an incompatible
Bluetooth-enabled
device.
Please refer to
“Bluetooth
®
Operation”
and “RF Specification”
sections.
Use non-Bluetooth-
enabled device.
Unexpected loss of
electrical/mechanical
integrity.
Reinsert the batteries
and try again.
Test
frequency
(MHz)
Modulation
Immunity
Test Level (V/m)
385 Pulse modulation 18 Hz 27
450 FM± 5 kHz deviation 1kHz sine 28
710
Pulse modulation 217 Hz
a)
9745
780
Test specifications for enclosure port immunity to RF wireless
communications equipment.
If the unit still does not work, contact Homedics Consumer Relations. Under no
circumstance should you disassemble or attempt to repair the unit by yourself.
Contact information for Homedics Consumer Relations Department can be found
in the Warranty page.
SPECIFICATIONS
Follow instruction for use.
TYPE BF Applied Part.
To avoid innacurate results caused by
electromagnetic interference.
WARNING: Portable RF communications
equipment (including peripherals such
as antenna cables and external antennas)
should be used no closer than 30cm (12
inches) to any part of the device. Otherwise,
degradation of the performance of this
equipment could result.
Waste of electrical and electronic equipment
(WEEE). Discard the used product to the
recycling collection point according to local
regulations.
Serial number
YYMMXXXXXX
IP22
Ingress Protection Rating.First characteristic
numeral - Degree of protection against access
to hazardous parts and against solid foreign
objects N1=2 (Protected against solid foreign
objects of 12.5 mm Ø and greater). Second
characteristic numeral Degree of protection
against ingress of water. N2=2 (Protected
against vertically falling water drops when
Non-ionizing electromagnetic radiation.
Test
frequency
(MHz)
Modulation
Immunity
Test Level (V/m)
810
Pulse modulation 18 Hz
a)
28870
930
1720
Pulse modulation 217 Hz
a)
281845
1970
2450 Pulse modulation 217 Hz
a)
28
5240
Pulse modulation 217 Hz
a)
95500
5785
NOTE: If necessary to achieve the IMMUNITY TEST LEVEL, the distance
between the transmitting antenna and the ME EQUIPMENT or ME SYSTEM may
be reduced to 1 m, The 1 m test distance is permitted by IEC 61000-4-3.
a). The carrier shall be modulated using a 50% duty cycle square wave signal.
b). As an alternative to FM modulation, 50% pulse modulation at 18 Hz may be
used because while it does not represent actual modulation, it would be
worst case.
Model Number
HL158B1-BD/ BPW-800BT-WT / BPW-800BTA-WT
Measurement Method Oscillometric
Rated Range of Cuff Pressure 0 ~ 300 mmHg
Rated Range of Determination 40 ~ 280 mmHg
Measurement Range
of Heart Rate
Pulse: 40 ~ 199 Beats / Minute
Accuracy Pressure: ± 3 mmHg
Pulse: ± 5 % Max.
Inflation Automatic Inflation (Air Pump)
Deflation Automatic (Passive Exhaust Valve)
Display Liquid Crystal Display
Memory 240 Memory Total for 2 Users
Unit Dimensions 73.79 mm x 60.15 mm x 22.94 mm (LxWxH)
2.91 × 2.37 × 0.90 inch (LxWxH)
Unit Weight 69 g ± 3 g (Without Cuff & Batteries)
Cuff Size 5.3 ~ 7.7 inch (approx.135 ~ 195 mm)
Storage/Transportation
Environment
Temperature: -25°C ~ 70°C (-13°F ~ 158°F)
Operation Environment Temperature: 5°C ~ 40°C (41°F ~ 104°F)
Humidity: 15% ~ 93% R.H.
Atmospheric pressure: 700 hPa ~ 1060 hPa
Power Supply DC 3V AAA “LR03” (1.5V)
Alkaline Battery x 2
Battery Life Approx. 250 Measurements
Shelf life (battery) 3 years (Temperature: 20 ± 2°C;
Relative humidity: 65 ± 20% RH)
Product Life 5 Years (4 times per day)
Sleeping Mode Without any operation for 1 minute, device
automatically shuts off.
Accessories Instruction Manual, 2 AAA (LR03) Alkaline
Batteries, Storage Pouch
RF Type Bluetooth
®
5.0 BLE
System requirement of the
Bluetooth-enabled device
Bluetooth
®
4.2 for Android 6.0 or above
Bluetooth
®
4.2 for IOS 7.0 or above
* The contents of this
this manual are subject to change for improvement without notice.
For service or repair,
DO NOT return this unit
to the retailer. Contact
Homedics Consumer
Relations at:
Email:
Phone:
1-800-466-3342
Business Hours:
8:30am-7pm EST
Monday-Friday
Distributed by:
Homedics, LLC
3000 N Pontiac Trail
Commerce Township, MI 48390
Printed in China or Vietnam
LIMITED 5-YEAR WARRANTY
Homedics sells its products with the intent that they
are free of defects in manufacture and workmanship
for a period of 5 years from the date of original
purchase, except as noted below. Homedics
warrants that its products will be free of defects in
material and workmanship under normal use and
service. This blood pressure monitor meets the
simulated measurement cycles test requirement
per EN1060-3, part 8.10. This warranty extends only
to consumers and does not extend to Retailers. To
obtain warranty service on your Homedics product,
contact a Consumer Relations Representative.
Please make sure to have the model number of the
product available. Homedics does not authorize
anyone, including, but not limited to, Retailers, the
subsequent consumer purchaser of the product
from a Retailer or remote purchasers, to obligate
Homedics in any way beyond the terms set forth
herein. This warranty does not cover damage caused
by misuse or abuse; accident; the attachment
of any unauthorized accessory; alteration to the
product; improper installation; unauthorized repairs
or modifications; improper use of electrical/power
supply; loss of power; dropped product; malfunction
or damage of an operating part from failure to
provide manufacturer’s recommended maintenance;
transportation damage; theft; neglect; vandalism;
or environmental conditions; loss of use during the
period the product is at a repair facility or otherwise
awaiting parts or repair; or any other conditions
whatsoever that are beyond the control of Homedics.
This warranty is effective only if the product is
purchased and operated in the country in which
the product is purchased. A product that requires
modifications or adoption to enable it to operate
in any other country than the country for which
it was designed, manufactured, approved and/or
authorized, or repair of products damaged by these
modifications is not covered under this warranty.
THE WARRANTY PROVIDED HEREIN SHALL BE
THE SOLE AND EXCLUSIVE WARRANTY. THERE
SHALL BE NO OTHER WARRANTIES EXPRESS OR
IMPLIED INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS OR ANY OTHER
OBLIGATION ON THE PART OF THE COMPANY
WITH RESPECT TO PRODUCTS COVERED BY
THIS WARRANTY. HOMEDICS SHALL HAVE NO
LIABILITY FOR ANY INCIDENTAL, CONSEQUENTIAL
OR SPECIAL DAMAGES. IN NO EVENT SHALL THIS
WARRANTY REQUIRE MORE THAN THE REPAIR
OR REPLACEMENT OF ANY PART OR PARTS
WHICH ARE FOUND TO BE DEFECTIVE: WITHIN
THE EFFECTIVE PERIOD OF THE WARRANTY. NO
REFUNDS WILL BE GIVEN. IF REPLACEMENT PARTS
FOR DEFECTIVE MATERIALS ARE NOT AVAILABLE,
HOMEDICS RESERVES THE RIGHT TO MAKE
PRODUCT SUBSTITUTIONS IN LIEU OF REPAIR OR
REPLACEMENT.
This warranty does not extend to the purchase of
opened, used, repaired, repackaged and/or resealed
products, including but not limited to sale of such
products on internet auction sites and/or sales of
such products by surplus or bulk resellers. Any and all
warranties or guarantees shall immediately cease and
terminate as to any products or parts thereof which
are repaired, replaced, altered, or modified, without
the prior express and written consent of Homedics.
This warranty provides you with specific legal rights.
You may have additional rights which may vary from
state to state. Because of individual state regulations,
some of the above limitations and exclusions may not
apply to you.
For more information regarding our product line in
the USA, please visit: www.homedics.com
©2023 Homedics, LLC. All rights reserved.
Homedics and the Smart Measure word mark and logo are registered trademarks of Homedics, LLC.
American Heart Association is a registered trademark of the American Heart Association, Inc.
use of such marks by Homedics, LLC is under license. The App Store is a service mark of Apple Inc.
Google Play and the Google Play logo are trademarks of Google LLC.
IB-BPW800BTWTB
P/N: 323103709 VER:002
EXPLANATION OF SYMBOLS
TROUBLESHOOTING
If any abnormality arises during use, please check the following points:
SPECIFICATIONS CONT.
TRANSMIT READING TO YOUR MOBILE DEVICE
Únase a la conversación sobre este producto
Aquí puedes compartir lo que piensas sobre Homedics BPW-800BT-WT Tensiómetro. Si tiene alguna pregunta, primero lea atentamente el manual. Puede solicitar un manual utilizando nuestro formulario de contacto.
