Manual de uso Hoover TFV1818 011 Freespace Evo Aspirador

Manual de uso

2

GB

(*Certain Models Only)

USING YOUR CLEANER

Extract power cord and plug it into the power supply. 1. [5] Do not pull the cord beyond the

red marker.

Adjust the telescopic tube to the desired height by moving the telescopic tube adjuster up 2.

and raise or lower the handle to the most comfortable cleaning position. [6]

Carpet & Floor Nozzle. Press the oor type selector on the nozzle 3. [7] to select the ideal

cleaning mode for the oor type.

Hard Floor – Brushes are lowered to protect the oor.

Carpet – Brushes are raised for the deepest clean.

Switch the cleaner on by rotating the On/O Variable Power Control Roller clockwise on the 4.

rear of the cleaner main body. [8]

Adjust the power level by rotating the On/O Variable Power Control Roller to the desired 5.

level. [8]

Switch o at the end of use by rotating the On/O Variable Power Control Roller anti-6.

clockwise to the end. [8] Unplug and gently pull the power cord out of the cleaner and the

cord will begin to automatically retract back into the cleaner. [9]

Parking and Storage - The exible hose and tube can be parked for temporary storage while 7.

in use [10] or in the Nanopack storage position when not in use: Retract the telescopic tube

to its storage length [6]. Remove the nozzle from the end of the telescopic tube [11] and

remove the hose handle from the telescopic tube [12]. Lift the hose latch at the rear of

the cleaner [13] and wrap the exible hose around the product [14]. Park the hose handle

on the product [15]. Assemble the nozzle into the parking slot underneath the product

[16]. Assemble the telescopic tube into the remaining parking slot underneath the product

[17].

CLEANER MAINTENANCE

Replacing The Dust Bag

If the bag check indicator [1C] is red please check and, if necessary, replace the bag.

1. Remove the hose from the cleaner [2].

2. Press the Bag Door Release buttons and remove bag door [18].

3. Pull the bag collar to remove the dust bag [19] and carefully dispose the bag into a bin.

4. Fit a new bag into the cleaner by inserting the bag collar into the bag holder [19].

IMPORTANT: The hose must be removed before removing or replacing the dust bag.

Remember: The bag check indicator may be red if an obstruction has occurred. In this case refer

to ‘Removing A Blockage From the System’.

Cleaning the Filters

To maintain optimum performance of your cleaner, please wash the pre-motor lter and exhaust

lter after each 5 bag changes.

To remove the pre-motor lter:

1. Open the bag door and remove the dust bag from the cleaner (see “Replacing The Dust

Bag”).

2. Press the latch at the top of the pre-motor lter frame to unlock it from the cleaner. Tilt and

remove the lter from the cleaner [20].

To remove the exhaust lter:

1. Unlock the door by rotating the door along arrows indicated [21].

2. Remove the lter pack from the recess [22].

Gently tap and wash the lter packs using hand warm water [23]. Remove excess water from the

lters with a dry cloth and leave to dry fully before re-using. Reassemble lter packs once fully

dry and ret to the cleaner.

Remember: Do not use hot water or detergents. In the unlikely event of the lters becoming

damaged, t a Genuine Hoover consumable. Do not try and use the product without a dust bag

or lter tted.

Cleaning the permanent dust bag (depending on model)

To maintain optimum performance we recommend that you wash the permanent bag after

every 5 full bags. Empty the contents of the Bag into a bin, wash the Bag under handwarm

water, remove excess water with a dry cloth and leave to dry fully before replacing.

Removing a Blockage From The System

If the bag check indicator is red:

1. Check if the bag is full. If so refer to ‘Replacing The Dust Bag’.

2. If it is not full, then;

A Do the lters need cleaning? If so refer to ‘Cleaning the Filter’.

B. Check if there is any other blockage in the system - Use a rod or a pole to remove any

blockage from the telescopic tube or exible hose.

C. Check for and clear any blockage in the Nozzle.

Warning - The bag check indicator will turn red if the cleaner is used when full, if there is

a blockage or if the lters are dirty. If the cleaner is used for a signicant period of time

with the bag check indicator is red, a thermal cut out will switch the cleaner o to prevent

overheating. The bag check indicator turn green once the cleaner has switched o to signal

that the thermal cut out has been activated. If this should happen, switch the cleaner o,

unplug and correct the fault. It will take about 45 minutes for the cut out to automatically

reset.

FreespaceEvo__1-4_union.indd 2 16-04-2010 16:24:28
