EN

2

Installation

 This instruction manual should be kept in a safe place

for future reference. If the washing machine is sold,

given away or moved, please ensure the manual is kept

with the machine, so that the new owner may benefit

from the advice contained within it.

 Read these instructions carefully: they contain vital

information relating to the safe installation and operation

of the appliance.

 Inside the pack containing this manual, you will also

find the guarantee and all the details necessary for

installation.

Unpacking and levelling

Unpacking

1. Once you have removed all the packaging from the

washing machine, make sure it has not been damaged

during transportation.

If it has been damaged, contact the retailer and do not

proceed any further with the installation process.

2. Remove the 4

protective screws (used

during transportation) and

the corresponding spacer,

located on the rear part of

the appliance (see figure).

3. Close off the holes using the plastic plugs supplied in

the pack.

4. Keep all the parts in a safe place; they will be needed

again if the washing machine is moved to another

location, to prevent the inside of the appliance being

damaged.

 Packaging materials should not be used as toys for

children.

Levelling

1. Place the washing machine on a flat sturdy floor,

without resting it up against walls or cabinets.

2. If the floor is uneven,

the front feet of the

machine may be adjusted

until it reaches a horizontal

position (the angle of

inclination must not

exceed 2 degrees).

 If the appliance is levelled correctly, it will be more

stable and much less likely to cause vibrations and noise

while it is operating, particularly during the spin cycle.

 If it is placed on carpet or a rug, adjust the feet in such

a way as to allow a sufficient ventilation space

underneath the washing machine.

Connecting the electricity and water

supplies

Connecting the water inlet hose

 Before connecting the inlet hose to the water supply,

run the water until it is perfectly clear.

1. Connect the inlet hose

to the machine by

screwing it onto the cold

water inlet of the

appliance, which is

situated on the top right-

hand side of the rear part

of the appliance (see

figure).

2. Connect the inlet hose

by screwing it to a cold

water tab using a 3/4 gas

threaded connection (see

figure).

3. Make sure that the hose is not folded over or bent.

 The water pressure at the tap must fall within the

values indicated in the Technical data table (see next

page).

 If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

 Never use second-hand or old inlet hoses; use the

products supplied with the machine.
