Manual de uso Indesit UI6 F2T W Congelador

Manual de uso

EN

1. Control panel

2. LED’s lighting*

3. Ice packs*

4. Ice Mate* or Ice tray*

5. Drawer divider*

6. Bottle rack*

7. Glass shelves

8. Rating plate with commercial name

9. Door reversibility kit

10. Area for freezing fresh food or to store

frozen food

11. Area for storing frozen foods

12. Door seal

* Available on selected models

HOW TO START THE APPLIANCE

After plugging the appliance to the mains, it starts the

operation automatically. After starting the appliance,

wait at least 4-6 hours before placing food into the

appliance. When the appliance is connected to the

power supply, the display lights up and all the icons

appear on the display for approximately 1 second.

The default (factory) values of the freezer

compartment settings light-up.

HOW TO REVERSE THE DOOR SWING

- see enclosed Instructions for Use (Version_2)

Is recommended to reverse door swing by two persons.

There is not foreseen door reversibility for:

- models with integrated handle

- models with glass panel on the door.

Specifications, technical data and images may

vary from model to model

To receive the assistance call the number shown on

the warranty booklet or follow the instruction on the

web site www.indesit.com

12

3

11

2

8

10

4

6

5

7

9

1

Read the Instructions for Use carefully before

using the appliance.

5897110402

QUICK START GUIDE

ALARMS TABLE

ALARM TYPE Signal Cause Cure

Door open alarm

The acoustical alarm is activated and the Alarm Indicator

blinks.

The door has remained open for more than 2 minutes. Close the door or press the Stop Alarm to mute the acoustical alarm.

Temperature alarm

The Temperature display blinks (°C) and the Alarm Indicator

remains on.

The inside temperature is not adequate.

Press the Stop Alarm button

; the acoustical alarm stops, the Temperature Display

(°C) and the Alarm Indicator

remain on until a temperature < -10°C is reached.

Party Mode alarm

The Party Mode Indicator

blinks and the acoustical alarm is activated.

30 min. elapsed since Party Mode function has been activated. It is time to take

out the bottle from the freezer (see Instructions for Use for more details).

Press the Party Mode button or alternatively Stop Alarm button to deactivate the Party

Mode alarm - and remove the bottle from the freezer.

Long black-out alarm

The Black Out Alarm icon

remains on, the Alarm indicator blinks and the Temperature

display (°C) blinks, showing the maximum temperature reached during blackout.

Prolonged power failure, able to cause the inside temperature to increase to 0°C.

Press the Stop Alarm button

; the acoustical alarm stops, the Temperature Display

(°C) and the Alarm Indicator

remain on until a temperature < -10°C is reached.

Malfunction The letter “F” blinks on the display (°C). Product malfunction. Contact the After-sales Service.

ON/STANDBY indicator

FAST FREEZE indicator

ON/STANDBY button

To put the product in Stand-by, press and hold for

3 seconds. All the icons turn off except On/Standby

indicator

. To reactivate the appliance press once

(briefly) this button.

ECO NIGHT indicator

button

Press to activate/deactivate the Eco Night function. The Eco

Night function enables appliance energy consumption to be

concentrated in the reduced rate hours, generally at night

(see the Instructions for Use).

BLACK OUT ALARM

Long Black-out Alarm indicator.

(see the Instructions for Use)

PARTY MODE indicator

PARTY MODE button

Press to activate/deactivate the Party Mode function.

Use this function to chill drinks inside the freezer

compartment.

Important: do not leave the bottle inside the freezer

compartment longer than the function is active

(30 minutes).

STOP ALARM button

Press in case of alarm.

ALARM indicator (see the below Alarms Table)

TEMPERATURE/FAST FREEZE button

Temperature Setting

The appliance is normally factory-set for operation at the recommended temperature of -18°C.

The internal temperature can be adjusted between -16°C and - 24°C, proceeding as follows:

• Press the temperature setting button (°C). The storage temperature can be changed by -1°C

with each pressure of the button: the value changes cyclically between -16°C and -24°C.

Fast Freeze

• Press for 3 seconds to activate the Fast Freeze function (see the Instructions for Use)

The function switches off automatically after about 50 hours.

TEMPERATURE DISPLAY

Printed in Italy 04/17
