3

GB

Description of the appliance

Control panel

Installation

! Before operating your new appliance please read

this instruction booklet carefully. It contains important

information concerning the safe operation, installation

and maintenance of the appliance.

! Please keep these operating instructions for future

reference. Pass them on to any new owners of the

appliance.

Positioning

! Keep all packaging material out of the reach of children.

It may present a choking or suffocation hazard (see

Precautions and tips).

! The appliance must be installed by a qualified

professional in accordance with the instructions provided.

Incorrect installation may cause harm to people and

animals or may damage property.

Built-in appliance

Use a suitable cabinet to ensure that the appliance

functions properly.

• The supporting surface must be heat-resistant up to a

temperature of approximately 100°C.

• If the appliance is to be installed above an oven,

the oven must be equipped with a forced ventilation

cooling system.

• Avoid installing the hob above a dishwasher:

if this cannot be avoided, place a waterproof

separation device between the two appliances.

Ventilation

To allow adequate ventilation and to avoid overheating of the

surrounding surfaces the hob should be positioned as follows:

• At a minimum distance of 40 mm from the back panel

or any other vertical surfaces.

• So that a minimum distance of 20 mm is maintained

between the installation cavity and the cabinet

underneath.

• Kitchen cabinets adjacent to the appliance and taller

than the top of the hob must be at least 600 mm from

the edge of the hob.

Fixing

The appliance must be installed on a perfectly level

supporting surface. Any deformities caused by improper

fixing could affect the features and operation of the hob.

The thickness of the supporting surface

should be taken

into account when choosing

the length of the screws for

the fixing hooks:

• 3,5 mm thick: 9,5 mm screws

The control panel described in this manual is only a representative

example: it may not exactly match the panelon your appliance.

When using the touch control pannel panel:

•

Do not use gloves

•

Use a clean finger

•

Touch the glass smoothly

1 INCREASE(+)/REDUCE(-) POWER button - controls

the power level on every individual cooking zone

2 INCREASE (+)/ REDUCE(-) TIME button -controls the

time of cooking on the cooking zones.

3 COOKING ZONE POWER displays -show the power

level selected for every individual cooking zone

4 ON/OFF button switches the appliance on and off.

5 CONTROL PANEL LOCK button prevents accidental

changes to the hob settings and shows the control

panel has been locked

6. .TIMER display -shows the cookig time selected .

! For detailed information on the control panel functions

refer to “Start-up and use” section.

! This product complies with the requirements of the

latest European Directive on the limitation of power

consumption of the standby mode.

If no operations are carried out for a period of 2

minutes, after the residual heat indicator lights turn

off and the fan stops (if present), the appliance

automatically switches to the .off mode..

The appliance resumes the operating mode once the

ON/OFF button is pressed.

! Depending on the number of heaters/cooking zones on

the hob the COOKING ZONE SELECTED INDICATORS

may vary between 3 and 4

2

5

4

1

6

1

3

3
