Manual de uso

2

GB

! Keep this instruction manual in a safe place for

future reference. Should the appliance be sold,

transferred or moved, make sure the instruction

manual accompanies the washer dryer to inform the

new owner as to its operation and features.

! Read these instructions carefully: they contain vital

information on installation, use and safety.

Unpacking

1. Unpack the machine.

2. Check whether the machine has been damaged

during transport. If this is the case, do not install it and

contact your retailer.

Remove the transit fixings

IMPORTANT: Follow these instructions to remove the

TWO transit fixings.

Situated on either side of the

rear panel,

BOTH transit boltsBOTH transit bolts

BOTH transit boltsBOTH transit bolts

BOTH transit bolts

MUST be rMUST be r

MUST be rMUST be r

MUST be r

emoved beforemoved befor

emoved beforemoved befor

emoved befor

e usee use

e usee use

e use.

! Failure to do so may cause

damage to your machine.

It is important the transit bolt

and spacer (see pic) come out

intact.

1. Unscrew the bolt using a

13mm spanner.

2. STOP when 3 threads can be

seen.

3. Hold, slide sideways and pull

to remove.

4. For safety, insert one of the

two plastic covers (supplied

with your machine) over the

hole.

! Repeat steps 1 to 4 to remove

the second transit bolt.

! Packaging materials are not

children’s toys.

Levelling

Your machine will be noisy if the two front feet are not

adjusted so that the machine stands firm and level.

! The machine should be levelled from side to side and

from front to back.

1. Move your machine into its final location.

- Take care not to trap or kink the hoses.

2. Turn one or both front feet

anti-clockwise by hand until the

feet cannot be turned any

more.

When adjusting the feet, use a

spirit level to check the machine

stands level, from side to side

and from front to back.

- The spring on each foot will stop them coming

loose.

! If it is placed on a fitted or loose carpet, adjust the

feet in such a way as to allow enough room for

ventilation beneath the machine.

Water connection

Connecting the water inlet hose.

Remember that this is a cold-fill machine.

! Check that seal is in place

inside the hose end cap.

Before making the water connections to gas ¾

thread, allow the water to run freely from the supply

tap until it is perfectly clear.

Screw the inlet end with the

blue cap onto the cold water

supply tap.

Turn the taps on and check for leaks: tighten if

necessary.

! Make sure there are no kinks or bends in the

hose.

! The water pressure at the tap must be within the

values indicated in the Technical details table (next

page).

! If the water inlet hose is not long enough, contact a

specialist store or an authorised serviceman.

! Always use new hoses.

! Check the water hose at least once a year, replace

any that are cracked as worn hoses could split under

water pressure.

Installation

WIDXXL126-GB.p65 10/01/06, 12.002
