Manual de uso ION Live LP Giradiscos

Manual de uso

4

Features

1. Platter – Place your record here.

2. Tonearm* – The tonearm can be raised and

lowered by hand, or by pressing the raise /

lower lever. Please note that the tonearm

needs to be moved away from resting position

(on the arm clip) for the turntable motor to

activate. When the tonearm is placed back in

its resting position, the turntable motor will

deactivate if Autostop has been turned on.

3. Arm Clip – This specially designed arm clip

secures the tonearm while at rest or when not

in use. The arm clip has been designed to

remain in the up position while unlocked.

4. Raise / Lower Lever – Raises and lowers the

tonearm.

5. 33 / 45 / 78 Switch – This switch controls the

RPM of the turntable platter.

6. 45 RPM Adapter Holder – Holds the

included 45 RPM adapter. When not using

the adapter, please place it in this holder.

7. Autostop Switch – This switch turns

autostop on or off. When autostop is on, the

platter will start spinning when the tonearm is

placed over the record and stop spinning when the

record has reached the end. (When autostop is off, the

platter will always spin regardless of the position of the

tonearm.)

Note: If your vinyl record stops before it reaches the

end of the music, turn Autostop to the off position for

this particular record. This is generally recommended

for 45 RPM records.

8. Speakers – Listen to the audio from your playing vinyl

record.

9. Volume – Controls the audio output from your

speakers.

10. RCA Output** – The audio from a playing vinyl record

is sent to this line-level coaxial audio output. This must

not be connected to phono level devices. (If you do not

already have an RCA cable, this can be found at a

local electronics retailer.)

11. Power – Use the included adapter to connect to wall power.

12. Power Button – Press this button to turn Live LP on/off.

IMPORTANT: Remove the plastic

cartridge cover (needle cover) before

operating the turntable.

** WARNING: The RCA outputs are LINE

level. Please only connect these to LINE

level inputs. You may damage your

receiver if you plug in a LINE level device

into a PHONO level input.

AUTO STOP

ON OFF

1

2

4

3

5

7

8

8

9

6

11

12

10

* IMPORTANT: If the turntable's stylus

becomes worn, purchase a replacement

at ionaudio.com/ict09rs. If you play 78

RPM records, we recommend using a 78

RPM stylus, which you can purchase at

ionaudio.com/ict06rs.
