Manual de uso Juiceman JM400 Licuadora

Manual de uso

AUTOMATIC JUICE EXTRACTOR

EXTRACTOR DE JUGO AUTOMÁTICO

MODEL/MODELO

❍ JM400

Customer Care Line:

USA 1-800-231-9786

Accessories/Parts (USA)

1-800-738-0245

For online customer service

and to register your product, go to

www.prodprotect.com/applica

Servicio para el cliente:

México 01-800 714-2503

Accesorios/Partes (EE.UU)

1-800-738-0245

Para servicio al cliente y para

registrar su garantía visite

www.prodprotect.com/applica

2011/6-6-22E/S

Enjoy the Fresh Side of Life

TM

3. Lift up on the lid to remove from the base.

To remove easily, you may need to lift up on

the front first, then disengage the back of

the lid from the pulp spout on the juice bowl

(M).

4. Grasp bottom of the pulp container and

pull it away from the base, titling slightly to

release it from behind the pulp spout (N).

5. Lift up on the rim of the filter over the back

of the pulp spout. This will disengage the

filter from the drive shaft and you can lift it

out easily (P).

Important: The cutting blades at the bottom

of the filter are extremely sharp! Always hold

and carry the filter by the rim.

6. Grasp the sides of the juice bowl with both

hands and lift off the base.

PREPARATION

How to prepare fruits and vegetables for juicing.

Purchasing and Storing Ingredients:

• Always use fresh fully ripened fruits and vegetables.

• When purchasing, consider selecting fruits and vegetables in season for best

freshness and flavor.

• Choose fruits that are plump, tender and have bright color. Fruits should be

heavy for their size without bruises, cuts or blemishes.

• To ripen fruit, place in a small clean paper bag. Close the bag loosely and let

stand at room temperature. (To speed ripening, add a ripe apple or banana to the

bag.) Once ripened, store in the refrigerator for a day or two until ready to use.

• Store perishable vegetables in the refrigerator until ready to use.

Preparing Fruits and Vegetables:

• Wash fruits and vegetables thoroughly just before using in the juice extractor

using a natural bristle brush and a biodegradable cleaner to help remove

pesticide residue.

• If desired, remove the skin. The skin may be left on all produce with the

exception of:

o All citrus fruits, including

• Oranges • Grapefruit • Lemons • Limes • Tangerines

o Papaya

Note: The oil in the skin of these fruits tastes bitter and is difficult to digest. When

removing skin from citrus fruits, remove the white pith, as well, to keep finished

juices from tasting bitter.

Hint: Although the skin may be left on melons, you may choose to remove them to

maximize the fruit flavor in the finished drink.

• All pits and large seeds should be removed from fruits, including:

o Apricots o Cherries o Nectarines o Mangoes

o Peaches o Plums o Melons o Papaya

•

Remove and discard outer leaves of non-organic produce. Peel away any wax coatings.

M

N

P

• Trim any bruised or discolored sections of fruits and vegetables.

• The design of the feed chute accommodates larger produce. It will easily

accommodate most whole fruits and vegetables, such as, apples, beets, carrots

and celery. If necessary, cut into large pieces before inserting into feed chute.

• Be sure all parts of the juice extractor are clean and dry. See the CARE AND

CLEANING instructions.

USING YOUR JUICE EXTRACTOR

1. Assemble the fruits and/or vegetables to be used on the counter or in a bowl next

to the extractor.

2. Place the juice pitcher, a clean measuring cup or a glass under the spout.

3. Be sure the pulp container is in place.

Note: When using the appliance, do not allow the pulp container to overfill. This may

cause the appliance to stall.

4. Plug appliance into standard electrical outlet.

5. Turn the power to the low setting (1) and allow it to run 10 seconds.

6. Select the low speed (1) for soft-to-medium textured fruits and vegetables; use

the high speed (2) for hard foods, such as, carrots, beets and broccoli.

7. Insert the fruits and/or vegetables into the feed chute and use the food pusher as

a guide to gently direct the produce through the feed chute. To get the most juice

from the fruits and vegetables, do not rush the food through the appliance.

Note: Never place fingers or hands into the feed chute.

8. The juice extractor will automatically separate the juice and pulp.

Important: Both the juice pitcher and pulp container can be emptied at any time.

Always turn the dial to off (0) and allow the motor to come to a complete stop before

emptying either. Be sure to replace both containers before resuming extraction.

9. When juicing is complete, turn the dial to off (0) and wait for the motor to come

to a complete stop. Allow all remaining juice to drip into juice pitcher before

removing it.

Tip: You can tip your juice extractor forward to help the remaining juice drain from the

juice bowl. Simply unplug, grip the base close firmly with both hands close to the top

and tip forward until all juice has drained.

10. Unplug appliance and follow directions under DISSASEMBLING YOUR JUICE

EXTRACTOR.

HINTS AND TIPS

• Do not put food into the extractor before turning the appliance on.

• For best results, refrigerate fruits and vegetables before juicing.

• Let the appliance run for at least 10 seconds before placing any food into the feed

chute.

• Do not let the juice pitcher or pulp container overfill while using the machine. Turn

the appliance off, wait for the motor to stop running and any juice to stop flowing.

Empty the juice pitcher and/or pulp container. Be sure they are properly replaced

before resuming operation of the extractor.

• For easy cleanup, place a plastic bag inside the pulp container before using the

appliance.

• Do not process bananas, avocados or coconut. They have no juice and will clog the

appliance.

• Be sure to remove all pits and large seeds from fruits.

• To make delicious citrus juice, peel the fruit, removing all the white pith.

Refrigerate until cold and process the fruit through the extractor for a great drink.

• For maximum nutritional benefits, drink your processed juice right away.

FOR OPTIMUM JUICING

• Avoid excessive build up of pulp on the underside of the cover lid.

• Use the pusher as a guide. Do not use excessive force. Food allowed to flow slowly

through the extractor produces more juice.

USES FOR THE PULP

The pulp from the fruits and vegetables is high in nutritional value. Use it to add fiber

and flavor to muffins and quick breads. Use it to thicken soups, casseroles and sauces.

Use fruit pulp to add nutrition and flavor to desserts, such as puddings and cakes. Be

sure to use it the same day you extract the juice.

Pulp is also food for your garden. You can use it as compost.

Copyright © 2011 Applica Consumer Products, Inc.

Made in People’s Republic of China

Printed in People’s Republic of China

Fabricado en la República Popular de China

Impreso en la República Popular de China

Please Read and Save this Use and Care Book

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed including the following:

❍ Read all instructions.

❍ To protect against risk of electrical shock do not put cord, plugs or

appliance in water or other liquid.

❍ Close supervision is necessary when any appliance is used by or

near children.

❍ Unplug from outlet when not in use, before putting on or taking off

parts, or before cleaning.

❍ Avoid contacting moving parts.

❍ Do not operate any appliance with a damaged cord or plug or

after the appliance malfunctions, or is dropped or damaged in any

manner. Return appliance to the nearest authorized service facility

for examination, repair or electrical or mechanical adjustment. Or,

call the appropriate toll-free number on the cover of this manual.

❍ The use of attachments not recommended or sold by the

manufacturer may cause fire, electric shock or injury.

❍ Do not use outdoors.

❍ Do not let cord hang over edge of table or counter.

❍ Always make sure juicer cover is clamped securely in place before

motor is turned on. Do not unfasten clamps while juicer is in

operation.

❍ Be sure to turn switch to OFF position after each use of your juicer.

Make sure the motor stops completely before disassembling.

❍ Do not put your fingers or other objects into the juicer opening

while it is in operation. If food becomes lodged in opening, use food

pusher or another piece of fruit or vegetable to push it down. When

this method is not possible, turn the motor off and disassemble

juicer to remove remaining food.

❍ Do not use the appliance if the rotating sieve is damaged.

❍ Do not operate without the pulp container in place.

SAVE THESE INSTRUCTIONS

This product is for household use only.

POLARIZED PLUG (120V Models Only)

This appliance has a polarized plug (one blade is wider than the other). To

reduce the risk of electric shock, this plug is intended to fit into a polarized

outlet only one way. If the plug does not fit fully into the outlet, reverse the

plug. If it still does not fit, contact a qualified electrician. Do not attempt to

modify the plug in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped with a tamper-resistant screw to

prevent removal of the outer cover. To reduce the risk of fire or electric

shock, do not attempt to remove the outer cover. There are no user-

serviceable parts inside. Repair should be done only by authorized

service personnel.

ELECTRICAL CORD

a) A short power-supply cord (or detachable power-supply cord) is to be

provided to reduce the risk resulting from becoming entangled in or

tripping over a longer cord.

b) Longer detachable power-supply cords or extension cords are available

and may be used if care is exercised in their use.

c) If a long detachable power-supply cord or extension cord is used,

1) The marked electrical rating of the detachable power-supply cord or

extension cord should be at least as great as the electrical rating of the

appliance,

2) If the appliance is of the grounded type, the extension cord should be a

grounding-type 3-wire cord, and

3) The longer cord should be arranged so that it will not drape over the

countertop or tabletop where it can be pulled on by children or tripped

over.

Note: If the power-supply cord is damaged, it should be replaced by

qualified personnel, or in Latin America by an authorized service center.

Product may vary slightly from what is illustrated.

† 1. Food pusher cap (Part # 71291B)

† 2. Food pusher (Part # 71273B)

† 3. Feed chute (Part # 71268FT)

4. Safety locking lever

† 5. Lid (Part # 71268LID)

† 6. Stainless steel mesh filter (not

shown) (Part # 71269)

† 7. Juice bowl (Part # 71270B)

8. Juice spout

† 9. Juice pitcher with froth separator

(Part # 71275)

10. Base

† 11. Cleaning brush (Part # 71266B)

12. Speed control

† 13. Pulp container (Part # 71274)

14. Pulp spout

15. Pulp opening

Note: † indicates consumer replaceable/

removable parts

A

5. Engage the safety locking lever with the

safety lock hook on the feed tube (F). You

should hear a click as it locks in place.

Important: Your juice extractor will not operate

if the safety locking lever is not properly locked.

6. Tilt the pulp container slightly and place it

directly beneath the pulp opening. Push the

bottom of pulp container inward so top edge

slides up, behind the pulp spout. Continue

to press firmly on the bottom of the pulp

container until it fits snugly against the

base (G). When correctly positioned, pulp

container will be completely covered by the

pulp opening in the lid.

Tip: To make cleaning easier, you may wish to

line the pulp container with a small plastic bag

to catch the pulp as you juice.

Important: Your juice extractor will not operate unless the pulp container

is correctly placed.

7. Place the froth separator into the juice

pitcher, then place the lid on top. Position

the pitcher beneath the juice spout. Be sure

that the juice spout empties into the larger

opening in the pitcher lid (H).

8. Keep the food pusher in the feed chute until

you are ready to juice. To insert, rotate the

food pusher until the groove on the food

pusher is properly aligned with the ridge in

the feed chute (J).

DISASSEMBLING YOUR JUICE EXTRACTOR

Important: Always make sure your juice extractor is unplugged before

starting to disassemble.

1. Press down on safety lock button, swing

safety locking lever away from feed tube.

Release safety lock button (K).

2. Unlock the feed chute by rotating it clockwise

to remove it from the lid (L).

B

C

How to Use

This product is for household use only.

GETTING STARTED

• Remove all packing material, and any stickers from the product.

• Remove and save literature.

• Please go to www.prodprotect.com/applica to register your warranty.

• For additional information about your new juice extractor go to

www.juiceman.com.

• Your juice extractor is partially assembled in the box.

• Take the appliance apart and wash all removable parts as instructed in the

CARE AND CLEANING section of this manual. This will remove any traces

of dust or residue left from manufacturing and shipping.

• Place on a dry level counter to prepare to assemble.

ASSEMBLING YOUR JUICE EXTRACTOR

Important: Always make sure your juice extractor is unplugged before

starting to assemble.

1. Place juice bowl over base with juice spout

facing toward the safety locking lever. Lower

juice bowl onto the base so that spout slides

through the oval ring on the base (B).

2. With both hands, hold the filter by the rim

and center it over drive shaft inside the juice

bowl. Carefully lower filter into the juice bowl,

rotating slightly until it drops into place; press

down firmly on the rim to secure (C).

Note: When assembled properly, the filter will

spin freely in the juice bowl. To check that it is

assembled properly, simply try spinning the

filter by the rim.

3. Place the lid on the juice bowl so that the pulp

opening is positioned over the pulp spout.

Position the back of the lid over the edges of

the pulp spout first; then lower the lid to fit

firmly against the base (D).

4. Center feed chute over lid opening so that the

safety lock hook on the feed tube is slightly

to the right of the arrow on the lid. Insert

three tabs located around bottom of the

feed tube into the three slots on the lid. Turn

counterclockwise until the safety lock hook on

feed chute aligns with the arrow on the lid (E).

D

E

F

G

H

J

K

L

CARE AND CLEANING

This product contains no user-serviceable

parts. Refer service to qualified service

personnel.

Important: Always unplug your juice

extractor from the outlet before cleaning.

CLEANING

1. Disassemble your juice extractor following

the instructions in DISSASSEMBLING

YOUR JUICE EXTRACTOR.

2. Using a sponge or damp cloth, clean the

base, rubber feet and underside of the

juice extractor. If necessary, you may use

a damp toothbrush or cloth to clean juice

from the inside the drive shaft (on top of

motor base).

Important: Do not immerse the base in

water or spray with water. Clean only by

wiping with a damp sponge, cloth or paper

towel.

3. All juicer parts – except the base – are

dishwasher-safe (top-rack only) or you

may wash in warm, soapy water, using

any mild liquid dishwashing detergent. Do

not use any products containing ammonia

or scouring powders, as these can dull,

scratch or mar the surface. Use the

cleaning brush provided to remove pulp

left on any of the removable parts. Do not

use metal brushes or pads.

4. To clean the food pusher properly, remove

the center cap in the cover of the food

pusher. To remove, grasp cap and lift

directly out of food pusher, using the

notch for leverage. Once parts are dry,

replace the cap.

5. To clean the filter, use cleaning brush

provided to make sure tiny holes in

mesh filter are not clogged. This can be

accomplished by holding filter basket

under a running faucet while brushing the

mesh filter screen from both the inside

and outside of the filter mesh.

REMOVING TOUGH STAINS

1. Due to powerful staining properties of

carotenoids found in many vegetables,

particularly carrots, we suggest soaking

any stained parts overnight in one of the

following solutions:

• Biodegradable soap in enough warm

water to cover juice extractor parts

• ¼ cup bleach added to a sink full of warm

water

• 1 part warm water to 1 part cider vinegar

• ½ small box of baking soda in enough

warm water to cover juicer parts

Important: Never use ammonia or abrasive

cleansers!

2. After soaking overnight, lightly scrub with

soft bristle brush and liquid detergent.

STORAGE

Store your juice extractor in a clean, dry

place. Never wrap cord tightly around the

appliance. Do not put any stress on cord

where it enters juicer, as this could cause

cord to fray and break.

OVERHEAT PROTECTION SYSTEM

Important: This appliance contains a PTC

overheat protection system. When the

appliance is being operated for too long or

with too much load, the PTC protector will

shut down the power of the appliance to

protect the unit. If the power shuts down,

unplug for 15 minutes and plug in for

normal operation.

Puntuación

Más sobre este manual

Entendemos que es bueno tener un manual en papel para tus Juiceman JM400 Licuadora. Siempre puedes descargar el manual desde nuestro sitio web e imprimirlo tú mismo. Si deseas tener un manual original te recomendamos contactar con Juiceman. Es posible que puedan proporcionar un manual original. ¿Estás buscando el manual de tu Juiceman JM400 Licuadora en otro idioma? Elija su idioma preferido en nuestra página de inicio y busque el número de modelo para ver si lo tenemos disponible.

Especificaciones

Todos los manuales para Juiceman Licuadoras
Más manuales de Licuadoras

Preguntas frecuentes sobre Juiceman JM400 Licuadora

Nuestro equipo de atención al cliente busca información útil sobre los productos y responde a las preguntas frecuentes. Si encuentra inexactitudes en las preguntas frecuentes, indíquenoslo usando nuestro formulario de contacto.

Productos relacionados

Manual de uso

Juiceman JM480S Licuadora

Manual de uso

Juiceman JM300 Licuadora

Manual de uso

Juiceman JM550S Licuadora

Manual de uso

Juiceman JM1000M Licuadora

Manual de uso

Juiceman JM2000S Licuadora

Manual de uso

Juiceman JM8000S Licuadora

Manual de uso

Peabody PE-SJ15 Licuadora

Manual de uso

Girmi SW1002 Licuadora

Categorias relacionadas
