Manual de uso

NOTE: It is easier to adjust the leveling legs if you have another

person to assist you.

1. Move the ice maker to its final location.

NOTE: If this is a built-in installation, move the ice maker as

close as possible to the final location.

2. Place the level on top of the product to see whether the ice

maker is level from front to back and side to side.

3. Push up on the top front of the ice maker, and then locate the

leveling screws that are on the bottom front of the ice maker.

4. Using an adjustable wrench, change the height of the legs as

follows:

■ Turn the leveling leg to the right to lower that side of the

ice maker.

■ Turn the leveling leg to the left to raise that side of the ice

maker.

NOTE: The ice maker should not wobble. Use shims to add

stability when needed.

5. Push up on the top rear of the ice maker and locate the

leveling legs that are on the bottom rear of the ice maker.

6. Follow the instructions in Step 4 to change the height of the

legs.

7. Use the level to recheck the ice maker to see that it is even

from front to back and side to side. If the ice maker is not

level, repeat steps 2 to 5. If the ice maker is level, go to the

“Connect Water Supply” section.

Water Filtration System

Install the Water Filter

1. Locate the accessory packet in the ice maker and remove the

water filter.

2. Take the water filter out of its packaging and remove the

cover from the O-rings. Be sure the O-rings are still in place

after the cover is removed.

3. The water filter compartment is located in the right-hand side

of the ice maker control panel.

4. Using the arrow pointing to the alignment pin on the side of

the filter and the arrow inside the control housing, align the

alignment pin with the cutout notch and insert the filter into

the housing.

5. Turn the filter clockwise until it locks into the housing. Ensure

that the alignment arrow on the filter head aligns with the

locked symbol on the control box housing.

NOTE: If the filter is not correctly locked into the housing, the

ice maker will not produce ice.

The Water Filter Status Light

The water filter status lights will help you know when to change

your water filter.

■ The “Order Filter” status light will be illuminated when it is

time to order a replacement filter.

■ The “Replace Filter” status light will be illuminated when it is

time to replace the filter.

■ Replacing the disposable water filter with a new filter will

automatically reset the filter status tracking feature. See

“Using the Controls.”

NOTES:

■ “Replace Filter” will remain illuminated if a filter is not

installed.

■ The “Filter” status light will flash if the filter is not correctly

installed or there is an obstruction in the water line.

A. Cover

B. O-rings

C. Alignment pin

D. Alignment arrow

Do not use with water that is microbiologically unsafe or

of unknown quality without adequate disinfection before

or after the system. Systems certified for cyst reduction

may be used on disinfected waters that may contain

filterable cysts.

A. Alignment pin

B. Unlocked symbol

C. Locked symbol

D. Cutout notch inside control housing

E. Arrow pointing to cutout notch

F. Arrow pointing to alignment pin

A. Alignment arrow aligned with locked symbol
