13

6. Pour one bottle of solution into the water pan. Fill the bottle

twice with tap water and pour it into the water pan.

7. Press the CLEAN button. See “Using the Controls.” The

Clean button will blink, indicating that the cleaning cycle is in

process. When the “Cleaning Complete” light is illuminated

(approximately 70 minutes), the cleaning cycle is complete.

During the cleaning cycle, the system will both clean and

rinse itself.

8. After the cleaning cycle is complete, remove the drain cap

from the water pan. Look for any cleaning solution left in the

water pan. If cleaning solution drains from the water pan, you

should run the clean cycle again. Be sure to refill the water

pan with cleaner before starting the clean cycle again. Be

sure to replace the drain cap securely on the water pan. If the

drain cap is loose, water will empty from the water pan and

you will have either thin ice or no ice.

NOTE: Severe scale buildup may require repeated cleaning with

a fresh quantity of cleaning solution.

9. Press the ON/OFF button to resume ice production.

Condenser

A Dirty or Clogged Condenser

■ Obstructs proper airflow.

■ Reduces ice making capacity.

■ Causes higher than recommended operating temperatures

which may lead to component failure.

1. Unplug ice maker or disconnect power.

2. Remove the 2 screws in the lower access panel and the

2 screws from the base grille area of the front panel support.

3. Pull the bottom forward and then pull down to remove the

lower access panel.

4. Remove dirt and lint from the condenser fins and the unit

compartment with a brush attachment on a vacuum cleaner.

5. Replace the lower access panel using the 4 screws.

6. Plug in ice maker or reconnect power.

Interior Components

1. Unplug ice maker or disconnect power.

2. Open the storage bin door and remove any ice that is in the

bin.

3. Remove the drain cap from the water pan and drain

thoroughly. Replace the drain cap securely on the water pan.

If the drain cap is loose, water will empty from the water pan,

and you will have either thin ice or no ice.

4. Remove the screw from the cutter grid cover.

5. Unplug the wiring harness from the left side of the cutter grid.

6. Unplug the ice level sensor from the right side of the cutter

grid. Pull the ice level sensor down and forward away from

the cutter grid.

7. Remove the right-hand and left-hand screws. Lift the cutter

grid up and out.

A. Water pan

B. Drain cap

A

B

WARNING

Electrical Shock Hazard

Disconnect power before cleaning.

Replace all parts and panels before operating.

Failure to do so can result in death or electrical shock.

A. Lower access panel screws

B. Base grille screws

A. Condenser fins

A. Cutter grid cover

B. Screw

A

B

A

B

A

A

B
