Manual de uso Klip Xtreme KLS-700 Magno Altavoz

Manual de uso

3. button

IV. Initial setup

V. Operating modes

1. Plug the AC cable to a wall outlet.

2. When the unit is not in use or switched off, it will automatically recharge the internal battery as long as it

remains connected to utility power.

3. The charge LED lights up in red to indicate that the unit needs charging. When the battery is fully

charged, the charge LED will turn green.

Note: For your safety, read this manual and follow all safety instructions before using the product.

1. Auxiliary playback

Charging the battery

1. Turn the volume control on the top panel fully counterclockwise.

2. Connect audio input devices first. Make sure that all input sources such as microphones, CD players or

digital media players are turned off and volume settings are set to their lowest settings (zero).

3. Connect one end of the AC cable to the louspeaker and the other end to the wall outlet.

4. Press and hold the power switch for about 5 seconds to turn on the speaker.

5. Turn the volume clockwise slowly until the sound reaches the desired level. If there is no sound, check to

make sure the source device is providing audio output.

Powering on the unit

1. Insert AA batteries into the handheld microphone by carefully unscrewing the base and aligning the “+” and

“-“ terminals of the batteries with the corresponding contacts inside the compartment.

2. Turn on the microphone. The speaker will detect the device automatically.

3. When not in use, switch the wireless microphone off to conserve battery power.

Using the wireless microphone

a. Use the supplied audio cable to connect the speaker to external audio devices through the Auxiliary input

located on the top panel.

b. If the speaker is not set to the AUX IN, press the MODE button until the corresponding input mode is

found.

c. When the AUX indicator is displayed on the screen, you can start streaming audio directly from compatible

multimedia sources.

d. Please note that the forward and backward song selection is not available on this mode.

4. button

5. button

Control Description

1. Power button

2. Mute button

Press this button briefly to turn the speaker ON/Standby.

Remote control

In addition to the panel controls, a remote control is included which provides additional functions to allow greater control

over the media player.

• Install the batteries in the remote control following the correct polarity as indicated inside the compartment. (Requires

two AAA batteries).

• In order for the remote to operate properly, ensure that it is pointed toward the front of the speaker.

Cancels the audio coming from the speaker. Press it again to unmute the speaker in

all modes.

In Bluetooth

®

, USB and SD

TM

mode, press this button briefly to play the next track.

Press and hold this button to fast forward tracks on your playlist.

In tuner mode, press it briefly to go to the next channel or song.

Press to play and pause media during Bluetooth

®

, SD

TM

or USB playback.

In Bluetooth

®

, USB/SD

TM

, press this button briefly to play the previous track. Press and

hold this button to fast backward tracks on your playlist .

In tuner mode, press it briefly to go to the previous channel or song.

7. SCAN button

8. REPEAT button

6. Vol +/- buttons

Increases or decreases the volume level of the speaker.

In tuner mode, press this button to go down to the previous channel. Press and

hold it to scan the different playing stations.

In USB and SD

TM

modes, use it to repeat a single track or repeat all tracks.

Turns the LED lights on or off.

Use it to scroll through the different sound effects.

Press this button to enter the

Bluetooth

®

mode

Use it to connect a cd player, digital media player, a mobile phone or other audio

sources to this 3.5mm stereo jack

Use it to play audio from MP3 and WMA music files stored in a USB memory stick or

SDTM card.

Tuner Use this button to switch into the FM mode.

9. Light button

10. EQ button

11. BT button

12. Aux In button

13. USB port and MicroSD

TM

memory card button

14. Tuner

15. Numbered keypad

In USB and SD

TM

modes, press any key from 0 to 9 on the remote to choose directly

the tracks you want to play. In tuner mode, it allows the manual input of frequencies.

Note: In order to save power, when the power supply is switched off by the remote control, the speaker can only be

restarted by pressing the Power button.

1 2 3

4 5 6

7 8 9

0

EQLIGHT

SCANRPT

BT TUNER

AUX SDUSB

VOL+

VOL-

CH- CH+

1 2

10

6

3 4

9

11

12

8 7

14

13

5

6

15
