Media panel controls

In addition to the top panel keys, an infrared remote control is included which provides additional functions to

allow greater control over the media player.

1. Install the supplied batteries in the remote control following the correct polarity as indicated inside the

compartment.

2. In order for the remote to operate properly, ensure that it is pointed toward the front of the speaker.

Remote control

Control Description

Press it to select the audio source connected to the 3.5mm stereo line-in jack

on the back of the unit

Press it to select Bluetooth

®

as the input mode

Press it to select the audio source connected to the USB port on the top

panel of the speaker

Press this button to switch the device from standby to active mode, and vice

versa

Press this button to cycle through the six different lighting schemes, and also to

disable this feature

Enables the channel selection, tuning and storage of scanned frequencies

In USB or Bluetooth

®

mode, press this button to select the previous or next

track in your playlist

In tuner mode, this button will scan memorized channels in a downward or

upward direction

This feature is not available in auxiliary mode

Increases or decreases the bass (low) frequencies of the speaker

In USB or Bluetooth

®

mode, press this button to start and pause media

In tuner mode, press and hold to initiate the scanning of channels from the

lowest up to highest frequency, and store them automatically as presets in the

memory

This feature is not available in auxiliary mode

Amplifies the low-frequency output by a few notches. When this function is

enabled, Loud appears on the screen. The screen will change to Null when

the booster is disabled

Adjust this knob to control how much of an echo effect is applied to the signal

from the microphones actively connected to the speaker

1. AUX mode

2. BT

3. USB

4. ST-BY

5. LED illumination

6. Tuner

10. BASS BOOSTER

11. Echo knob

9.

8. Bass + / -

7. /

Control Description

Controls the audio level of the wireless and wired microphones actively

connected to the speaker

Mic volume 1 will control the audio from both wireless microphones plus the

input from a wired microphone connected to Mic 1. Mic volume 2 will

control the Mic 2 input from a wired microphone.

Toggles the signal from a wired microphone and guitar connected to the

Mic 2 stereo input. When the button is depressed, the microphone

reverberation is disabled.

These stereo 1/4-inch jacks accepts the input from a wired microphone or

guitar

Controls the overall audio level from all inputs. Turn it counterclockwise to

lower the volume. A clockwise rotation will increase the volume level of the

speaker

Connect your USB flash drive to play MP3 and WMA music files

It exhibits the mode, volume level, the selected channel and the track being

played

12. Mic. volume 1 / Mic. volume 2

13. Mic /Guitar button

14. Mic. 1 /Mic 2

15. Master volume

16. USB port

17. LED display

12

9

8

6

4

2

3

10

7

5

1

11

13

TUNER

USB

14

11

12

7

8

9

13

1

2

3

4

5

6

151716

10
