Using Control Switch

The control switch may be set to three positions:

forward, reverse and lock. Due to a lockout mecha-

nism, the control switch can only be adjusted when

the ON/OFF switch is not pressed. Always allow

the motor to come to a complete stop before using

the control switch.

1. For forward (clockwise) rotation, push the

control switch in the direction shown. Check the

direction of rotation before use.

2. For reverse (counterclockwise) rotation, push

the control switch in the direction shown. Check

the direction of rotation before use.

3. To lock the trigger, push the control switch to the

center position. The trigger will not work when

the control switch is in the locked position.

Always remove the battery pack before perform-

ing maintenance, changing accessories, storing

the tool and any time the tool is not in use.

Push for

Forward

Push for

Reverse

PUSH TO CENTER TO LOCK

Fig. 2

Starting, Stopping and Controlling Speed

These tools may be operated at any speed from

0 to full speed.

1. To start the tool, pull the trigger.

NOTE: An LED is turned on when the trigger is

pulled.

2. To vary the driving speed, simply increase or

decrease pressure on the trigger. The further

the trigger is pulled, the greater the speed.

3. To stop the tool, release the trigger and the

electric brake stops the tool instantly.

Impacting Techniques

The longer a bolt, screw, or nut is impacted, the

tighter it will become. To help prevent damaging the

fasteners or workpieces, avoid excessive impact-

ing. Be particularly careful when impacting smaller

fasteners because they require less impacting to

reach optimum torque.

Practice with various fasteners, noting the length

of time required to reach the desired torque. Check

the tightness with a hand-torque wrench. If the

fasteners are too tight, reduce the impacting time.

If they are not tight enough, increase the impact-

ing time.

Oil, dirt, rust or other matter on the threads or

under the head of the fastener affects the degree

of tightness.

The torque required to loosen a fastener averages

75% to 80% of the tightening torque, depending on

the condition of the contacting surfaces.

On light gasket jobs, run each fastener down to a

relatively light torque and use a hand torque wrench

for fi nal tightening.

OPERATION

WARNING Always remove battery

pack before changing or removing acces-

sories. Only use accessories specifically

recommended for this tool. Others may be

hazardous.

WARNING To reduce the risk of injury,

wear safety goggles or glasses with side

shields.

Fig. 1

Attaching and Removing Accessories

Square drive shank

These impact wrenches are intended only for use

with sockets designed for impact wrenches that

have a 3/8” (Cat. No. 2651-20) or 1/2” (Cat. No.

2652-20) square drive. Other sockets could shatter

or break, causing injury.

1. To attach a socket or other accessory, align the

accessory with the drive shank and push it fi rmly

over the retaining ring.

2. To remove the accessory, pull the accessory off

the drive shank.

Hex drive chuck

This driver is intended for use with drill and driver

bits with a 1/4” hex shank and ball detent recess.

1. To attach an accessory, pull the ring out and

insert the accessory shank. Release the ring. It

may be necessary to pull the bit out slightly to

engage the holding mechanism.

2. To remove the accessory, pull out the ring and

remove the accessory. Release the ring.

ASSEMBLY

WARNING Recharge only with the

charger specifi ed for the battery. For specifi c

charging instructions, read the operator’s

manual supplied with your charger and battery.

Inserting/Removing the Battery

To remove the battery, push in the release buttons

and pull the battery pack away from the tool.

To insert the battery, slide the pack into the body of

the tool. Make sure it latches securely into place.

WARNING Use only sockets and other

accessories specifi cally designed for use on

impact wrenches and drivers. Other sockets

and accessories might shatter or break caus-

ing injury.

WARNING Always remove battery

pack before changing or removing acces-

sories. Only use accessories specifically

recommended for this tool. Others may be

hazardous.
