Attaching and Removing Accessories

1/4" Hex Impact Driver (Cat. No. 2667-20)

This impact driver is intended for use with drill and

driver bits with a 1/4" hex shank and ball detent

recess.

1. To attach an accessory, pull the ring out and

insert the shank. Release the ring. It may be

necessary to pull the bit out slightly to engage

the holding mechanism.

2. To remove the accessory, pull out the ring and

remove the accessory. Release the ring.

3/8" Impact Wrench (Cat. No. 2668-20)

1. Use only the appropriate size Square Drive

Sockets.

2. To attach a socket, align the accessory with the

anvil and push it fi rmly over the retaining ring.

3. To remove the accessory, pull the accessory

off the anvil.

ASSEMBLY

WARNING Recharge only with the

charger specifi ed for the battery. For specifi c

charging instructions, read the operator’s

manual supplied with your charger and battery.

Inserting/Removing the Battery

To remove the battery, push in the release buttons

and pull the battery pack away from the tool.

To insert the battery, slide the pack into the body

of the tool. Make sure it latches securely into place.

WARNING Use only sockets and other

accessories specifi cally designed for use on

impact wrenches and drivers. Other sockets

and accessories might shatter or break caus-

ing injury.

WARNING Always remove battery

pack before changing or removing acces-

sories. Only use accessories specifically

recommended for this tool. Others may be

hazardous.

WARNING To reduce the risk of injury,

securely tighten the drive head screw before

use. Do not use tool with drive head screw

loose or missing.

Rotating the Drive Head

To rotate the drive head for a more comfortable grip:

1. Loosen the drive head screw.

2. Pull the drive head away from the tool and rotate

to one of the detent positions.

3. Press the drive head onto the tool and tighten

the drive head screw securely.

Starting, Stopping and Controlling Speed

1. To start the tool, grasp the tool by the insulated

gripping surface and pull the paddle switch. Keep

hands clear of the drive head.

WARNING To reduce the risk of explo-

sion, electric shock and property damage,

always check the work area for hidden pipes

and wires before drilling.

NOTE: An LED is turned on when the trigger is

pulled.

2. To vary the driving speed, increase or decrease

pressure on the paddle switch. The further the

paddle switch is pulled, the greater the speed.

3. To stop the tool, release the paddle switch.

Impacting Techniques

The longer a bolt, screw, or nut is impacted, the

tighter it will become. To help prevent damaging the

fasteners or workpieces, avoid excessive impact-

ing. Be particularly careful when impacting smaller

fasteners because they require less impacting to

reach optimum torque.

Practice with various fasteners, noting the length of

time required to reach the desired torque. Check the

tightness with a hand-torque wrench. If the fasten-

ers are too tight, reduce the impacting time. If they

are not tight enough, increase the impacting time.

Oil, dirt, rust or other matter on the threads or

under the head of the fastener affects the degree

of tightness.

The torque required to loosen a fastener averages

75% to 80% of the tightening torque, depending on

the condition of the contacting surfaces.

On light gasket jobs, run each fastener down to a

relatively light torque and use a hand torque wrench

for fi nal tightening.

OPERATION

WARNING Always remove battery

pack before changing or removing acces-

sories. Only use accessories specifically

recommended for this tool. Others may be

hazardous.

WARNING To reduce the risk of injury,

wear safety goggles or glasses with side

shields.

Using the Control Switch

The control switch may be set to three positions:

forward, reverse and lock. Always allow the motor

to come to a complete stop before using the control

switch to avoid damage to the tool.

For forward (clockwise) rotation, push in the control

switch from the right side of the tool ►. Check the

direction of rotation before use.

For reverse (counterclockwise) rotation, push in

the control switch from the left side of the tool ◄.

Check direction of rotation before use.

To lock the trigger, push the control switch to the

center position. The trigger will not work while the

control switch is in the center locked position. Always

lock the trigger or remove the battery pack before

performing maintenance, changing accessories,

storing the tool and any time the tool is not in use.

Selecting Speed

Allow the tool to come to a complete stop before

changing speeds.

1. For Low speed, push the speed selector to

display “1”.

2. For High speed, push the speed selector to

display “2”.
