Manual de uso

User Manual

French Door Countertop Oven

Manual de Instrucciones

Horno para mostrador

con puerta francesa

P.N. 180803

Visit us at www.oster.com

TSSTTVFDDG

MODEL/MODELO

For product questions contact: Jarden Consumer Service - USA: 1.800.334.0759 - Canada: 1.800.667.8623 - www.oster.com © 2013 Sunbeam Products,

Inc. doing business as Jarden Consumer Solutions. All rights reserved. Distributed by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca

Raton, Florida 33431. Jarden Consumer Solutions is a subsidiary of Jarden Coporation (NYSE : JAH) Printed in China.

Para preguntas sobre los productos llame: Jarden Consumer Service - EE.UU.: 1.800.334.0759 - Canadá: 1.800.667.8623 - www.oster.com © 2013 Sunbeam

Products, Inc. operando bajo el nombre de Jarden Consumer Solutions. Todos los derechos reservados. Distribuido por Sunbeam Products, Inc. operando bajo el nombre de Jarden Con-

sumer Solutions, Boca Raton, Florida 33431. Jarden Consumer Solutions es una subsidiaria de Jarden Coporation (NYSE : JAH) Impresso en China.

CBA-042415

For Products Purchased in the United States and Canada Only

To reduce the risk of electrical shock, this appliance has a polarized plug (one blade is wider than

the other). This plug fits a polarized outlet only one way; if the plug does not fit fully into the

outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to

modify the plug in any way.

SAVE THESE INSTRUCTIONS

W

elcome

C

ongratulations on your purchase of an OSTER

®

T

oaster Oven!

Features of Your Toaster Oven

(See Figure 1)

1. Removable Wire Racks/Broil Rack

2. Interior Light

3. Time Display

4

. Control Buttons

5. Two Rack Positions

6. Easy Clean Interior Walls

7. Glass Doors

8. Internal Removable Crumb Tray

9. Baking Pan

Control Buttons

1. Function Buttons –

(See Figure 2)

Bake – Select to bake.

Turbo – Select to bake with convection.

Broil – Select to Broil.

Toast – Select to toast bread, bagels, etc.

Pizza – Select to bake up to 16” pizza.

Defrost – Select to defrost foods.

Dehydrate – Select to dehydrate foods

Timer – Adjusts time, temperature

or toast shade.

Temp – Adjusts temperature.

Clock – Sets the Oven Clock.

Stop/Cancel – Stops heating or cancels function.

Start – Starts baking/cooking process.

NOTE – Oven is on when display icons are

illuminated and flashing.

Pressing Stop/Cancel button twice

turns off unit.

>

<

>

<

IMPORTANT SAFEGUARDS

SAVE AND READ THESE INSTRUCTIONS

When using electrical appliances, basic safety precautions should always be followed including

the following:

• READ ALL INSTRUCTIONS, PRODUCT LABELS AND WARNINGS

BEFORE USING THE TOASTER OVEN.

• Do not touch hot surfaces. Always use oven mitts when handling hot materials and allow

m

etal parts to cool before cleaning. Allow the unit to cool thoroughly before putting in or taking

off parts. Always use the oven handles when moving the unit.

• When the unit is not in use and before cleaning, unplug the toaster oven from the wall outlet.

Note: Make sure the oven is turned off before unplugging.

• To protect against risk of electrical shock, do not immerse the appliance in water or any other liquids.

• Close supervision is always necessary when this or any appliance is used near children. This

appliance is not for use by children.

• Do not operate this or any appliance with a frayed or damaged cord or plug or after the appliance

malfunctions or is dropped or has been damaged in any manner. Return appliance to the nearest

authorized service facility for examination, repair or adjustment.

• Do not use attachments not recommended by the manufacturer; they may cause fire,

electric shock or personal injury.

• Do not use outdoors or for commercial purposes.

• Do not use this appliance for other than its intended use.

• Do not let the cord dangle over the edge of a tabletop or countertop or touch hot surfaces.

• Do not place the appliance near a hot gas or electric burner or in a heated oven.

• Extreme caution should be used when using containers constructed of material other than metal or glass.

• A fire may occur if the toaster oven is covered or touching flammable materials, including cur-

t

ains, draperies, walls, etc., when in operation. Do not store any items on top of the appliance

when in operation.

• When using toaster oven, pull the unit out a minimum of 6 inches away from walls on all sides.

Remove cords from other products from behind toaster oven.

• Do not store any materials, other than manufacturer’s recommended accessories, in this unit when

not in use.

• Do not place any flammable materials in oven, such as paper, cardboard, plastic or any materials

that may catch fire or melt.

• Do not cover the crumb tray or any part of the oven with metal foil. This will cause overheating

o

f the appliance.

• Oversized foods or metal utensils must not be inserted in the appliance as they may create a fire

or risk of electrical shock.

• Do not clean with metal scouring pads. Pieces can break off the pad and touch electrical parts

involving a risk of electrical shock.

• Use extreme caution when removing tray or disposing of hot grease.

• To turn this appliance off, press Stop/Cancel button twice.

• To disconnect, press Stop/Cancel button twice to turn unit off, then remove plug from wall outlet.

• Extreme caution must be used when moving an appliance containing hot oil or other hot liquid.

THIS UNIT IS FOR HOUSEHOLD USE ONLY

SHORT POWER SUPPLY CORD INSTRUCTIONS

A short power-supply cord is provided to reduce the risk resulting from becoming entangled

in or tripping over a longer cord. An extension cord may be used if care is exercised in its use.

If an extension cord is used, the electrical rating of the cord must be at least as great as the

electrical rating of the appliance. The extension cord should be arranged so that it will not

d

rape over the countertop or tabletop where it can be pulled on by children or tripped over

unintentionally.

1

2

78

3

5

4

9

6

English-1 English-2

Figure 2

F

i

gure

1

Interior light turns on when timer is on. At the end of cooking cycle the light turns off automatically.

N

OTE – Both heating elements will cycle ON and OFF to maintain the desired temperature, and

may not glow.

When baking is completed, open door fully and remove food carefully.

T

o Use the Broil Function

Place the pan into the guide rails below the rack and place the food on top of the rack.

(See “Positioning Rack” Section)

Place broil rack in oven.

Push Broil button until the word “Broil” lights up on display.

Push Timer arrows to select the desired time.

P

ush the Start button.

Interior light turns on when timer is on. At the end of cooking cycle the light turns off automatically.

NOTE – The top heating element will cycle ON and OFF to maintain desired temperature, and

may not glow.

When broiling is completed, open door fully and remove food carefully.

WARNING: DO NOT LEAVE TOASTER OVEN UNATTENDED.

T

o Use the Toast Function

Place oven rack into the desired position before heating the oven. (See “Positioning Rack” Section)

NOTE – Different types of bread require different settings. Lighter breads and waffles

require a lighter setting. Darker breads, muffins, and English muffins require a darker setting.

Arrange food on the wire rack.

P

ush the Toast button. Use arrows to select Toast Shade.

Press the Start button.

W

hen toasting is completed, open door fully and remove food carefully.

To Use the Pizza Function

Place oven rack into the desired position before heating the oven. (See “Positioning Rack” Section)

Arrange pizza on the wire rack.

Push the Pizza button and 20:00 default time will appear. Use arrow keys to adjust

the time as desired. Push the Start button.

Interior light turns on when timer is on. At the end of cooking cycle the light turns off

automatically.

NOTE – The Pizza function temperature is set at 400°F and cannot be adjusted.

I

f different temperature is desired, cancel Pizza function and use Bake function.

F

or 2 Pizzas: Place the 2 pizzas on the wire racks. Cook the pizzas for about one-half the recommended

time, and then switch the rack positions to allow the pizzas to uniformly cook top and bottom.

Defrosting Function

When defrosting do not preheat oven. Temperature Control is already set to 150°F and cannot

be adjusted.

Push the defrost button. Use arrow keys to adjust time. Allow 15 to 20 minutes per

side for meats or fish to defrost. Always cook food promptly after thawing.

Push the Start button.

Interior light turns on when timer is on. At the end of cooking cycle the light turns off automatically.

Dehydrate Function

W

hen dehydrating do not preheat oven. Temperature Control is already set to 150°F and can-

not be adjusted. Push the dehydrate button. Use arrow keys to adjust time. Dehydrate time can

be adjusted up to 6hrs. Push the start button to start dehydrating.

For more information on dehydrating food, please visit www.oster.com

Preparing To Use Your Toaster Oven for the First Time

I

f you are using your toaster oven for the first time, please be sure to:

Remove any stickers from the surface of the oven.

Open oven door and remove all printed documents and paper from inside the toaster oven.

Clean the rack, tray, and pan with hot water, a small amount of dishwashing liquid

and a non-abrasive sponge or cleaning pad.

DO NOT IMMERSE THE BODY OF THE UNIT IN WATER.

Dry the unit thoroughly before using.

Select a location for the toaster oven. The location should be in an open area on a flat

counter where the plug will reach an outlet.

P

lug the toaster oven into a 120 Volt AC electrical outlet.

U

sing Your Toaster Oven

S

etting the Clock

Push the Clock button. The clock will flash.

Use the arrow keys to set the hour. Push the Clock button again.

Use the arrow keys to set the minutes.

Push the Clock button once more or the start button and the time will be set.

P

reheating the Oven

Place oven rack into the desired position before heating the oven. (See “Positioning Rack” Section)

This oven has a preheat feature in Turbo Convection Bake and Bake mode. Select the mode, Turbo

Convection or Bake. Use the temp arrow keys to select the desired temperature. Use the timer

arrow keys to select the desired time.

P

ush the Start button. Display will show PrE until temperature is reached, the oven will beep and

d

isplay remaining time. At this time you may adjust the selected time. The temperature may also be

a

djusted. If you increase the temperature the unit will go back to preheat mode until it reaches the

n

ew set temperature.

To bypass the preheat function press the start button a second time.

To Use the Bake Function

Place oven rack into the desired position before heating the oven. (See “Positioning Rack” Section)

Arrange food on the wire rack or in the baking pan.

P

ush the Bake button. Use the Temperature arrow keys to select desired temperature.

Use the Time arrow keys to select desired time.

P

ush the Start button.

T

he oven will go into the preheat mode. To bypass the preheat mode press the start button a sec-

ond time.

Interior light turns on when timer is on. At the end of cooking cycle the light turns off automatically.

NOTE – Upper and lower heating elements will cycle ON and OFF to maintain the desired

temperature, and may not glow.

When baking is completed, open door fully and remove food carefully.

To Use the Convection Fan Bake Function

When you select the Convection Bake the convection fan will turn on and circulate air

allowing the food to cook evenly and faster.

Place oven rack into the desired position before heating the oven. (See “Positioning Rack” Section)

Arrange food on the wire rack or in the baking pan.

Push the Convection Bake button until “Convection Bake” lights up on display. Use the Temp

arrow keys to select desired temperature.

Push Timer arrow keys to select desired time.

Push the Start button.

The oven will go into the preheat mode. To bypass the preheat mode press the start button a sec-

ond time.

English-3 English-4

H

E

L

PF

U

L

T

I

PS

/

T

R

O

U

B

L

E

SH

O

OT

I

N

G

PROBLEM

• Overcooked / Un-

dercooked Foods

• Burnt Smell

• Oven does not

turn ON

• Only one heating

element is heating

up

• Heating elements

do not stay ON

• Cannot change

function button

SOLUTION

• You may have to adjust the time and tem-

perature to desired taste.

• Because your toaster oven is smaller than

your regular oven, it will heat up faster and

generally cook in shorter periods of time.

• Refer to “Positioning Rack” Section,

Page English-4. Rack may need to be ad-

justed to accommodate food type.

• Refer to “Cleaning Your Toaster Oven”

Section, Page English-5.

• Plug the toaster oven into a 120-volt AC

electrical outlet.

• Set timer knob and temperature knob to

desired setting. Both must be turned on

to operate the toaster oven.

• Press Start.

• When toasting, make sure the oven is

not

set to broil setting.

• Be certain that function is as desired.

• Heating elements may not glow.

• Press cancel.

POTENTIAL CAUSE

• Incorrect temperature or

time setting

• Rack placement

• Food build-up inside

oven, on heating elements

or in crumb tray.

• Unit is unplugged

• Did not press Start.

• Function setting selec-

tion determines which

heating element will op-

erate.

• Heating elements will

cycle ON and OFF to

maintain proper heat.

• Need to cancel function.

1 Year Satisfaction Guarantee

Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam

Corporation (Canada) Limited doing business as Jarden Consumer Solutions (collectively “JCS”)

warrants that for a period of fone year from the date of purchase, this product will be free from

defects in material and workmanship. JCS, at its option, will repair or replace this product or

any component of the product found to be defective during the guarantee period. Replacement

will be made with a new or remanufactured product or component. If the product is no longer

available,

replacement may be made with a similar product of equal or greater value. This is your exclusive

guarantee. Do NOT attempt to repair or adjust any electrical or mechanical functions on this

product. Doing so will void this guarantee. This guarantee is valid for the original retail pur-

chaser from the date of initial retail purchase and is not transferable. Keep the original sales re-

ceipt. Proof of purchase is required to obtain satisfaction guarantee performance. JCS dealers,

service centers, or

retail stores selling JCS products do not have the right to alter, modify or any way change the

terms and conditions of this guarantee.

This guarantee does not cover damage resulting from any of the following: negligent use or mis-

use of the product, use on improper voltage or current, use contrary to the operating instruc-

tions, disassembly, repair or alteration by anyone other than JCS or an authorized JCS service

center. Further, the guarantee does not cover: Acts of God, such as fire, flood, hurricanes and tor-

nadoes.

What are the limits on JCS’s Liability?

JCS shall not be liable for any incidental or consequential damages caused by the breach of any

express, implied or statutory guarantee or condition. Except to the extent prohibited by appli-

cable law, any implied guarantee or condition of merchantability or fitness for a particular pur-

pose is

limited in duration to the duration of the above guarantee. JCS disclaims all other guarantees,

conditions or representations, express, implied, statutory or otherwise. JCS shall not be liable

for any damages of any kind resulting from the purchase, use or misuse of, or inability to use

the

product including incidental, special, consequential or similar damages or loss of profits, or for

any breach of contract, fundamental or otherwise, or for any claim brought against purchaser

by any other party.

Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or

consequential damages or limitations on how long an implied guarantee lasts, so the above limi-

tations or exclusion may not apply to you. This guarantee gives you specific legal rights, and

you may also have other rights that vary from province to province, state to state or jurisdiction

to jurisdiction.

How to Obtain Satisfaction Guarantee Service

In the U.S.A.

If you have any question regarding this guarantee or would like to obtain guarantee service,

please call 1-800-334-0759 and a convenient service center address will be provided to you.

In Canada

If you have any question regarding this guarantee or would like to obtain guarantee service,

please call 1-800-667-8623 and a convenient service center address will be provided to you.

In the U.S.A., this guarantee is offered by Sunbeam Products, Inc. doing business as Jarden

Consumer Solutions located in Boca Raton, Florida 33431. In Canada, this guarantee is offered

by Sunbeam Corporation (Canada) Limited, located at 20 B Hereford Street, Brampton, On-

tario L6Y 0M1. If you have any other problem or claim in connection with this product, please

write to the Consumer Service Department.

PLEASE DO NOT RETURN THIS PRODUCT TO ANY OF

THESE ADDRESSES OR TO THE PLACE OF PURCHASE.

English-5 English-6

Positioning Rack

To accommodate a wide variety of foods, the

oven has 2 racks and two (2) rack positions.

(See Figure 3)

Positioning of the rack will depend on the size

of the food and desired browning.

Before removing the rack, allow the unit to cool.

PLEASE NOTE – For best toast and pizza results,

position the rack in the top rack position.

Positioning Pan

• To accommodate a wide variety of foods the oven has two pan positions. The pan can

be placed on top of the rack or inserted into the guide rails below the rack. (See Figure Below)

• Before removing the pan allow the unit to cool.

• Positioning of the oven pan will depend on the desired cooking method. For baking, place

the pan on top of one of the racks. For grilling or broiling, insert the pan into the guide rails

below the rack and place the food on top of the rack.

PLEASE NOTE

–

Do not to use the broil pan under the rack in the lower position.

Cleaning Your Toaster Oven

Before cleaning your OSTER

®

Toaster Oven, press Stop/Cancel button twice, unplug it and

allow it to cool. To clean, wipe with damp cloth.

DO NOT IMMERSE IN WATER!

Make

sure to use only mild, soapy water. Abrasive cleaners, scrubbing brushes and chemical cleaners

will damage the

coating on this unit. Empty crumb tray frequently to avoid accumulation

of crumbs.

Toaster oven racks are dishwasher safe (top of dishwasher only).

Storing Your Toaster Oven

Allow the appliance to cool completely before storing. If storing the toaster oven for long periods

of time make certain that the toaster oven is clean and free of food particles. Store the toaster oven

in a dry location such as on a table or countertop or cupboard shelf. Other than the recommended

cleaning, no further user maintenance should be necessary.

Figure 3

For Baking

For Grilling

or Broiling

Puntuación

Más sobre este manual

Entendemos que es bueno tener un manual en papel para tus Oster TSSTTVFDDG Horno. Siempre puedes descargar el manual desde nuestro sitio web e imprimirlo tú mismo. Si deseas tener un manual original te recomendamos contactar con Oster. Es posible que puedan proporcionar un manual original. ¿Estás buscando el manual de tu Oster TSSTTVFDDG Horno en otro idioma? Elija su idioma preferido en nuestra página de inicio y busque el número de modelo para ver si lo tenemos disponible.

Especificaciones

Todos los manuales para Oster Hornos
Más manuales de Hornos

Preguntas frecuentes sobre Oster TSSTTVFDDG Horno

Nuestro equipo de atención al cliente busca información útil sobre los productos y responde a las preguntas frecuentes. Si encuentra inexactitudes en las preguntas frecuentes, indíquenoslo usando nuestro formulario de contacto.

Productos relacionados

Manual de uso

Oster TSSTTVLS25 Horno

Manual de uso

Oster TSSTTV7030 Horno

Manual de uso

Oster TSSTTVLS25NS Horno

Manual de uso

Oster TSSTTVFDXL2 Horno

Manual de uso

Oster TSSTTVLS35NS Horno

Manual de uso

Oster TSSTTV7118 Horno

Manual de uso

Oster TSSTTVDAF1 Horno

Manual de uso

Oster TSSTTVCG05-1MX Horno

Categorias relacionadas
