4

• After preparing the ends of the speaker cables

for the right and left speakers, connect them

as shown in the illustration.

• The red cable is for the (+) polarity and the

black cable is for the (-) polarity. Do not

connect the cables to the wrong polarities.

• If fixing the plasma television to the wall-

hanging bracket, first connect the speaker

cables to the plasma television.

6. Connect the speaker

cables.

Preparing the ends of the

speaker cables

Remove while

twisting

1. Press down on the lever.

2. Insert the cable.

3.

Release the lever.

1. Push down the lever.

3. Return the lever to its

normal position.

2. Insert

the cable.

Installation

Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households)

This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be

mixed with general household waste.

For proper treatment, recovery and recycling, please take these products to designated collection points, where

they will be accepted on a free of charge basis. Alternatively, in some countries you may be able to return your

products to your local retailer upon the purchase of an equivalent new product.

Disposing of this product correctly will help to save valuable resources and prevent any potential negative effects

on human health and the environment which could otherwise arise from inappropriate waste handling. Please

contact your local authority for further details of your nearest designated collection point.

Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further

information.

Information on Disposal in other Countries outside the European Union

This symbol is only valid in the European Union.

If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.

• To attach to each speaker, use the bracket

mounting screws. To attach to the plasma TV,

use the fixing screws.

5. Attach C brackets

Bracket mounting screws

Fix screws

Mounting C bracket

Rear of speaker

Rear of Plasma Television

English

Black

Red

Black

Red

1. Press down on the lever.

2. Insert the cable.

3.

Release the lever.

TY̲SP65PV500̲690̲1̲2095.indb4TY̲SP65PV500̲690̲1̲2095.indb4 2005/09/1215:29:302005/09/1215:29:30
