Manual de uso Panasonic WH-MDC16G6E5 Bomba de calor

Manual de uso

8

How to use

User

Enjoy quiet operation

Press .

• This operation reduces the noise of mono bloc unit.

The operation may cause heating/

*

1

cooling ability to

decrease.

User

System status check mode

1

Press

.

(The display shows STATUS.)

2

Press

or to check the selected mode.

• Dry concrete (does not show during normal

operation)

• The Water Inlet Temperature

• Tank Temperature

• Compressor Running Frequency

• Error History

• Heat mode total power consumption (Up to 999 days)

• *

1

Cool mode total power consumption (Up to 999 days)

• Tank mode total power consumption (Up to 999 days)

• Press to exit the STATUS mode.

■ Note:

• Once the STATUS mode is entered, the display

shows STATUS.

• The STATUS mode cannot be activated when the

display shows SETTING.

• The total power consumption is an estimated value

based on AC 230 V and may differ from value

measured by precise equipment.

■ Note: In normal operation, the , and buttons are not in use.

User

Turn on or off the system

Press .

When the system is ON, the operation LED is lit and the

actual water outlet temperature and outdoor ambient

temperature are shown on the display.

User

Select operation mode

Press to select operation mode.

AUTO • Depending on the preset outdoor

temperature, the system selects HEAT or

*

1

COOL operation mode.

AUTO

+ TANK

• Depending on the preset outdoor

temperature, the system selects HEAT +

TANK or *

1

COOL + TANK operation mode.

HEAT • The panel/floor HEAT operation is either

turned ON or OFF.

• The mono bloc unit provides heat to the

system.

HEAT

+ TANK

• The mono bloc unit provides heat to the

sanitary water tank and the system.

• This mode can be selected only when the

sanitary water tank is installed.

TANK • The sanitary water tank is either turned

ON or OFF.

• The mono bloc unit provides heat to the

sanitary water tank.

COOL

+ TANK

• The mono bloc unit provides cooling to

the system.

• The system controls the booster heater in

the sanitary water tank.

COOL

• The panel is either turned ON or OFF.

• The mono bloc unit provides cooling to

the system.

User

Initiate the backup heater

Press

.

• The backup heater provides extra heat at low outdoor

temperature. The backup heater is possible only in the

heat mode.

• Once the backup heater is set, it is automatically

operated when conditions are fulfilled.

• To disable the backup heater, press

again.

The system is turned off by an external switch.

*

1,

*

2

*

1,

*

2
