Manual de uso PetSafe Staywell 340 Trampilla para gatos

Manual de uso

3

DEITNL

ES

FR

EN

Accessories available online

Optional: Add tunnel extensions (sold separately) to extend the tunnels through

your wall.

9. Attach the two (2) included metal clips into the rectangular recesses on the

remaining adaptor plate with the flat side of the clip flush with the outer face of

the plate.

10. Set the exterior frame on top of the remaining adaptor plate and attach using

the two (2) 16 mm flat head screws (included).

11. From the exterior of the home, place the exterior frame with installation adaptor

attached onto the tunnel of the interior frame and mark the four (4) screw holes

on the installation adaptor plate. Remove the exterior frame.

12. Using the proper hardware for your wall construction (not included), drill

the appropriate size holes for your hardware, and attach the exterior frame

assembly to the wall.

13. Insert the eight (8) blanking plugs into the exterior and interior installation

adaptor plates and the two (2) blanking plugs into the exterior frame.

4-Way Manual Lock

The 4-Way Manual lock allows you to control your cat’s access in and out of your

home in either direction. Until your pet is thoroughly familiar with using the cat flap,

it is a good idea to only use the 4-Way Manual lock in the In or Out position only

(Fig. L).

Fig. L

Additional Information

For extended information on your PetSafe

®

Manual-Locking Cat Flap including glass

and wall installation, helpful training tips, and available accessories, please visit

www.petsafe.com.

Fully lockedIn or Out Out onlyIn only

Installation

–

Glass Doors or Windows

A mounting adaptor and wall extension tunnels are available to complete

the installation of the cat flap into glass doors or windows. Please visit

www.petsafe.com to learn more about glass installation and to purchase

these accessories.

Working with glass is a skilled job and should be carried

out by a professional glazier. It is not possible to cut holes in toughened glass or

double glazed units except at the time of manufacture. Please consult a glazier.

Installation – Walls

Installation of the cat flap into a wall will require an Installation Adaptor (sold

separately) to ensure performance. Extension Tunnels may also need to be

purchased to ensure that the flap extends completely through the wall. Once this

has been purchased, follow the instructions below.

Important: Check for electrical and plumbing that could be in the wall where you

wish to place the pet door.

1. Attach the supplied Cutting Template to the inside of your wall in the correct

position ensuring that it is the right way up and level (Fig. C).

2. Drill four (4) corner holes with a 12 mm diameter drill bit as marked on the

Cutting Template through the wall. Ensure that the drill remains straight

and level.

3. Using the appropriate tool for your home construction, such as a jig saw, cut

along the appropriate line as indicated on the Cutting Template. (Fig. E).

4. From the exterior of the home, finish cutting the hole through the wall using the

four corner holes drilled through the wall as a guide.

5. Clean the area of any dust, dirt or debris.

6. Slide one installation adaptor plate over the tunnel on the interior frame

and attach it to the back of the frame using the two (2) pan headed

screws (included).

7. From the interior of the home, position the interior assembly on the wall and

mark the four (4) screw holes on the installation adaptor plate attached to the

cat flap. Remove the assembly.

8. Using the proper hardware for your wall construction (not included), drill the

appropriate size holes for your hardware and attach the interior frame with

installation adaptor to the wall.
