3

En

English

How to install

Choosing where to place the speaker systems

• Sounds played through speaker systems are easily affected in

subtle ways by the conditions in the listening space.

• For best sound, choose a solid floor upon which to place the

speakers, and position the speakers as shown below. The level

of low sounds can be adjusted by moving the speakers closer

to or further from the wall. Adjust the speakers so that they are

equidistant from their respective side walls to assure balanced

sound.

• Place the left and right speakers equal distances from your

listening position for good stereo sound. Use speaker cords of

the same length for each speaker.

• So far as possible, place the front left and front right speakers

on the same plane as the TV screen.

• To achieve optimum surround sound, you should place the TV

between the left and right speakers, with the speakers

pointing at a 50 to 60 degree angle toward the listening

position.

• If the room has a lot of reverberation, we recommend hanging

heavy fabric on the walls, and/or putting a carpet on the floor

to damp the sound. For best results, cover walls completely.

• Pioneer assumes no liability whatsoever for damages

resulting from assembly, improper mounting, insufficient

reinforcement, misuse of the product, acts of nature, etc.

• Since these speaker systems are quite heavy, do not install

them in unstable locations; a falling speaker could result in

damage or dangerous personal injury.

• When installing these speaker systems, be sure to provide

positive measures against tipping or falling, since accidental

falls due to earthquakes or other causes could result in injury.

Applying non skid pads

The use of non skid pads is recommended depending on the

installation location. Apply the pads to the four corners of the side

of the speaker which will be on the bottom. Note that depending

on the location, the pads may not provide fully sufficient traction

to prevent slipping, so care should be taken not to install the

speakers in conditions where they may be prone to slide.

Mounting the Fall-Prevention Fastener

• Using the included screw, tightly secure the metal catch to the

backside of the speaker.

• Pass a commercially-available reinforced string through the

metal catch to securely support the speaker to the wall. Be

sure that the wall to which you fasten the speaker is strong

enough to support the weight of the speaker. After fastening

the speaker, make sure that it does not fall over.

• The speaker can incur damage in the event of a fall.

• Do not attach the metal catch directly to the wall. It should

only be used in conjunction with reinforced string to prevent

the speaker from falling.

• Pass two reinforced strings through the metal catch, and

fasten the speaker to the wall as shown above.

50 to 60

20 cm

(7

7

/

8

in.)

50 cm

(19

11

/

16

in.)

Non skid pads

Metal catch

Reinforced strings

Backside of speaker

S-31_En.fm 3 ページ ２００９年７月２９日　水曜日　午後３時４５分
