insulation. Double insulated tools do not need to be

grounded.

WARNING

The double insulated system is intended to protect

the user from shock resulting from a break in the tools

internal wiring. Observe all normal safety precautions to

avoid electrical shock.

IMPORTANT

Servicing of a tool with double insulation requires

extreme care and knowledge of the system and should

be performed only by a quali ed service technician. For

service, we suggest you return the tool to your nearest

authorized service center for repair.

WARNING

Do not attempt to modify this tool or create accessories

not recommended for use with this tool. Any such

alteration or modi cation is misuse and could result

in a hazardous condition leading to possible serious

personal injury.

ADJUSTMENTS

WARNING

Your router should never be connected to power supply

when you are assembling parts, making adjustments,

installing or removing cutters, or when not in use.

Disconnecting the tool will prevent accidental starting

that could cause serious injury.

CUTTER INSTALLATION

See Figure 3 - 4.

1. Unplug the tool.

WARNING

Failure to unplug the tool could result in accidental

starting causing possible serious injury.

CAUTION

To prevent damage to the spindle or spindle lock,

always allow motor to come to a complete stop before

engaging the spindle lock.

2. Remove chip shield from router base.

3. Depress spindle lock.

4. Lay router down on workbench in order to gain easy

access to collet nut.

5. Place the spanner provided through front of router

base onto collet nut and turn counterclockwise to

loosen.

WARNING

If you are changing a cutter immediately after use, be

careful not to touch the cutter or collet with your hands

or  ngers. They will get burned because of the heat

buildup from cutting. Always use the wrench provided.

6. Install cutter once collet nut is loose. If changing

cutters, cutter will easily slip from collet after loosening

collet nut.

7. Insert shank of cutter until shank bottoms out, then pull

it out 1/16 in (1.6 mm) to allow for expansion when the

bit gets hot.

8. Tighten the collet nut.

9. Release spindle lock.

10. Replace chip shield.

WARNING

If the collet nut is not securely tightened, the cutter may

detach during use causing serious personal injury.

WARNING

Do not use cutters with undersized shanks. Undersized

shanks will not tighten properly and could be thrown

from the tool causing injury.

WARNING

Do not use cutters that are larger in diameter than the

opening in router base. Use of such cutters will come

in contact with the router base and damage both the

cutter and router base. This situation could also cause

possible loss of control or create other hazardous

conditions that could cause possible serious personal

injury.

DEPTH OF CUT

When routing a groove that is too deep to safely cut in one

pass, it is best to make the cut in several passes.

Proper depth of cut depends on several factors such as

horsepower of the router motor, type of cutter being used

and the type of wood being routed. A lightweight, low

horsepower router is designed for making shallow cuts.

A router with high horsepower rating can safely cut deeper.
