Manual de uso Saivod LST 126 Lavadora

Manual de uso

-4- EN

Water Inlet Filters

There is a filter at each flat end where water inlet hose is con-

nected to tap and at each of water inlet valve placed behind the

machine. These filters blocks entrance of foreign objects and dirts

to the machine. Filters must be cleaned regularly to avoid clog-

ging. For doing this, turn off tap water. Pull out water inlet hoses.

Clean the top of the water inlet valve filter with a brush. If filters are

extremelycloggedyoucanpullitoutwithapincer.Youcantake

out the flat side of water inlet hoses with its seal and clean with

tap water.

Hose

There is risk of freezing in cold region, if your machine is placed in

a cold place remaining water in hoses must be drained with pump

filter when machine is not used. Water inlet hoses can be drained

by taking it out from tap.

Cleaning Pump Filter

There is filter system maintaning long lifetime of pump by blocking

foreign objects like button, cloth fiber enter to the pump during

drain of washing water. It is useful to clean the filter when it is

soiled. In order to do this:

1. Turn off the appliance, unplug the power cable and close the

tap. Wait for the hot soapy water to cool enough. Otherwise,

there is a risk of scalding.

2. Open the service cover by pressing the button. In order to pre-

vent the little amount of water that is inside pump spilling over the

floor, put a container in front of the filter cover. Take out the filter

by turning anticlockwise.

3. To loosen the foreign substance filter, turn it half turn (anticlock-

wise) and take the remaining water with a cloth. When there is no

water, turn the foreign substance filter until it is totally released

and take it out.

4. Clean the foreign substance filter and pump opening.

5. Reinstall the foreign substance filter and turn it tightly (clock-

wise).

6. Close the service cover.

1. Removing the transportation safety bolts

Beforethewashingmachineisoperated,thetransitbarsmustbe

removed! In order to do this:

1. Loosen “C” bolts by rotating them counter clockwise with a

suitable spanner

2. Remove transportation safety bolts by turning.

3. Place “P” plastic covers onto the openings of transportation

locks by rotating in direction of arrow and pushing.

Attention please! Keep the transit safety bolts for using when ma-

chine is to be transported again. Always transport your machine

with transportation locks.

2. Leveling the feet

In order to operate your machine without noise

and vibration it must be properly on balance.

Four feet of your machine can be adjusted.

First loosen the plastic counter bolt. Tighten

the counter bolt after adjusting the feet for

leveling your machine.

3. Water Connections

a) Water Inlet Hose: Yourmachineisconnect-

ed to water supply by special hoses supplied by

the machine.

There are plastic seals on hose or plastic bag for

eliminating any leakage in connections points.

These seals must be used on each side of the

connection. Seals on machine side must be

connected filter cannal.

After connecting the hose, check all connections for leaks In order

to eliminate any risk due to water leakage keep the taps off when

machine is not used.

Yourmachinewilloperateefficientlyifthewaterfromtapismini-

mum 1 and maximum 10 bars. Practically 1 bar means 8 liters of

water in one minute when tap is fully on.

Connect hose to the machine. Tighten bolts with hand power, do

not use spanner.

Do not connect single inlet machine to hot water. If machine is

connectedwithYparttoadoubleinletandover40˚Cforsingle

inlet machines, machine may switch to protection mode.

b) Water drain hose: Water drain hose could be placed either at

the side of the bath tub, or directly to the drain. The hose should

not be bent. Water drain hose should be secured with the holder

so that it would not fall down on the ground.

The hose should be placed between 40 and 100 cm. from the

ground. Water drain hose could be placed directly to the drain

water inlet.

4. Electrical connection

Connect the power cord to the appropirate electrical system

which is being supported by the maximum voltage and cur-

rent rating indicated on the rating plate placed on the washing

machine.

Look! Page 1, Steps before operating Fullautomatic Washing Ma-

chine and safety precautions. Make sure that you have grounded

power outlet.

You turned the machine on, but the leds are off on the

panel.

Check the grounding on the power cable or a blown fuse. Check

the front door proper closure.

Machine does not take water.

Check the front door for proper closure. Either taps are closed or

water intake filters are clogged.

Taken water is directly discharged.

Check if the discharge hose placed as described in the users

manual or not.

Water coming from beneath the machine.

Check the water intake and drain hoses. Tighten the connections.

The washers of the hoses may be worn out. If non of the both,

the pump filter is not closed properly.

Foam coming out of the detergent dispenser.

Check whether your detergent is suitable for automatic machines.

Next time use less detergent.

Pump does not drain water.

Clean the pump filter. Check whether the drain hose is bent or

not. If there is need to clean the pump filter, refer to the pump

filter cleaning section of the manual.

Installation

6

Before calling service

7
