Manual de uso SilverStone KL06 Caja PC

Manual de uso

Product Overview

Specification

Material

Model

Motherboard

Drive Bay

Cooling System

Expansion Slot

Front I/O Port

Power Supply

Expansion Card

Limitation of CPU cooler

Limitation of PSU

Dimension

Plastic front panel with steel mesh, steel body

SST-KL06B (black)

SST-KL06B-W (black + window)

Micro ATX, Mini-DTX, Mini-ITX

Exposed

Internal

Front

Rear

4

USB 3.0 x 2, Audio x 1, MIC x 1

Optional PS2 (ATX)

Compatible up to 14.5" (368mm) long, width restriction-6.69" (169mm)

165mm

180mm*

211mm (W) x 375mm (H) x 405mm (D)

* Power supply and optical drive’s combined allowable total length is 404mm including connectors, which may take up additional 20mm. We suggest maximum length for PSU at 180mm (ST1500-GS).

5.25" x 2

3.5" x 1 , 2.5” x 8

120mm intake fan x 2, 1200rpm, 20dBA

120mm fan slot x 1

Kublai Series KL06

Introduction

1

Being the first Micro-ATX chassis in the Kublai series, a line of cases famed for

layout efficiency with classic styling, the KL06 fills the role perfectly. Equipped with

dual 120mm quiet fans for cooling multiple drives and high-end components, it retains

SilverStone’s signature positive pressure design for effective dust prevention.

With an internal body structure based on the benchmark Temjin TJ08-E and

Precision PS07, the KL06 was designed to meet current and future demands with

unique features. These include accommodation for 14.5 inch (368mm) long

graphics cards and simultaneous front/rear all-in-one liquid cooler support

without drive cage removal. For more convenient access during assembly and for

advanced enthusiasts, the KL06 has removable drive cage, motherboard tray, and

top panel plus provision for custom liquid cooling pump. Maintenance is remarkably

easy thanks to externally accessible filters on the front panel and independent

power supply vent. Finally for storage expansion, the KL06 has a forward-thinking

layout that focuses on 2.5” drives with a total of eight bays that include tool-less

cage and a special bracket from RAVEN RV02 for showing off installed SSD on

its side.

For those looking for an expertly designed Micro-ATX case built for the future and

designed to beautifully complement any computing environment, the SilverStone

Kublai KL06 is as clever of a choice as it gets.

Special Features

Up to eight 2.5” drives and one 3.5” drive capacity

Innovative drive cage design enables support for front and rear AIO liquid coolers

Modular design with removable drive cage, motherboard tray, and top panel

Includes two quiet 120mm fans

Convenient externally removable fan filters

Independent power supply intake vents
