Manual de uso Steren AUD-7600 Auriculares

Manual de uso

AUD-7600

V0.00118m

Instruction manual

Bluetooth headphones

with MP3 player

Change mode/

Equalizator

Left side

Right side

01 800 500 9000

WARRANTY

This Steren product is warranted under normal usage against defects in workmanship and materials to the original purchaser for one year and three months on the battery from the date of purchase.

CONDITIONS

1. This warranty card with all the required information, invoice, product box or package, and product, must be presented when warranty service is required.

2. If the product is in the warranty time, the company will repair it free of charge.

3. The repairing time will not exceed 30 natural days, from the day the claim was received.

4. Steren sell parts, components, consumables and accessories to customer, as well as warranty service, at any of the addresses mentioned later.

THIS WARRANTY IS VOID IN THE NEXT CASES:

If the product has been damaged by an accident, acts of God, mishandling, leaky batteries,

failure to follow enclosed instructions, improper repair by unauthorized personnel, improper safe keeping, among others.

a) The consumer can also claim the warranty service in the purchase establishment.

b) If you lose the warranty card, we can reissue it, if you show the invoice or purchase ticket.

RETAILER INFORMATION

Name of the retailer ________________________________________________________________________________________________________________________________________________________________________________________

Address _________________________________________________________________________________________________________________________________________________________________________________________________

Product _________________________________________________________________________________________________________________________________________________________________________________________________

Product: Bluetooth headphones with MP3 player

Part number: AUD-7600

Brand: Steren

CHARGE BATTERY MUSIC PLAYBACK

HANDS FREE

OPTION 1

Use a micro USB cable with adapter (not included)

OPTION 2

Use a micro USB cable

to connect them to a computer

In case that the battery is finished, you can insert a 3.5 mm cable into the auxiliary connector to use the wired headphones.

IMPORTANT

PARTS

CAUTIONS

Read these manual to avoid any damage.

The instructions of these manual are for reference about the product.

There may be differences due to update.

Please check our web site www.steren.com to obtain the latest version of the

instruction manual.

Press and hold to change play mode ( Bluetooth / micro SD).

Press once to play or pause playback.

Press once to change to the next track.

Press once o change to the previous track.

Press and hold to decrease volume.

Press and hold to increase volume.

Input: 5 V - - - 500 mA (x USB)

Battery capacity: 3.7 V - - - 200 mAh

Headphone:

Frequency response: 20 Hz - 20 kHz

Speaker sensitivity: 110 dB +/- 3 dB

Impedance: 32 Ohms

Driver unit: 40 mm

Power output: 40 mW

Microphone:

Frequency response: 50 Hz – 16 kHz

Sensitivity: -56 +/- 3dB

Children should be supervised to ensure they do not use the device as a toy.

Adjust the volume to a level that allows you to hear external sounds.

Avoid using headphones if you drive a car or perform any activity that requires your attention.

Before using, charge the battery 100%.

Any unauthorized repair may cause malfunction and will void the warranty.

This device is not intended for use by persons (including children), whose physical, sensory or mental abilities are different or reduced, or lack experience or knowledge.

The operation of this device is subject to the following two conditions: (1) it is possible that this device may not cause harmful interference and (2) this device must accept any interference, including interference that may cause undesired operation.

This functions may vary according the model and Bluetooth version of your mobile device.

Press once to answer or end a call.

Press for 2 secondss to reject a call.

Press twice to call the last dialed number.

V

V

FRONTAL PART

REAR PART

Previous track /

Volume down

Play / Pause

Answer / Hang up

Next track /

Volume up

ON / OFF

Auxiliary input

Microphone

Operating LED

indicator

Micro USB power input

Micro SD memory input

BLUETOOTH PAIRING

2

Turn on the headphones with the power button (ON). You will hear the following

message: “Bluetooth mode”. The LED indicator will flash in blue and green

3

Activate the Bluetooth function in your device. Search and select:

“STEREN AUD-7600”. If the pairing was successful, the LED indicator will remain fixed,

and will be heard a tone.

1

Put on the headphones and adjust the headband.

SPECIFICATIONS

M/EQ

V

V

Before using for the first time, charge the headphones for four hours at a time.

During charging, the LED indicator will remain lit in red
