Manual de uso Weller WEP 70 Pistola de soldadura

Manual de uso

14

The soldering tool must be operated only in perfect

technical working order.Safetydevicesmustnotbe

deactivated.

Faults and defects must be repaired immediately.

Beforeusingtheunit/tool,safetydevicesmustbecarefully

checkedtomakesurethattheyarefunctioningproperlyand

in the manner intended. Check that moving parts are func-

tioningproperlyandarenotsticking,andwhetherpartsare

damaged.Allpartsmustbecorrectlyttedandmustsatisfy

alltherequirementsnecessarytoguaranteetroublefree

operation of the unit.

Use the correct tool.

Useonlyaccessoriesorauxiliaryde-

vices which are included in the list of accessories or appro-

vedforusebythemanufacturer.UseWELLERaccessories

orauxiliarydevicesonoriginalWELLERequipmentonly.The

useofothertoolsandotheraccessoriescancauseinjury.

Secure the tool.Useclampingxturestoholdthe

workpiece.

Use a solder fume extraction unit. If appliances for

connecting solder fume extraction units are available, ensure

thattheyareconnectedandusedproperly.

Soldering

Please be sure to read and follow the operating

instructions for your Weller Supply Unit.

Use only original Weller soldering

tips!

Handling the soldering tips

• Coat the selective and tinnable soldering tip with solder

whenheatingitupforthersttime.Thisremovesoxide

coatings which have formed during storage and impurities

from the soldering tip.

• Make sure that the soldering tip is well coated with solder

during breaks between soldering work and prior to storage

of the device.

• Donotuseaggressiveuxingagents.

• Alwaysmakesurethatthesolderingtipsarettedproperly.

• Select as low a working temperature as possible.

• Select the largest possible soldering tip shape for the

application. Rule of thumb: the soldering tip should be

roughlyaslargeasthesolderingpad.

• Coat the soldering tip well with solder to ensure that there

isefcientheattransferbetweenthesolderingtipandthe

soldering area.

• Prior to extended breaks between soldering work, switch

offthesolderingsystemorusetheWellerfunctionto

reduce the temperature when the soldering equipment is

not in use.

• Coatthetipwithsolderpriortostorageifyoudonotintend

to use the soldering iron for an extended period of time.

• Applysolderdirectlytothesolderingarea,nottothe

soldering tip.

• Donotapplymechanicalforcetothesolderingtip.

Specied Conditions Of Use

SupplyunitforWELLERsolderingtools.Usethesoldering

stationonlyforthepurposeofsoldering,asspeciedinthe

Operating Instructions.

Usethesolderingironexclusivelyforthepurposeindicated

in the Operating Instructions of soldering and desoldering

undertheconditionsspeciedhere.

ThesolderingironmayonlyusedincombinationwithWeller

SupplyUnits.

Thisdevicemayonlybeusedatroomtemperatureand

indoors. Protect against moisture and direct sunlight.

Care and maintenance

WARNING

Before doing any work on the machine, pull

the plug out of the socket. Leave the unit to

cool down.

Check all connected cables and hoses on a regular basis. If

powertoolsaredamaged,theymustbeimmediately

removed from use.

Onlyreplacethesolderingtipswhentheyarecold.

Thesolderingtoolmustbeleftswitchedoffinthesafetyrest

for at least 3 minutes until the soldering tip has cooled down.

The LED status indicator must be at „OFF“.

Keep the heat transfer surfaces of the soldering tip and

heating element clean. The heating element must not come

into contact with soldering tin.

Repairs must always be referred to a Weller-trained

specialist.

Useoriginalreplacementpartsonly.

Warranty

Claimsbythebuyerforphysicaldefectsaretime-barred

afteraperiodofoneyearfromdeliverytothebuyer.This

doesnotapplytoclaimsbythebuyerforindemnicationin

accordance with §§ 478, 479 BGB (German Federal Law

Gazette).

Weshallonlybeliableforclaimsarisingfromawarranty

furnishedbyusifthequalityordurabilitywarrantyhasbeen

furnishedbyuseinwritingandusingtheterm„Warranty“.

Thewarrantyshallbevoidifdamageisduetoimproperuse

andifthedevicehasbeentamperedwithbyunauthorised

persons.

For more information please visit

www.weller-tools.com.

EN

ENGLISH
