10 | English

The stated vibration level and noise emission value repres-

ent the main applications of the power tool. However, if the

power tool is used for other applications, with different ap-

plication tools or is poorly maintained, the vibration level

and noise emission value may differ. This may significantly

increase the vibration and noise emissions over the total

working period.

To estimate vibration and noise emissions accurately, the

times when the tool is switched off or when it is running but

not actually being used should also be taken into account.

This may significantly reduce vibration and noise emissions

over the total working period.

Implement additional safety measures to protect the oper-

ator from the effects of vibration, such as servicing the

power tool and application tools, keeping their hands warm,

and organising workflows correctly.

Assembly

u Remove the battery from the power tool before carry-

ing out work on the power tool (e.g. maintenance,

changing tool, etc.). The battery should also be re-

moved for transport and storage. There is risk of injury

from unintentionally pressing the on/off switch.

Inserting the



® Low Energy Module

GCY30-4 (Accessory)

Read the corresponding operating instructions for informa-

tion about the Bluetooth® Low Energy ModuleGCY30-4.

Charging the Battery

u Use only the chargers listed in the technical data. Only

these chargers are matched to the lithium-ion battery of

your power tool.

Note: The battery is supplied partially charged. To ensure

full battery capacity, fully charge the battery in the charger

before using your power tool for the first time.

The lithium-ion battery can be charged at any time without

reducing its service life. Interrupting the charging process

does not damage the battery.

The lithium-ion battery is protected against deep discharge

by the "Electronic Cell Protection (ECP)". When the battery

is discharged, the power tool is switched off by means of a

protective circuit: The application tool no longer rotates.

u Do not continue to press the On/Off switch after the

power tool has automatically switched off. The battery

can be damaged.

Follow the instructions on correct disposal.

Removing the Battery

The battery (6) is equipped with two locking levels to pre-

vent the battery from falling out when pushing the battery re-

lease button (7) unintentionally. As long as the battery is in-

serted in the power tool, it is held in position by means of a

spring.

To remove the battery (6), press the release button (7) and

pull the battery out of the power tool. Do not use force to

do this.

Battery charge indicator

The green LEDs on the battery charge indicator indicate the

state of charge of the battery. For safety reasons, it is only

possible to check the state of charge when the power tool is

not in operation.

Press the button for the battery charge indicator or to

show the state of charge. This is also possible when the bat-

tery is removed.

If no LED lights up after pressing the button for the battery

charge indicator, then the battery is defective and must be

replaced.

Battery model GBA 18V...

LEDs Capacity

3× continuous green light 60−100%

2× continuous green light 30−60%

1× continuous green light 5−30%

1× flashing green light 0−5%

Battery model ProCORE18V...

LEDs Capacity

5× continuous green light 80−100%

4× continuous green light 60−80%

3× continuous green light 40−60%

2× continuous green light 20−40%

1× continuous green light 5−20%

1× flashing green light 0−5%

Changing the Tool

Inserting the application tool (seefigure A)

Push the locking sleeve (2) back and insert the application

tool by turning it into the holder (1). Release the locking

sleeve (2) to lock the application tool.

Removing the application tool

Push the locking sleeve (2) back and pull the application tool

out of the holder.(1).

Fitting the adapter (see figure B)

Remove the application tool.

Insert the adapter into the holder (1). Turn the locking ring

(16) until it audibly clicks into place.

1 609 92A 53M | (09.12.2019) Bosch Power Tools
