Manual de uso Campbell Hausfeld AL2130 Sistema de pintura

Manual de uso

2

Operating Instructions and Replacement Parts List

Description

Airless paint sprayers are capable of

spraying a wide variety of latex, oil-

based, and alkyd paints, as well as

stains, preservatives and other non-

abrasive finishes. Sprayers are also pow-

erful and versatile enough to be used

with a variety of options (roller attach-

ment, extra lengths of hose, etc.) to be

an even more efficient tool.

Important Safety Instructions

Save these instructions.

This manual contains information that is

very important to know and understand.

This information is provided for SAFETY

and to PREVENT EQUIPMENT PROBLEMS.

To help recognize this information,

observe the following symbols.

Danger indicates

an imminently haz-

ardous situation which, if not avoided,

WILL result in death or serious injury.

Warning indicates

a potentially haz-

ardous situation which, if not avoided,

COULD result in death or serious injury.

Caution indicates a

potentially haz-

ardous situation which, if not avoided,

MAY result in minor or moderate injury.

Notice indicates

important informa-

tion, that if not followed, may cause

damage to equipment.

Unpacking

After unpacking the unit, inspect care-

fully for any damage that may have

occurred during transit. Make sure to

tighten fittings, bolts, etc., before

putting unit into service.

Do not operate

unit if damaged

during shipping, handling or use.

Damage may result in bursting and

cause injury or property damage.

General Safety Information

1. To reduce the risk of fire

or explosion, electrical

shock, and injury to per-

sons, read and understand

all instructions included

with this product. Be familiar with

the controls and the proper use of

the equipment.

2. This product should be grounded.

Follow all grounding instructions

included with your sprayer (pump).

!

WARNING

NOTICE

!

CAUTION

!

WARNING

!

DANGER

To reduce risk of fire or

explosion:

1. Do not spray flammable or com-

bustible materials near an open

flame or sources of ignition such as

cigarettes, motors, and electrical

equipment.

2. Paint or solvent flowing through

the equipment is able to result in

static electricity. Static electricity

creates a risk of fire or explosion in

the presence of paint or solvent

fumes. All parts of the spray system,

including the pump, hose assembly,

spray gun, and objects in and

around the spray area shall be prop-

erly grounded to protect against

static discharge and sparks. Use only

conductive or grounded high-pres-

sure airless paint sprayer hoses spec-

ified by the manufacturer.

3. Verify that all containers and collec-

tion systems are grounded to pre-

vent static discharge.

4. Connect your sprayer to a grounded

outlet and use grounded extension

cords. Do not use a 3 prong to 2

prong adapter.

5. Do not use paints or solvents con-

taining halogenated hydrocarbons

such as methyl bromine, carbon

tetrachloride, and ethyl iodine.

6. Keep spray area well ventilated.

Keep a good supply of fresh air

moving through the spray area.

7. Do not smoke or eat in the spray

area.

8. Do not operate light switches,

engines, or similar spark producing

products in the spray area.

9. Keep area clean and free of paint or

solvent containers, rags, and other

flammable materials.

10. Know the contents of the paints

and solvents being sprayed. Read all

Material Safety Data Sheets (MSDS)

and container labels provided with

the paints and solvents. Follow the

paint and solvent manufacturer’s

safety instructions.

11. Do not use materials with a flash

point less than 20°C (70°F) in or to

clean this equipment. (Examples of

acceptable cleaning solvents are:

water, mineral spirits, lacquer thin-

!

WARNING

ner, Xylene and high flash naphtha.

A PARTIAL example list of unaccept-

able cleaning solvents are low flash

naphtha, mek, acetone, alcohol,

toluene and fuels of any kind.

12. Have fire extinguisher equipment

present and working.

To reduce the risk of

skin injection:

1. Do not aim the gun at, or spray, any

person or animal.

2. Keep hands and other body parts

away from the discharge. For exam-

ple, do not try to stop leaks with

any part of the body.

3. Always use the nozzle tip guard. Do

not spray without nozzle tip guard

in place.

4. Do not remove tip while cleaning

the pump.

5. Only use a nozzle tip specified by

the manufacturer.

6. Use caution when cleaning and

changing nozzle tips. Before remov-

ing the nozzle tip, follow the manu-

facturer’s instructions for turning

off the unit and relieving the pres-

sure.

7. Do not leave the unit energized or

under pressure while unattended.

When not in use turn off the unit

and relieve the pressure in accor-

dance with the manufacturer’s

instructions.

8. High pressure spray is able to inject

toxins into the body and cause seri-

ous bodily injury. In the event that

injection occurs, seek medical atten-

tion immediately.

9. Check parts for signs of damage.

Replace any damaged parts.

10. This spray gun is rated for 3000 psi

(205 bar). Do not use on systems

designed to produce more than

3000 psi (205 bar).

11. Always engage the trigger lock

when not spraying. Verify the trig-

ger lock is functioning properly.

• To lock (engage): rotate tabs on

lock to horizontal position.

• To unlock (disengage) to spray:

rotate tabs on lock to vertical position.

!

WARNING

MANUAL

www.chpower.com
