Manual de uso Hikoki G 18DBBL Amoladora angular

Manual de uso

6

English

WARNING

If a conductive foreign matter enters in the terminal of lithium

ion battery, the battery may be shorted, causing fi re. When

storing the lithium ion battery, obey surely the rules of

following contents.

○ Do not place conductive debris, nail and wires such as

iron wire and copper wire in the storage case.

○ To prevent shorting from occurring, load the battery in

the tool or insert securely the battery cover for storing

until the ventilator is not seen.

REGARDING LITHIUM-ION BATTERY

TRANSPORTATION

When transporting a lithium-ion battery, please observe the

following precautions.

WARNING

Notify the transporting company that a package contains a

lithium-ion battery, inform the company of its power output

and follow the instructions of the transportation company

when arranging transport.

○ Lithium-ion batteries that exceed a power output of

100Wh are considered to be in the freight classifi cation

of Dangerous Goods and will require special application

procedures.

○ For transportation abroad, you must comply with

international law and the rules and regulations of the

destination country.

Wh

Power Output

2 to 3 digit number

SYMBOLS

WARNING

The following show symbols used for the machine.

Be sure that you understand their meaning before

use.

G18DBBL / G18DBBVL / G18DBBAL:

Cordless Disc Grinder

To reduce the risk of injury, user must read

instruction manual.

Always wear eye protection.

Only for EU countries

Do not dispose of electric tools together with

household waste material!

In observance of European Directive 2002/96/

EC on waste electrical and electronic equipment

and its implementation in accordance with

national law, electric tools that have reached

the end of their life must be collected separately

and returned to an environmentally compatible

recycling facility.

V Rated voltage

n

Rated speed

min

-1

Revolution or reciprocations per minute

Switching ON

Switching OFF

Disconnect the battery

Warning

Battery capacity

Remaining battery indicator switch

The battery remaining power is nearly empty.

Recharge the battery soonest possible

The battery remaining power is a half.

The battery remaining power is enough.

STANDARD ACCESSORIES

In addition to the main unit (1 unit), the package contains the

accessories listed on page 231.

Standard accessories are subject to change without notice.

APPLICATIONS

○ Removal of casting fi n and fi nishing of various types of

steel, bronze and aluminum materials and castings.

○ Grinding of welded sections or sections cut by means of

a cutting torch.

○ Grinding of synthetic resins, slate, brick, marble, etc.

SPECIFICATIONS

The specifi cations of this machine are listed in the Table on

page 10.

NOTE

Due to ’s continuing program of research and

development, the specifi cations herein are subject to

change without prior notice.

CHARGING

Before using the power tool, charge the battery as follows.

1. Connect to the power source. (Fig. 2)

When charging the battery from an AC power source

○ Connect the charger’s power cord to the receptacle.

When connecting the plug of the charger to a receptacle,

the pilot lamp will blink in red (At 1- second intervals).

CAUTION

Do not use the electrical cord if damaged. Have it

repaired immediately.

When charging the battery from a DC 12V in-car power

source (UC18YML2)

○ Secure the battery charger in place in the car.

Use the strap supplied with the battery charger to fasten

the battery charger in place and prevent it from moving

inadvertently. (See Fig. 13)

CAUTION

Do not place the battery charger or battery under the

driver’s seat. Secure the battery charger in place to

prevent it from moving inadvertently as this may lead

to an accident.

0000Book̲G18DBBL.indb60000Book̲G18DBBL.indb6 2017/12/0113:15:452017/12/0113:15:45
