Black plate (3,1)

Head unit

71 4 6

3

2

9

a de

8

5

c

b

1 h (eject)

2 SRC/OFF

3 MULTI-CONTROL (M.C.)

4

(list)

5 DISP

6 Disc loading slot

7 USB port

8 EQ

9 BAND

a

(back)/DIMMER (dimmer)

b c/d

c 1/

to 6/

d AUX input jack (3.5 mm stereo jack)

e Detach button

CAUTION

Use an optional Pioneer USB cable (CD-U50E)

to connect the USB storage device as any device

connected directly to the unit will protrude out

from the unit, which could be dangerous.

Display indication

21 3 75

9

4 6 8

a

1 (list)

2 Sub information section

3 TA (traffic announcements)

4 TP (traffic program identification)

5

(sound retriever)

6 LOC (local seek tuning)

7

(repeat)

8

(random)

9

Main information section

! Tuner: band and frequency

! RDS: program service name, PTY infor-

mation and other literal information

! CD player and USB storage device:

elapsed playback time and text informa-

tion

a

Appears when a lower tier of folder or menu

exists.

Set up menu

1 After installation of this unit, turn the

ignition switch to ON.

SET UP appears.

2 Turn M.C. to switch to YES.

# If you do not use the unit for 30 seconds, the set

up menu will not be displayed.

# If you prefer not to set up at this time, turn M.C.

to switch to NO.

3 Press M.C. to select.

4 Follow these steps to set the menu.

To proceed to the next menu option, you need to

confirm your selection.

LANGUAGE (multi-language)

This unit can display the text information from a

compressed audio file even for information em-

bedded in English, Russian or Turkish.

! If the embedded language and the selected

language setting are not the same, text infor-

mation may not display properly.

! Some characters may not be displayed prop-

erly.

1 Turn M.C. to select the desired setting.

ENG (English)—РУС (Russian)—TUR (Turk-

ish)

2 Press M.C. to confirm the selection.

CLOCK SET (setting the clock)

1 Turn M.C. to adjust hour.

2 Press M.C. to select minute.

3 Turn M.C. to adjust minute.

4 Press M.C. to confirm the selection.

FM STEP (FM tuning step)

Use FM STEP to set FM tuning step options (seek

step settings).

1 Turn M.C. to select the FM tuning step.

100 (100 kHz)—50 (50 kHz)

2 Press M.C. to confirm the selection.

QUIT appears.

! The manual tuning step is fixed at 50 kHz.

! When AF and TA are turned off, the seek step

is fixed at 50 kHz even if set to 100.

5 To finish your settings, turn M.C. to select

YES.

# If you prefer to change your setting again, turn

M.C. to switch to NO.

6 Press M.C. to select.

Notes

! You can set up the menu options from the

system menu and initial menu. For details

about the settings, refer to System menu on

page 7 and Initial menu on page 7.

! You can cancel set up menu by pressing

SRC/OFF.

Basic operations

Important

! Handle the front panel with care when re-

moving or attaching it.

! Avoid subjecting the front panel to excessive

shock.

! Keep the front panel out of direct sunlight

and high temperatures.

! To avoid damaging the device or vehicle inte-

rior, remove any cables and devices attached

to the front panel before detaching it.

English

Using this unit

3

Section

Using this unit

En

02

<QRD3204-A>3
