Instruction manual Mini Smoke Alarm

Type: RWM-20

Thank you for purchasing this Mini Smoke Alarm. Please read the instructions for use and installation carefully and be sure to follow them!

• Pass these instructions on to the person or company that installs the smoke alarm!

• The Mini Smoke Alarm is also suitable for use in caravans, boats etc.

• Home smoke alarm for private use.

1. INSTALLING THE SMOKE ALARM

• One smoke alarm is required per 60m² of floor area per storey.

Install a smoke alarm in every bedroom and corridor.

The smoke alarm must be placed in the centre of the room.

Affix a smoke alarm to the ceiling of the uppermost floor in each staircase.

INTERFERENCES

Corners and walls: Leave a gap of at least 50cm between the smoke alarm and any corners or walls.

Steam: Avoid installing the smoke alarm in close proximity to sources of steam, as these could cause false alarms (e.g. cooking vapours, showers)

Fans/ventilation systems: Avoid installing the smoke alarm close to ventilation devices. These could prevent smoke from entering the smoke alarm’s detection

chamber, thereby preventing the alarm from functioning properly. The maximum permitted air speed where the alarm is installed is 1.5m/s.

Dead air spaces with no air movement:

Avoid installing the smoke alarm on sloping roofs. Ensure a minimum distance of 10cm from the roof ridge.

Lights: Do not affix the smoke alarm directly next to a light source (minimum distance 30cm).

2. FUNCTIONS AND FUNCTIONAL TEST

Alarm: The red warning light flashes every 344 seconds (5:44 minutes) when the alarm is in standby mode. As soon as the smoke alarm detects smoke, it switches

into alarm mode.

It triggers the alarm signal and the red warning light flashes continually.

Functional test: On the bottom surface is the button that carries out a functional test. When this is held down for more than one second, the smoke alarm will be

triggered and the LED will flash continually. Once the test button is released, the alarm will cease a few seconds later and the smoke alarm will go into alarm switch-off

mode.

Switching off/muting the alarm: When the device triggers the alarm signal, the alarm can be switched off manually by pressing the test button for one second. The

switch-off is reversed automatically after 9 minutes, which is indicated by the LED flashing every 10 seconds. As soon as a critical level of smoke is detected, or the

test button is held down for longer than 1 second, the alarm signal will be triggered again.

Error mode: If the smoke alarm emits a short beep three times every 43 seconds, the device is in error mode. Clean the surface of dust using a dry, lint-free cloth. If

error mode is still indicated, the smoke alarm is no longer operational and must be replaced.

Battery warning: Once the battery has reached the end of its usable life, a short tone will sound every 43 seconds. Holding the test button down for three seconds

will switch off the battery warning for 8 hours. Replace the smoke alarm immediately once the battery warning has sounded more than four times.

Alarm memory: An alarm event is saved for 24 hours and is indicated by the LED flashing green three times.

End of life indicator: After 10 years of operation, the smoke alarm will switch into error mode and must be replaced promptly.

3. MAINTENANCE

Battery: The device contains a 3V lithium battery. The battery has a service life of approx. 10 years and cannot be replaced. The whole smoke alarm must be

replaced once the battery has been drained.

Warning: Lithium batteries can explode or cause fires if they are handled improperly!

Cleaning: Remove the device from the mounting plate and clean the outer surface regularly with a dry, lint-free cloth. Vacuum all visible openings with a vacuum

cleaner (recommended every 3 months). Carry out a functional test after cleaning the appliance.

Do not paint or stick anything to the smoke alarm, as this can impair its ability to function!

4. SPECIFICATIONS

Type: RWM-20

Principle: Photoelectric smoke detection

Voltage: 3V lithium battery

Quiescent current consumption: < 3μA

Current consumption during alarm: < 200mA

Ambient temperature: 0 - 45°C

Volume: 85 dB at a distance of 3m

Dimensions: 42,5 × Ø50,8mm

Weight: 54g

Maximum air humidity: 93%

Mandatory standard: EN 14604:2005/AC:2008

GB

Nursery

Installing in the wrong place reduces the effectiveness

of the smoke alarm!

Fix the smoke alarm to the ceiling with

a gap of at least 50cm to the wall or corner!

Living room Kitchen

Cellar

Compulsory locations for installation Recommended locations for installation

Staircase Bedroom

Caution
