Manual de uso Sylvania 6427TF Televisor

Manual de uso

VIDEO L - AUDIO - R

HEADPHONE

Y VOLUME X

MENU

L

CHANNEL

K

POWER

VIDEO L - AUDIO - R

HEADPHONE

Y VOLUME X

MENU

L

CHANNEL

K

POWER

123

456

789

0 +100

DISPLAY

VOL

CH

CH

VOL

SLEEP

CHANNEL

RETURN

MUTE

GAME

POWER

MENU

PREPARATION FOR USE

[ANTENNA CONNECTION] [CATV/SATELLITE CONNECTION]

CONNECTIONS

UHF

VHF

VHF/UHF

OUT IN

ANT

.

IN

VHF/UHF

Combiner

OR

OR

75-ohm

Coaxial Cable

From Cable

System

From Cable

System

or Satellite

Antenna

CATV Box

*

or Satellite Box

*Some cable TV systems use scrambled signals and

require a special converter to receive these channels.

Consult your local cable company.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO

WIDE SLOT AND FULLY INSERT.

MISE EN GARDE: POUR ÉVITER LES RISQUES D’ÉLECTROCUTION, INTRODUIRE

LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE

LA PRISE ET POUSSER JUSQU’AU FOND.

[EXTERNAL CONNECTION]

Rear AUDIO/VIDEO INPUT

ANT.

.

VIDEO

R

L

IN

AUDIO

IN

Front AUDIO/VIDEO INPUT

VIDEO L - AUDIO - R

Video Cable

Audio Cable

Video Cassette Recorder

Video Cable

Audio Cable

Video GameVideo Camera

Front of this TV

Rear of this TV

Note:

●

When both rear and front input jacks are connected simultaneously, priority is given to the

front jacks. When using rear input jacks, disconnect the cables from the front jacks.

Notes:

●

If you hit [GAME] when the TV is off, the TV turns on and enters in Game mode.

●

If you adjust another picture control while in Game mode, this mode will automatically be

canceled.

ex.

ex.

Cables used here are available on the market.

OPERATIONS

Note:

●

If some digits appear in the corner of the screen when the unit is turned on at the first time, hit

[POWER] without unplugging the power cord.

REMOTE CONTROL AND FRONT PANEL FUNCTION

POWER button

To turn TV on/off

Channel number buttons

CH(ANNEL)

KK

/

LL

buttons

MENU button

GAME button

SLEEP button

DISPLAY button

To display CH No./Audio Status

CHANNEL RETURN button

To return previous screen

MUTE button

VOL(UME)

KK

/

LL

buttons

To select channel

To adjust volume

Infrared Sensor Window

POWER button

CHANNEL

▲ /▼ buttons

VOLUME

mm

/

nn

buttons

MENU button

AUDIO L/R input jacks

VIDEO input jack

INSTALLING THE BATTERIES

Install two AA batteries (supplied)

matching the polarity indicated inside

battery compartment of the remote con-

trol.

[BATTERY PRECAUTIONS]

• Be sure to follow the correct polarity as indicated in the battery compartment.

Reversed batteries may cause damage to the device.

• Do not mix different types of batteries together (e.g. Alkaline and Carbon-Zinc) or old batteries

with fresh ones.

• If the device is not to be used for a long period of time, remove the batteries to prevent

damage or injury from possible battery leakage.

• Do not try to recharge batteries not intended to be recharged; they can overheat and rupture.

2

1

3

UHF/VHF Rod Antenna

(Not supplied)

OR

SELECTING AUDIO/VIDEO INPUT

You can select external input jacks by hitting [GAME] on the remote control.

HEADPHONE jack

1

1

GAME

GAME

To use external input

Picture: GAME

Input:

External

(front/rear)

2

2

15

To return to TV channel

GAME

In the Game mode, you can use front or rear input jacks with suitable picture adjustments for

video games.

2

2

[-]

GAME MODE

[+]

OFF ON

VIDEO

Select “PICTURE”

After 10 seconds

3

3

Picture: Customized

Input: External

15

To return to TV channel

GAME

MENU

VOL

You can enter into Video mode from Game mode by adjusting a Picture control.

(OUT)

(OUT)

(OUT)

(IN)

(IN)

(IN)

(IN)

(OUT)

Note:

●

The AUDIO L jack is for mono input. The sound is heard from both speakers. Use this jack for

connecting monaural audio equipment.

2 times

1

1

GAME

GAME

To use external input

Picture: GAME

Input:

External

(front/rear)

Note:

•

For your safety and to avoid damages to the unit, unplug the antenna cable from the

ANT. IN jack before moving the unit.

RF Cable

RF Cable

To cancel Game mode only
