ENGLISHENGLISH

Connections

A

Analog audio output connectors (L/R)

These output analog audio signals.

The PHONO EQ switch setting changes the type of out-

put signal.

Use the included audio cables (or commercially-available

ones) to connect to analog audio input connectors (LINE,

PHONO, etc.) on other equipment.

RCA audio cable

White (L)

Red (R)

White (L)

Red (R)

B

PHONO EQ (audio output setting) switch

ON

Audio signals that have been amplified by the built-in

phono equalizer amp are output from the analog audio

output connectors (L/R).

THRU

The MM cartridge signal is output directly through the

analog audio output connectors (L/R).

Use this when connecting to equipment that has PHONO

inputs.

o When shipped new from the factory, this is set to ON.

ATTENTION

When set to ON, if connected to the PHONO inputs of

an amplifier, for example, the output from speakers and

headphones will be very loud, which could damage

equipment or harm hearing.

C

DC input connector

After completing audio cable connections, connect the

included AC adapter here.

Confirm that the power plug of the AC adapter is

plugged into a power outlet.

o Do not use any AC adapter other than the one

included.

o The included AC adapter has plugs that can be

changed. Attach the plug that suits the region where

it is being used.

V

Be sure to connect the power cord to

an AC outlet that supplies the correct

voltage. Connection to an outlet that

supplies incorrect voltage could cause

fire or electric shock.

V

Hold the power plug when plugging it

into an outlet or unplugging it. Never

pull or yank on the power cord.

V

Unplug the power cord from the outlet

when you are not planning to use the

unit for an extended period of time.

D

STANDBY/ON button

Press the STANDBY/ON button to turn the unit on or put

it in standby.

Names and functions of parts

a

Turntable (platter)

Place records centered on the turntable (platter).

b

Counterweight

c

Tracking force adjustment ring

d

Anti-skating dial

e

Tonearm lifter

Use this to raise and lower the tip of the stylus.

We recommend using the tonearm lifter to avoid dam-

aging records and styluses, because it is safer and more

certain than using a finger to do so.

f

Tonearm holder

This is a rest for the tonearm. Gently push the clasp to the

right to release the tonearm before playing a record.

g

Tonearm

h

Rotation speed setting knob

Select the rotation speed (RPM) suitable for the record.

i

START/STOP turntable rotation knob

j

Headshell

V

Precautions when making connections

o Do not plug the unit in until after making all connections.

o Carefully read the manuals of the devices that you are

connecting and follow their instructions when making

connections.

B

C

A

RL

D

When PHONO EQ is ON

Connect to line input connectors of

amplifier, etc.

When PHONO EQ is THRU

Connect to phono input connectors

of amplifier, etc.

Included AC adapter

Amplifier

A

N

T

I

–

S

K

A

T

I

N

G

3

0

5
