ENGLISH
DATA SHEET
Connection BT + 2.4G (USB A)
Buttons 6
Adjustable DPI 800/1200/1600
Reach 10 meters
Size 109 x 68 x 36mm
Battery 3.7V 400mAh
Voltage / Current DC 5V/≤10mA
Charging connector USB Type C
Bluetooth connection
Open computer and find the Bluetooth mark, soft-press
the switch with seconds to Red (BT3.0) or Blue (BT5.0) on
windows system and Mac OS, find the Bluetooth and
click the ”add device or search” (press and hold the
switch at the bottom of the mouse for 3 seconds and
unlash the bottom) after send a signal, the indicator light
flashes quickly, the device searches for the name (middle
for BT4.0/Red light, and top for BT5.0/Blue light) and click
to connect. The mouse can be using normally.
Power consumption control
Mouse goes to sleep mode to save power in case of
non-use and it can be reactivated at press a button or
scroll wheel.
Attention
1. Do not place the device near a heat source, exposed
fire, or other places that may generate high temperature.
2. If the battery is improperly replaced, it may explode.
3. Do not ry to replace the internal rechargeable
lithium-battery.
4. Do not try to disassemble or modify the battery,
otherwise, the battery may explode or leak liquid.
KNOW YOUR DEVICE
1.- Left button
2.- Right button
3.- Metal scroll wheel
4.- Next button in file explorer or web.
5.- Back to previous button in file or web browser.
6.- DPI Key
7.- Red charging light.
8.- Power switch
9.- Mode switch Key
10.- Connectivity Options BT 5.0 / BT 3.0 / 2.4G
11.- USB-C Charging port
12.- USB A Dongle Cover
13.- Dongle USB A
INSTRUCTIONS FOR USE
Charging Instructions
Always keep the lithium battery inside the mouse, if it
runs out, please charge the mouse via the Type C
connector to a power source (charger or USB port) for
2-3 hours (depending on supply) It will turn on a red light
indicating that it is in the charging process, you can use
it while it is charging. Do not replace with any kind of
alkaline battery.
To verify the battery percentage of the mouse, it is
necessary to pair it via Bluetooth to the computer,
tablet or another and enter show / manage
connected devices, where the percentage is reflected
of charge.
2.4G wireless connection:
Find the OFF or ON marks switch at the botton of the
mouse, switch turn ON ( the round contact button (9) at
the top, soft-press to switch, modes: 2.4G/Green light
by the indicator at bottom, ). Saque el nano receptor de
la cubierta doble (12) and connect to the computer
equipment. disable bluetooth mode of the computer or
device
ENGLISH
Vorago,S.A.deC.V.
FranciscoVillaNo.3
Col.SanAgustín, C.P.45645
TlajomulcodeZúñiga,
Jalisco, México.
Tel.(33) 3044 6666
Importadora Global Rida S.A. de C.V.
Matilde Márquez No. 68
Colonia Peñón de los Baños C.P. 15520
Alcaldía Venustiano Carranza, CDMX
RFC: IGR1510164C2
Limited product warranty
Vorago equipment and / or accessories are covered by a limited
warranty for the time indicated in the annexed validity table, counting
from the date of acquisition, against any manufacturing and operation
defect, provided they have been used under normal conditions of use
during the warranty period and for which it was manufactured. Vorago
warranty the buyer the absence of anomalies regarding the materials.
Products Validity
PC, tablets, cell phones, audio, keyboards, mouse, networks and accessories 12 Months
LCD Monitor
* Except in panel (screen display) for which it will only be 12 months.
36 Months*
Computer equipment 3 years including Nanobay 3.
* Except computer equipment where the processor is integrated
36 Months *
on the motherboard it will only be 12 months.
Important warranty policy: Please read and complete this warranty policy and
seal it in the store when purchasing the product.
Product: Mouse Rechargeable
Model: MO-450 Dealer stamp
Brand: Vorago
Serial number:
Invoice number:
Delivery date:
Responsibilities
The total responsibility of Vorago will be to repair or replace the product,
including labor and parts, at no cost to the buyer when it is returned to
the point of sale, presenting this warranty policy properly completed and
stamped by the establishment where it was purchased. The product or
copy of the receipt or receipt or invoice, in which data of the product the
date of purchase is specified, to verify the times within the
warranty.
Vorago may use new parts, restored or used in good condition to repair
or replace any product, at no additional cost to the consumer. In the case
of equipment and / or accessories that can not be repaired, the change
will be generated by a similar product or with superior characteristics. This
warranty covers the transportation expenses of the product derived from
its fulfillment; which will be directly attributable to the supplier of the
product. In all replacement products, the original warranty period will be
renewed. Vorago is governed by international standards for the
manufacture of products.
How to obtain warranty support
Warranty claims are processed through the point of sale, during the first 15 days
after the purchase, as long as they meet the requirements. Guarantee claims that
can not be processed through the point of sale and any concerns related to the
product purchased should be sent with the prepaid guide by Vorago to the
address of the Vorago headquarters in Francisco Villa No. 3, Col. San Agustín, CP
45645, Tlajomulco de Zúñiga, Jalisco, Mexico.
Except in situations of force majeure or fortuitous event, the repair time in no
case will be greater than 30 calendar days from the date of receive of the
equipment in Vorago.
Exclusions
This warranty is has valid in the following cases:
a) When the product had been used in conditions other than normal.
b) When the product has not been operated in accordance with the instructions
for use.
c) When the product has been altered or repaired by unauthorized persons by
Vorago.
Vorago does not oer any other express warranty for this product.
To make the warranty valid, as well as the acquisition of parts, components,
consumables and accessories
To validate a warranty, the following information must be sent to the email:
1.- Model and color
2.- Product failure
3.-Ticket or purchase invoice (digitized)
4.-Your address with CP, telephone and full Name.
Available in the establishment where the product was purchased and / or in our
central oces:
Returns
In the case of product return, it will only be the place of purchase by the end
customer. Subject to the return policies established by the same seller
.
3
1 2
4
6
7
8
11
13
12
9 10
5
