Manual de uso Klip Xtreme KLS-650 Charme Altavoz

Manual de uso

IV. Initial setup

V. Functionality

Note: For your safety, read this manual and follow all safety instructions before using the product.

1. Auxiliary mode operation

Recommendation: An RCA to 3.5mm connector audio cable has to be used to enable audio playback from

devices fitted with an auxiliary 3.5mm jack.

a. First, connect the RCA portion of the cable to the RCA input of the speaker, then connect the other side of the

cable (3.5mm plug) to the source of choice. If the speaker is not set to the LINE IN mode, press the MODE

button to toggle through the different modes available until the preferred mode is found: Line In, Bluetooth®,

USB, SD

TM

, FM.

b. Start streaming audio files directly from the source of choice.

2. USB mode operation

a. First, connect a USB memory stick to the USB port of the speaker.

b. The speaker will detect the USB device and play the audio files. If the USB drive is not automatically

detected, press the MODE button to toggle through the different modes available until the preferred

mode is found: Line In, Bluetooth®, USB, SD

TM

, FM.

Control Description

1. Mute button

2.

3. Mode

4. REC button

5. and 16. ECHO+/-button

6. Bass +/-

7. EQ

Cancels the audio coming from the speaker. Press it again to unmute

the speaker in all modes.

Remote control

In addition to the panel controls, a remote control is included which provides additional functions to allow

greater control over the media player.

• Install the batteries in the remote control following the correct polarity as indicated inside the compartment.

(Requires two AAA batteries).

• In order for the remote to operate properly, ensure that it is pointed toward the front of the speaker.

MODE REPEAT

REC PLAY

REC

BASS TREBLE

ECHO ECHO+

EQ

MIC

VOL

0

1 2 3

4 5 6

7 8 9

-

-

+

+

VOL

-

+

-

+

M-PRI

R.DEL

VOICE

1

9

11

13

15

17

18

19

20

10

12

14

16

2

3

4

5

6

8

7

In USB/SD

TM

press this button briefly to play the previous track. Press and hold

this button to go backward fast.

In FM and Bluetooth

®

mode press it briefly to go to the previous channel or song.

This feature is not available in Line In mode

Press this button to cycle through the different audio sources: FM, Bluetooth

®

, Line in,

USB and SD

TM

modes. Press and hold this button to turn the voice prompt on or off.

Use this button to activate the recording function when using the wired or wireless

microphone. Press it again to stop this function. Insert a USB or SD

TM

drive and connect

the microphone prior to start recording. You can record from the external microphone,

Line in and FM input and save the recording to the storage device of your choice.

Enables the reverberation effect of the microphone. Use + or – to increase or

decrease the effect.

Increases or decreases the bass (low) frequencies of the speaker.

Scrolls through the different equalizer sound effects.

8. Mic volume +/- button

9. LED ON/OFF

11.

12. VOICE button

13. Repeat button

14. REC/Play button

15. R-DEL button

17. M-PRI

18. Treble +/- button

19. Vol +/-

20. Numbered keys (0 to 9)

10.

Increases or decreases the volume of the microphone.

Use this button to filter the bass effect to make the sound clearer.

Short press this button to activate the speaker from standby mode and vice

versa,press this button for three seconds to turn the LED lights on or off.

Press to start and pause media during Bluetooth

®

, SD

TM

or USB playback. In tuner

mode, press it to scan for channels. This feature is not available in Line In mode.

In USB/SD

TM

press this button briefly to play the next track. Press and hold this button

to go forward fast. In FM and Bluetooth

®

mode press it briefly to go to the next channel

or song. Note: The first time the speaker is used, press the button to search available

FM radio stations automatically. This feature is not available in Line In mode.

Use it to repeat a track or song in only in USB and SDTM modes. It has a single

repeat or repeat all function.

Use it to delete the files that have been recorded in the USB memory device.

Use it to give priority to the microphone. The music volume will decrease

automatically when the microphone is in use.

Adjusts the level of the high-frequency range.

It increases or decreases the volume level of the speaker. The volume can also be

controlled directly from each of the sources connected to the speaker.

In USB and SD

TM

modes, press any key from 0 to 9 on the remote to choose directly

the tracks you want to play.

Press this button to play what was recorded in the USB memory device.

LED

ON/OFF

1. Turn the volume control on the top panel fully counterclockwise.

2. Connect audio input devices first. Make sure all input sources such as microphones, CD players, or digital

media players are turned off and volume settings are set to their lowest settings (zero).

3. Check that the loudspeaker voltage selector is set to the same voltage as the AC power outlet.

4. Then, connect the power cord to the loudspeaker and AC power outlet.

5. Slowly turn the volume clockwise until the sound output is at the desired level. If there is no sound, check

to make sure the source equipment is providing audio output.

1. Plug the AC cable to a wall outlet.

2. When the unit is not in use or switched off, it will automatically recharge the internal battery as long as it

remains connected to utility power.

Charging the battery

Powering on the unit
